STRIPCAT™
OWNER's Manual
Revised 01.21
308.708.8185 | Hawkins@HawkinsAg.com| Rev. 01/21 | Part Number 123013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hawkins StripCat and is the answer not in the manual?

Questions and answers

Related Manuals for AGROdeviate Hawkins StripCat

Summary of Contents for AGROdeviate Hawkins StripCat

  • Page 1 STRIPCAT™ OWNER’s Manual Revised 01.21 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 01/21 | Part Number 123013...
  • Page 2 This manual is applicable to: StripCat™ Record the model number and serial number of your StripCat™ along with date purchased: MODEL NUMBER SERIAL NUMBER DATE PURCHASED SERIAL NUMBER The serial number plate is located on the frame to be readily available. It is suggested that your serial number and purchase date also be recorded above.
  • Page 3 TO THE DEALER Factory to Farm™ service includes full factory assembly. Dealer is responsible for field readiness. PRE-DELIVERY CHECKLIST Use the following checklist after your StripCat™ is completely assembled. Check off each item as it is found satisfactory or after proper adjustment is made. All working parts move freely, bolts are tight, and cotter pins are spread.
  • Page 4 Check safety/warning lights are functioning properly. (Signature Of Set-Up Person/Dealer Name/Date) All registrations must be submitted to: All registrations must be submitted to AGROdeviate within 5 business days of AGROdeviate delivery. Retain a copy of this form for 124 W 25th St. Ste C5 auditing purposes.

  • Page 5: Table Of Contents

    GENERAL INFORMATION HOW TO USE THIS MANUAL                                                           1 WARRANTY INFORMATION                                                            2 SAFETY                                                                              3 SIGNAL WORDS                                                                      3...

  • Page 7: General Information

    GENERAL INFORMATION HOW TO USE THIS MANUAL This manual is divided into sections. The first section contains a Table of Contents, General Information, and a Part Number Index. The remaining sections divide the machine into assemblies and sub-assemblies which illustrate and list all parts. Hawkins Ag parts in this manual are specially designed for this machine and should be replaced with Hawkins Ag parts only.

  • Page 8: Warranty Information

    If determined that the product is defective in material and/or workmanship, the necessary parts will be replaced and/or repaired. All warranty repair or labor is to be performed by an AGROdeviate authorized party. AGROdeviate obligation under this warranty shall be limited to repairing or replacing parts deemed defective.

  • Page 9: Safety

    If you have questions not answered in this manual, require additional copies, or the manual is damaged, please contact AGROdeviate, 124 W 25th St. Ste C5, Kearney, NE, 308.708.8185, or visit our website: www.hawkinsag.com. 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 01/21...

  • Page 10: Equipment Safety Guidelines

    SAFETY SAFETY... YOU CAN LIVE WITH IT! EQUipment Safety Guidelines Safety of the operator is one of the main concerns in designing and developing a new piece of equipment. Designers and manufacturers build in as many safety features as possible. However, every year many accidents occur which could have been avoided by a few seconds of thought and a more careful approach to handling equipment.

  • Page 12: Safety Sign Locations

    SAFETY SAFETY SIGN LOCATIONS These types of Safety Signs and locations on the equipment are shown in the illustrations below. Good safety requires that you familiarize yourself with the various Safety Signs, the type of warning and the area, or particular function related to that area, that require your SAFETY AWARENESS.
  • Page 13 SAFETY 461213 PINCH POINT - WARNING • Keep extremities clear of equipment. Object(s) can move or shift; can result in death or serious injury. • Hazards may include, but are not limited to, hinge mechanism movement, pin movement, row unit movement and shifting, accessory movement and shifting, etc. 461220 CRUSH HAZARD - WARNING •...
  • Page 14 SAFETY 461225 CRUSH HAZARD - WARNING • Keep clear of moving and shifting equipment. Equipment can move or shift; can result in death or serious injury. • Hazards may include, but are not limited to, folding wing movement, raised equipment movement and shifting, etc.
  • Page 15 SAFETY 461248 CONTENTS UNDER PRESSURE - WARNING • Do not operate if damaged or improperly pressurized. Damaged or improperly pressurized components can discharge; can result in death or serious injury. • Hazards may include, but are not limited to, damaged tire and/or rim, over pressurized tire, excessive tire wear, tire tears or punctures, ect.
  • Page 16 SAFETY 461255 ELECTRICAL SHOCK/ELECTROCUTION HIGH-CLEARANCE DANGER • Keep clear of overhead power lines, maintain 20-foot minimum distance. Electrical shock and/or electrocution can occur; will result in death or serious injury. • Hazards may include, but are not limited to, high clearance equipment, low clearance power lines, lack of awareness of surroundings, etc.

