- Page 1 OPERATOR’S HANDBOOK w w w . t t i . c o m . a u TrailPro ™ with Versatile Boom and 30m Hose Reel Manufacturer of The Safest Tanks in Motion...
-
Page 2: Table Of Contents
TTi’s TrailPro HandBook ™ Table of Contents Introduction Risk Assesment Operating Instructions Mixing and Filling Calibration Calibration Procedures Spraying Guide Spray Decontamination After Season Care Versatile Boom Spray Lance Warranty Warranty Limitations Warranty Registration Card www.tti.com.au Call 1800 816 277... -
Page 3: Introduction
Please read your operators handbook carefully before mounting and using your SpotPro Deluxe sprayer. Keep your handbook in a safe place. Congratulations on your purchase of a TTi SpotPro Sprayer which is complete and ready to attach to an ATV. Ideally suited to farmers or spray contractors for weed spraying, fence line spraying, spraying of drainage channels and around buildings etc. -
Page 4: Risk Assesment
TTi’s TrailPro HandBook ™ Risk Assesment Product Information Risk Assessment Sheet TTi - TrailPro Sprayer TASK HAZARDS RISK CONTROL MEASURES Concentrate on task; follow safe manual handling techniq ues: • Don’t lif t on your own if > 20kg; •... -
Page 5: Operating Instructions
TTi’s TrailPro HandBook ™ Operating Instructions To commence spraying, connect the spray lance to the hose by tightening the hose cap to the lance grip. Do not cross thread or over tighten. • When mounting to an ATV make sure the current size ball is used. Check that the spray tank is still secure after the first 15 minutes of operation and re-tighten if necessary. -
Page 6: Mixing And Filling
TTi’s TrailPro HandBook ™ Mixing and Filling The following steps are given as a guide for mixing and filling your trailer sprayer. • Read the product label and follow all directions carefully, taking special care with regard to the order in which the products are added to the tank. -
Page 7: Calibration Procedures
TTi’s TrailPro HandBook ™ Calibration Procedures Boom Sprayers Hydraulic Nozzles Example Spray VOLUME 200 litres/hectare Read the label Product Dose 50 litres/hectare Spray QUALITY Medium Measure TIME per Measure time in seconds over land similar to 41.9 seconds 100 Metres... -
Page 8: Spraying Guide
TTi’s TrailPro HandBook ™ Spraying Guide The following steps are given as a guide for spraying with your trailer unit. • Before commencing spraying, plan the work effectively to reduce potential contamination to a minimum. • Wind Direction and speed must be taken into account. Avoid spraying on hot and sunny days or when wind speed exceeds 6.5km/h... -
Page 9: Spray Decontamination
TTi’s TrailPro HandBook ™ Spray Decontamination TTi - Operators Handbook • After use, the sprayer must be thoroughly decontaminated including tank, pump, Spray Decontamination height hoses, boom and hand lance to avoid damage to crops from harmful spray height residue and to the sprayer from corrosion or abrasion. -
Page 10: After Season Care
TTi’s TrailPro HandBook ™ After Season Care NOTE: It is important that when cleaning the sprayer one wears proper safety equipment. See your chemical or fertilizer package for this information. • After spraying chemicals run water through the tank, pump, and all hose hookups. -
Page 11: Versatile Boom
TTi’s TrailPro HandBook ™ Versatile Boom Index Code Description STAB039 Off centre end jet kit with tap STAB023 1/4” Male/Female ball valve tap STAB012 Brass offset end nozzle OC-04 TeeJet STAB011 Single swivel nozzle holder with cap 1/4” BSPM Nozzle holder with 1/4” BSPF thread - elbow... -
Page 12: Spray Lance
TTi’s TrailPro TTi - Operators Handbook HandBook ™ Spray Lance Spray Lance 29.17.02.26 29.1003.24 23.602.34 23.1310.8 23.602.29 23.1603.14 23.1304.29 23.601.25 29.1101.1 30.208.130 23.602.34 23.1003.16 29.507.10 29.801.40 29.1607.3 29.902.8 30.1903.8 w w w. t t i . c o m . a u C a l l 1 8 0 0 8 1 6 2 7 7 www.tti.com.au... -
Page 13: Warranty
Warranty Warranty Policy Your TrailPro is guaranteed free from defect in materials, workmanship or manufacture for 12 months from the date of purchase. Any parts which appear to us to be defective either in material or workmanship will be replaced or repaired at no cost to the purchaser, subject to the following conditions: 1. -
Page 14: Warranty Limitations
Any and all implied warranties are excluded. b] TTI will not be liable for any incidental, consequential or special damages and/ or expenses in connection with the purchase or use of this equipment, to the extent permitted by law. -
Page 15: Warranty Registration Card
Alternatively if you are unable to register on-line fill in all the details below, copy and email to warranty@tti.com.au or post to the address on the back cover. I have read and understood the instructions in this booklet. Date Purchased:... - Page 16 w w w. t t i . c o m . a u 1800 816 277 sal es@t ti.co m .au PO Box 137, N a t ha l i a , V I C , 3 6 3 8 M ur ra y Valley Hw y, N a t h a l i a , VI C 3 63 8...
