Summary of Contents for RJM OVERTURE
- Page 1 Overture ™ User’s Manual ®...
- Page 2 (2) this device must accept any interference received, including interference that may cause undesired operation. Copyright © 2021 RJM Music Technology, Inc. Overture is a trademark of RJM Music Technology, Inc. RJM and the RJM logo are registered trademarks or RJM Music Technology, Inc.
-
Page 3: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS INTRODUCTION THE BASICS FRONT PANEL CONTROLS REAR PANEL CONNECTIONS OVERDRIVE MODES USING PRESETS MIDI USAGE MIDI EXPRESSION PEDAL SETUP SETUP MODE... -
Page 4: Introduction
On its own, you can program up to 8 presets and recall them with the press of a button. If you add a MIDI controller to your setup, you can access up to 100 presets. The Overture can connect to other devices via its standard 5-pin MIDI jacks or its USB-C connector. -
Page 5: Front Panel Controls
The LED above turns red when the pedal is active, and yellow when the current preset has been edited. NOTE: Press both the SOLO and ON/OFF footswitches at the same time to switch to the next preset in the current bank. Overture Manual - 3/6/2021... -
Page 6: Rear Panel Connections
OVERDRIVE MODES Clean Boost - This mode, an RJM original, offers boost up to a light overdrive. It has the highest maximum output level of all of the modes, and is excellent at pushing an amp into overdrive. Both Bass and Treble controls are active in this mode. -
Page 7: Using Presets
You can also use a MIDI controller to select presets. This allows you to select up to 100 individual presets. To store and recall presets, use the above instructions, but instead of using the SOLO and ON/OFF buttons, select presets using your MIDI controller. More details on MIDI using can be found in the next section. Overture Manual - 3/6/2021... -
Page 8: Midi Usage
PC message received (in the range of 0-99) will re-activate the pedal. Please note that PC numbers are one lower than preset numbers on the Overture. For example, send PC#0 to recall the first preset, send PC#1 to recall the second preset, etc. -
Page 9: Midi Expression Pedal Setup
You can test your settings in real time by moving your expression pedal, or any other method of sending CCs to the Overture. The parameter settings will smoothly transition between their heel down and toe down settings as you move the expression pedal. -
Page 10: Setup Mode
LED 4 1 (default) off off off off off off off off off off off off off off off off off off off off off off off off off off off off off off off off Overture Manual - 3/6/2021... - Page 11 MIDI Cable Tester The Overture also features a built-in MIDI cable tester. To test, plug your MIDI cable into the MIDI IN and MIDI OUT jacks. Hold the MODE button. After a few seconds of holding, some of the MODE LEDs should start flashing.