  • Page 17: Safety Sign Care

    SAFETY SAFETY SIGN CARE • Keep safety signs clean and legible at all times. • Replace safety signs that are missing or have become illegible. • Replaced parts that displayed a safety sign should also display the current sign. • Safety signs are available from Hawkins Ag.

  • Page 19: Preparation & Set-Up

    PREPARATION & SET-UP This section helps you prepare your tractor and StripCat™ for use. Your must level the implement, hook up the implement hydraulics to the tractor, and check that the hydraulics have been bled. POST-DELIVERY/SEASONAL SET-UP On initial delivery, use with a new tractor, and seasonally check and as necessary, complete these items before continuing to the routine set-up items: Bleed hydraulic fold system (page 54) Check/Change Hitch Configuration...

  • Page 20: Check/Change Hitch Configuration

    PREPARATION & SET-UP CHECK/CHANGE HITCH CONFIGURATION On initial delivery, use with a new tractor, and seasonally check and as necessary, complete these items before continuing to the routine set-up items: Choose a hitch option that is compatible with your tractor 3-point. The StripCat™ has two hitch configurations: •...
  • Page 21 PREPARATION & SET-UP TO OPERATE AS CATEGORY 4 1 Remove and store the Category 3 pins. 2 Once removed, the remaining pins are set to run the implement with a Category 4 hitch. 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 01/21...

  • Page 22: Hitching Tractor To Implement

    PREPARATION & SET-UP HITCHING TRACTOR TO IMPLEMENT On initial delivery, use with a new tractor, and seasonally check and as necessary, complete these items before continuing to the routine set-up items: 1 Connect the tractor 3-point lift arms to the lower hitch pins.

  • Page 23: Hydraulic Hose Hook-Up

    PREPARATION & SET-UP HYDRAULIC HOSE HOOK-UP The StripCat™ is equipped with independently controlled fold cylinders to individually fold the left and right wings. This requires the use of two remote valves. Hoses at base end of cylinder will unfold machine. Rod end hoses will fold machine up.

  • Page 24: Light Kit Guide And Relocation

    PREPARATION & SET-UP LIGHT KIT GUIDE AND RELOCATION The light kit is installed at the factory. However, due to shipping requirements and other circumstances, some positions are altered and SMV sign or lights may need relocated before use. Typically, the SMV sign is the only component that needs relocated;...

  • Page 25: Electrical Hook-Up

    PREPARATION & SET-UP ELECTRICAL HOOK-UP Lights are connected using a standard 7-pin connector. To connect, simply lift receptacle cover, align plug and insert. To disconnect, lift receptacle cover and remove plug. Once connected, check to make sure all lights are working properly.

  • Page 26: Leveling The Implement

    PREPARATION & SET-UP LEVELING THE IMPLEMENT Figure 1 Center Frame L/R Leveling (Figure 1) LEVEL 1 Hitch the StripCat™ to a tractor (page 14). 2 Raise the implement. 3 Adjust the tractor 2-point lift arms so that the center section tool bar is level. Wing Leveling (Figure 2 &...

  • Page 28: Operation

    OPERATION REMEMBER Your best assurance against accidents is a careful and responsible operator. If there is any portion of this manual or function you do not understand, contact Hawkins Ag. BEFORE OPERATION • Carefully study and understand this manual. • Do not wear loose-fitting clothing which may catch in moving parts.
  • Page 29 OPERATION This section covers general operating procedures. Experience, machine familiarity, and the following information will lead to efficient operation and good working habits. Always operate farm machinery with safety in mind. PRE-START CHECKLIST Perform the following steps before transporting the StripCat™ to the field. Carefully read “Important Safety Information”...

