INSTRUCTION
Alu-Star
722077.004
∼ 220 - 240 V 50/60 Hz
3 x 0,75 - 4,0 mm²
4,00 mm²
1
2
3
[mm]
L 342, B 115, H 231
CCT
3000 K
EEK
CRI
80
I
I
/2
max
max
T50
70 A / 265 µs
INSTRUCTION
WARTUNGSPLAN/
MAINTENANCE
SCHEDULE
EN 12464
EN 13201
<100%
2019-09-11
IP 65
IK07
60
50
10
40
0
30
20
-10
10
0
-20
LED
P
39 W
EEK
A+
A+
B
B
10
1
2
DIN EN 61340-5-1
INSTRUCTION
WARTUNGSPLAN/
MAINTENANCE
SCHEDULE
Umgebungstemperatur / temperature
ambiente
=> -25 °C ... + 40 °C
P
1 x 40 W
Φ
2900 lm
RG
RG 1
C
16
10
2
EN 12464
EN 13201
EN 12464
100%
www.rzb.de
3,1 kg
C
16
3
!
H O
2
1
Advertisement
Related Manuals for RZB Lighting Alu-Star
Summary of Contents for RZB Lighting Alu-Star
- Page 1 INSTRUCTION Alu-Star 722077.004 ∼ 220 - 240 V 50/60 Hz IP 65 IK07 3 x 0,75 - 4,0 mm² Umgebungstemperatur / temperature ambiente 4,00 mm² => -25 °C ... + 40 °C [mm] L 342, B 115, H 231...
- Page 2 INSTRUCTION 722077.004 Mast / Post Ø 70 - 100 mm, Wanddicke / Post wall thickness 3,0 - 4,0 mm 8 Nm 2,5 Nm 4 mm 4 mm 2,5 Nm 4 mm 1 = frei/free 2 = N blau/blue grüngelb/ green-yellow 22 mm 4 = L braun/brown 2,5 - 3 Nm...
- Page 3 INSTRUCTION 722077.004 2019-09-11 www.rzb.de...
- Page 4 INSTRUCTION 722077.004 Der Abstand zu beleuchteten Gegenständen muss min. 0,5 m betragen! / 0,5 m The distance to the direct illuminated objects must be at least 0,5 m! Indoor & Outdoor Temperatur / temperature Temperatur / temperature => -25 °C - +40 °C =>...
- Page 5 INSTRUCTION 722077.004 [mm] Mastaufsatz / mast 982455.004 D 100, H 237, 1,7 kg Mastaufsatz / mast 982456.004 D 100, H 237, 1,7 kg Mastaufsatz / mast 982457.004 D 100, H 237, 1,9 kg Mastaufsatz / mast 982458.004 D 100, H 237, 1,7 kg Abblendschute / 982165.003...
- Page 6 INSTRUCTION 722077.004 www.rzb.de 2019-09-11...
- Page 7 INSTRUCTION 722077.004 2019-09-11 www.rzb.de...
- Page 8 INSTRUCTION 722077.004 Mast / Post Ø 70 - 100 mm, Wanddicke / Post wall thickness 3,0 - 4,0 mm RZB - Rudolf Zimmermann, Bamberg GmbH Rheinstraße 16 Telefon: 0951/7909-0 96052 Bamberg Telefax: 0951/7909-198 E-mail: info@rzb-leuchten.de www.rzb.de 2019-09-11...