  • Page 30: Wing Lock Pins

    OPERATION WING LOCK PINS Remove the wing lock pins from the lock position and place in the non-locking position before folding the wing(s). To move wing lock pin position, pull ring cotter pin. Then, pull the pin out of the toolbar and reinsert it into the desired position.
  • Page 31 OPERATION FOLDING Fold the implement for movements on public roads and between fields and narrow clearances. Do not use the folded configuration for parking or storage. 1. Hitch tractor (page 14). 2. Move to level ground. Be aware of vertical clearance needed to fold implement. 3.
  • Page 32 OPERATION UNFOLDING Unfold the implement for adjustments, field operations, maintenance, parking and storage. 1. Unless the implement was folded, with the currently hitched tractor, only a short time ago, check for evidence of oil leaks. Check the ground at hitch connections, hose fittings and under cylinders. 2.

  • Page 33: Transport Checklist

    OPERATION TRANSPORT CHECKLIST Before transporting the implement, check the following items. Transport only with a tractor of proper size and adequate ballast. Hitch implement securely to tractor. See “Hitching Tractor to Implement” on page 14. Plug implement safety lights into tractor seven-pin connector. Make sure implement is folded properly.

  • Page 34: Leveling The Machine

    OPERATION LEVELING THE MACHINE When initially setting the StripCat™ up to operate in the field the machine should be set level front to back and level left to right. To level center and wings refer to “Leveling the Implement” section on page In order to set front to back level of machine, pull into field, then lower implement in ground.

  • Page 35: Gauge Wheel Adjustment

    OPERATION GAUGE WHEEL ADJUSTMENT Gauge wheels are equipped with two different methods to adjust the depth of the gauge wheels. The first is to use the ratcheting turn buckle. To do this, loosen the jam nut with a combination wrench ( 1 ¾”).

  • Page 36: Down Pressure Springs

    OPERATION DOWN PRESSURE SPRINGS The down pressure on each row unit can be adjusted by changing which pin hole the spring retainer is set at: FRONT HOLE: Lightest down pressure for light or sandy soils MIDDLE HOLE: Medium down pressure for most soil types. REAR HOLE: Maximum down pressure for high clay soils, compacted soils, and heavy residue.
  • Page 37 OPERATION ROW UNIT DEPTH See pages 29 & 30 for details on how to adjust depth gauge wheel and knife plate settings. StripCat™ is designed to run the knife at a depth of 5” to 8”. Deeper and shallower settings are possible, but not recommended as they will cause excessive knife blowout and/or machine wear.

  • Page 38: Row Unit Depth/Adjustment

    OPERATION ROW UNIT DEPTH ADJUSTMENT Each row can be adjusted for desired depth by changing the hole position of the depth gauge wheels. The factory setting is the second hole from the top. To adjust depth, remove the 5/8” bolts from each side using a pair of 15/16” wrenches. Depth adjustment must be done on each side of the row unit.

  • Page 39: Knife Plate

    OPERATION KNIFE PLATE The knife plate can be set in two different positions with 1-1/2” difference between the two settings. To change the position of the knife plate, remove the two 5/8” bolts that hold the knife plate between the side plates of the row unit using a pair of 15/16” wrenches. Move the knife plate to the desired position and reinstall and tighten the bolts.

  • Page 40: Residue Manager

    OPERATION RESIDUE MANAGER The residue manager is intended to scratch the surface (1/4”-1/2”) to remove most of the residue from the surface without moving too much soil. The lower the residue manager is set, the more soil will be moved. To adjust the residue manager, remove the 1/2”...

  • Page 41: Row Configurations

    OPERATION ROW CONFIGURATIONS StripCat™ row units are set up from the factory in left-hand and right-hand configurations based on which side of the residue managers and Independent Berm Builders lead and trail. Row units are alternated left and right across the machine to allow residue to flow between the units. Right-Hand Row Unit Left-Hand Row Unit 308.708.8185 | Hawkins@HawkinsAg.com| Rev.

  • Page 42: Independent Berm Builders

    OPERATION INDEPENDENT BERM BUILDERS The Independent Berm Builders on StripCat have numerous adjustable features which allow you to customize your strips. You can adjust down pressure, blade fore/aft, blade toe angle, blade depth, and distance between the blades. Independent Berm Builders 308.708.8185 | Hawkins@HawkinsAg.com| Rev.
  • Page 43 OPERATION INDEPENDENT BERM BUILDERS - DOWN PRESSURE Down pressure can be increased or decreased based on conditions. For heavy residue or compacted soil, typically, more down pressure is needed. To increase down pressure on the berm building discs, tighten the 3/4” nylon lock nut on the IBB arm compression spring.
  • Page 44 OPERATION INDEPENDENT BERM BUILDERS - DISC PITCH Adjusting the pitch of the berm building discs changes the amount of soil being moved into the strip. When the discs are set parallel to the direction of travel, very little soil will be moved. As the pitch of the discs is increased (rear edge of disc moved inward) more soil will be moved into the strip, increasing the size of the berm created by the machine.
  • Page 45 OPERATION INDEPENDENT BERM BUILDERS - BLADE DEPTH Depth of the Berm Building Blades can be adjusted by changing which hole the disc hub is bolted into. This adjustment allows for 1-1/4” of difference in blade depth. To change the depth of the blades use a 1-1/8” socket to remove the 3/4” nut from the carriage bolt, move the bolt to the other hole, making sure to get the same number of washers between the hub and stem plate as before removal, and retighten in the new position.
  • Page 46 OPERATION INDEPENDENT BERM BUILDERS - DISC SPACING Spacing between the Berm Building Discs can be changed to adjust the shape and size of the berm being created by the row unit. To achieve different spacing of the Berm Building Discs, poly spacer blocks can be removed or added on each side of the row unit.
  • Page 47 OPERATION INDEPENDENT BERM BUILDERS - FORE & AFT The Berm Building Discs can be adjusted fore & aft in order to manage residue flow and blowout from the knife. To adjust the fore & aft of the Berm Building Discs, remove the two 5/8” bolts that attach the rear IBB arms to the front IBB arm using a pair of 15/16”...

  • Page 48: Rear Finishing Tools

    OPERATION REAR FINISHING TOOLS StripCat can be outfitted with 3 different rear finishing tools: a rolling basket, iron tires, and rubber packing wheels. Each rear accessory can be added/removed by removing a 1/2” retaining pin. Each accessory can be adjusted for height by placing the pin in different holes on the stem of the accessory.

  • Page 49: Hydraulic Tripping Unit                                                         40

    OPERATION HYDRAULIC TRIPPING UNIT The hydraulic tripping system uses a pressure relief valve with constant flow from the tractor to allow the knife plate to trip when encountering a hard object in the soil and reset itself automatically. The resistance to tripping is controlled by the hydraulic system pressure and can be set between 500 and 2500 psi (see page 42 for more details).
  • Page 50 OPERATION HYDRAULIC TRIPPING SYSTEM - CONNECTING • Connect the hose from the pressure port on the hydraulic block to the pressure-side SCV port on your tractor. • Connect the hose from the return port on the hydraulic block to the corresponding return SCV port on your tractor.
  • Page 51 OPERATION HYDRAULIC TRIPPING SYSTEM - SETTING PRESSURE • The tripping force can be adjusted by adjusting system pressure on the hydraulic block. • Pressure can be adjusted from 500 to 2500psi. • To increase system pressure (more resistance to tripping) turn the adjustment screw on the hydraulic block clockwise.

  • Page 52: Bar Stands

    OPERATION BAR STANDS • Bar stands on the StripCat™ can be set to various heights to accommodate your machine storage and hookup situation. • There are multiple hole combinations between the stand tube and the receiver tube to achieve the ideal stand height.

  • Page 53: Operating Tips/Operating Speed                                                 44

    OPERATION OPERATING TIPS WHEAT STUBBLE AND SOYBEAN RESIDUE • In conditions with little residue from the previous crop, the row cleaners may not be necessary and can be adjusted up to not contact the soil or used as normal. CORN STALKS •...
  • Page 54 OPERATION SPEED RECOMMENDATIONS A speed of 5 to 6.5 miles per hour is recommended for optimum results. Faster speeds will result in more soil disturbance, knife blowout, and wear on the machine. Slower speeds may result in inconsis- tent strips. •...
  • Page 55 OPERATION PARKING For long-term parking, see also “Storage” below. 1. Choose a parking location that has room for unfolding, is level, has firm soil and is unlikely to develop soft soil in rain. With the implement still hitched, maneuver it to the parking location. If the implement must be parked folded, leave it hitched to the tractor.
  • Page 56 OPERATION FOLLOWING OPERATION • Store the unit in an area away from human activity. • Do not park equipment where it will be exposed to livestock for long periods of time. Damage and livestock injury could result. • Do not permit children to play on or around the stored unit. •...
  • Page 57 OPERATION STRIPCAT™ DO’S AND DON’TS • DO follow all safety precautions in this manual. • DO locate and familiarize yourself with the various Safety Signs and instructional decals prior to operation. • DO inspect equipment for damage and wear before use; repair as needed. •...

  • Page 59: Troubleshooting

    TROUBLESHOOTING Troubleshooting Problem Possible Cause Solution Adjust gauge wheels up to allow the toolbar to run lower (see page 26). Toolbar not running low enough. Adjust hitch settings in tractor to allow 3-point hitch to run lower. Tooling not engaging with the soil as desired.
  • Page 60 TROUBLESHOOTING Troubleshooting Problem Possible Cause Solution Increase distance between discs and knife by adjusting berm building disc width with poly spacer blocks (see page 37). Not enough space for residue between knife and discs. Increase distance between discs and knife by adjusting berm building discs fore &...
  • Page 61 TROUBLESHOOTING HYDRAULIC TRIPPING SYSTEM Troubleshooting Problem Possible Cause Solution Increase system pressure. Pressure adjust- ments should be made in 25 psi increments, as small changes to pressure can have a large System trips too easily/knives won’t Pressure relief valve set too low. effect on tripping force.

  • Page 63: Maintenance & Lube

    MAINTENANCE & LUBE MAINTENANCE • Proper maintenance will ensure longevity and optimum performance of your Hawkins equipment. • Visual inspection is recommended before each use. Check for loose bolts, worn parts, cracked welds and other damage. Replace and repair as needed. •...
  • Page 64 MAINTENANCE & LUBE DAILY MAINTENANCE 1. Inspect row units for any loose or missing hardware. WEEKLY MAINTENANCE 1. Grease the toolbar hinges - three (3) grease zerks on each hinge. 2. Grease gauge wheel bearings. YEARLY MAINTENANCE 1. Clean machine off. 2.
  • Page 65 MAINTENANCE & LUBE BLEEDING FOLD HYDRAULICS To function properly, the hydraulics must be free of air. If hydraulics have not been bled, they will operate with jerky, uneven motions and could cause wings to drop rapidly during folding or unfolding. If hydraulics were not bled during initial implement setup or if you replace a part in hydraulic system during the life of the implement, complete the following procedures: Check hydraulic fluid level in tractor reservoir and fill to proper level.

  • Page 66: Bolt Torque Chart

    MAINTENANCE & LUBE CHECKING BOLT TORQUE The table shown below gives correct torque values for various bolts and capscrews. Tighten all bolts to the torques specified in chart unless otherwise noted. Check tightness of bolts periodically, using bolt torque chart as a guide. Replace hardware with the same grade bolt. BOLT TORQUE CHART Torque Specifications Bolt Diameter...
  • Page 67 MAINTENANCE & LUBE HYDRAULIC FITTING IDENTIFICATION Hydraulic fitting styles, types and sizes are numerous and at times easily confused. The chart below shows the most common types and sizes of hydraulic fittings for the industry, male ends depicted. This chart is printed at 1 to 1 for ease of identification. NPTF (National Pipe Taper Fuel) uses tapered threads to create a seal.
  • Page 68 MAINTENANCE & LUBE CHECKING HYDRAULIC FITTINGS • Before connecting hydraulic fittings, check that fittings are clean and undamaged. Replacement fittings and hoses are available from StripCat™. • Ensure O-ring(s) are installed properly as shown in the image. (ORB fitting above, ORFS fitting below) •...
  • Page 70 PARTS GUIDE Toolbar Mount and Parallel Linkage Item Number Part # Description Quantity 333046 LH MOUNT 333047 RH MOUNT 333012 TOP PARALLEL ARM ASSEMBLY 333011 BOTTOM PARALLEL ARM ASSEMBLY 333014 PARALLEL LINK SPRING RETAINER 333150 PARALLEL LINK SPRING 333020 BENT PIN **SEE NEXT PAGE FOR REMAINING PARTS LIST** 308.708.8185 | Hawkins@HawkinsAg.com| Rev.
  • Page 71 PARTS GUIDE Toolbar Mount and Parallel Linkage Item Number Part # Description Quantity 333021 COTTER PIN BOW TIE 415004 3/4-10 X 7 X 9 UBOLT 413072 3/4 FLAT WASHER SAE Z/C 410012 3/4-10 NUT CENTER LOCK Z/C 305113 1/4 X 2 ROLL PIN 411597 3/4-10 X 6 GR 5 BOLT 411595...
  • Page 72 PARTS GUIDE SidePlate & Row Cleaner Stem Item Number Part # Description Quantity 333035 SIDEPLATE 333049 STEM 411241 5/8-11 X 10.5 GR5 Z/C BOLT 411240 5/8-11 X 6.5 GR5 Z/C BOLT 410009 5/8-11 NUT CENTER LOCK GR2 Z/C 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 01/21...
  • Page 73 PARTS GUIDE Front Coulter Item Number Part # Description Quantity 333155 20" NOTCHED COULTER BLADE 333161 SQUARE HOLE HUB W/ BEARING 333009 BEARING SPACER 333166 ROUND HOLE HUB W/ BEARING 411733 1/2-13 X 2 CARRIAGE BOLT GR5 413508 1/2 LOCK WASHER 412058 1/2-13 NUT GR5 333164...
  • Page 74 PARTS GUIDE Depth Gauge Wheel Item Number Part # Description Quantity 413072 3/4 FLAT WASHER SAE 410012 3/4-10 NUT CENTER LOCK 333048 GAUGE WHEEL BRACKET 411584 3/4-10 X 2 GR.5 BOLT 411598 3/4-10 X 6.5 GR.5 BOLT 413011 5/8 FLAT WASHER SAE 411565 5/8-11 X 3.5 GR.5 BOLT 409009...
  • Page 75 PARTS GUIDE Independent Berm Builder - Mount Item Number Part # Description Quantity 333205 5/8 WASHER 333040 IBB LEFT SIDE MOUNT BRACKET 333038 IBB RIGHT SIDE MOUNT BRACKET 333054 IBB RIGHT SIDE SUPPORT BRACKET 333055 IBB LEFT SIDE SUPPORT BRACKET 333103 IBB ARM ASSEMBLED 411241...
  • Page 76 PARTS GUIDE Independent Berm Builder - Mount Item Number Part # Description Quantity 410009 5/8-11 NUT CENTER LOCK GR2 333091 COIL SPRING 333117 SPRING PULL ROD 333072 SPRING CAP 305101 3/4-10 NUT NYLON LOCK 413012 3/4 FLAT WASHER USS 333070 IBB ARM NO BEARING 333097 5/8 BORE BEARING...
  • Page 77 PARTS GUIDE Independent Berm Builder - Rear Arms Item Number Part # Description Quantity 333059 IBB ADJUSTABLE ARM SHORT 333221 IBB ADJUSTABLE ARM LONG 333068 1 IN. POLY SPACER 333067 IBB DISK ARM 411737 1/2-13 X 4 1/2 CARRIAGE BOLT GR5 413508 1/2 LOCK WASHER 413510...
  • Page 78 PARTS GUIDE Independent Berm Builder - Coulter & Hub Bearing Housing Lip Bearing Disc Section view of NOTE: Items have a IBB Hub to show 6 on 3” Bolt pattern position of Bearing Housing lip Item Number Part # Description Quantity 333104 IBB HUB...
  • Page 79 PARTS GUIDE KNIFE PLATE - RIGID Item Number Part # Description Quantity 333050 RIGID KNIFE PLATE ASSEMBLY 333029 3/4 OD BUSHING 411569 "5/8-11 X 5.5 GR.5 BOLT" 413011 5/8 FLAT WASHER SAE 410009 5/8-11 NUT CENTER LOCK GR.2 411185 1/2-13 X 2 1/4 GR.5 BOLT 413007 1/2 FLAT WASHER SAE 412058...
  • Page 80 PARTS GUIDE REAR ACCESSORY MOUNT Item Number Part # Description Quantity 333109 REAR ACCESSORY ARM 333111 1" OD BUSHING 333116 SPRING PLATE 333197 COMPRESSION SPRING 333117 SPRING PULL ROD 333113 SPRING CAP 411568 5/8-11 X 5 GR.5 BOLT 410009 5/8-11 NUT CENTER LOCK GR.2 305101 3/4-10 HEX NUT NYLON LOCK 308.708.8185 | Hawkins@HawkinsAg.com| Rev.
  • Page 81 PARTS GUIDE ROLLING Basket Item Number Part # Description Quantity 333096 BASKET FRAME 333089 BASKET 333051 BEARING 411718 5/16-18 X 1 1/4 CARRIAGE BOLT 413005 5/16 FLAT WASHER SAE Z/C 412055 5/16-18 NUT Z/C 333021 COTTER PIN BOW TIE 333099 1/2 X 4 BENT PIN 308.708.8185 | Hawkins@HawkinsAg.com| Rev.
  • Page 82 PARTS GUIDE PACKING Wheels Item Number Part # Description Quantity 333127 ADJUSTABLE STEM 333021 COTTER PIN BOW TIE .120 WIRE X 2.75 OAL 411222 5/8-11 X 4 GR5 Z/C 333077 SPACER .688 ID X 1.00 OD 410009 5/8-11 NUT CENTER LOCK GR2 Z/C 413011 5/8 FLAT WASHER SAE Z/C 333136...
  • Page 83 PARTS GUIDE IRON TIRES Item Number Part # Description Quantity 333127 ADJUSTABLE STEM 333021 COTTER PIN BOW TIE 333152 STEEL WHEEL ASSEMBLY 411222 5/8-11 X 4 GR5 Z/C BOLT 333077 SPACER .688 ID X 1.00 OD 410009 5/8-11 NUT CENTER LOCK GR2 Z/C 413011 5/8 FLAT WASHER SAE Z/C 333205...
  • Page 84 PARTS GUIDE Left ROW CLEANER ASSEMBLY Item Number Part # Description Quantity 333183 LH STEM 416615 1/2 X 3 PUSH BUTTON QUICK RELEASE PIN 411590 3/4-10 X 3 1/2 GR5 Z/C BOLT 333186 HUB ASSEMBLY 333185 RH NOTCHED BLADE 333176 LH NOTCHED BLADE 410012 3/4-10 NUT CENTER LOCK Z/C...
  • Page 85 PARTS GUIDE Right ROW CLEANER ASSEMBLY Item Number Part # Description Quantity 333187 RH STEM 416615 1/2 X 3 PUSH BUTTON QUICK RELEASE PIN 411590 3/4-10 X 3 1/2 GR5 Z/C BOLT 333186 HUB ASSEMBLY 333185 RH NOTCHED BLADE 333176 LH NOTCHED BLADE 410012 3/4-10 NUT CENTER LOCK Z/C...
  • Page 86 PARTS GUIDE Hydraulic Trip Item Number Part # Description Quantity 333217 HYD TRIP CYLINDER PLATE 333115 1 1/4 BUSHING 333146 2 1/2 X 8 CYLINDER 411595 3/4-10 X 5.5 GR5 BOLT 413072 3/4 FLAT WASHER SAE 410012 3/4-10 NUT CENTER LOCK 308.708.8185 | Hawkins@HawkinsAg.com| Rev.
  • Page 87 PARTS GUIDE HYDRAULIC TRIP - KNIFE PLATE NOTE: Pre model year 2019 only Item Number Part # Description Quantity 333171 KNIFE PLATE ASSEMBLY 333130 PACKER SPRING BRACKET 412058 1/2-13 NUT GR5 Z/C 413007 1/2 FLAT WASHER SAE Z/C 411185 1/2-13 X 2 1/4 GR5 Z/C 410012 3/4-10 NUT CENTER LOCK Z/C 411597...
  • Page 88 PARTS GUIDE HYDRAULIC TRIP - KNIFE PLATE Item Number Part # Description Quantity 411562 5/8-11 X 2.5 GR.5 411569 5/8-11 X 5.5 GR.5 413072 3/4 FLAT WASHER SAE Z/C 410009 5/8-11 NUT CENTER LOCK GR2 Z/C 413011 5/8 FLAT WASHER SAE Z/C 333140 KNIFE PLATE STOP 333077...
  • Page 89 PARTS GUIDE Hyrdraulic TripPing System - Row Unit Item Number Part # Description 333230 40” 10 FJIC - 10 FJIC HOSE ASSEMBLY 333231 30” 10 FJIC - 10 FJIC HOSE ASSEMBLY 333232 20” 10 FEMALE 45 - 10 FEMALE 45 HOSE ASSEMBLY 333226 FITTING BULKHEAD 10 NJIC TEE 333225...
  • Page 90 PARTS GUIDE Hyrdraulic TripPing System - Manifold to tractor (Folding) Item Number Part # Description 333246 HOSE ASSEMBLY 72” LONG 12 FJIC - 8 MORB 333245 8 ORB ISO TRACTOR 1/2” QUICK COUPLER 333256 HOSE ASSEMBLY 8R30 AND 12R20/22 FOLDING MANIFOLD TO WINGS 333258 HOSE ASSEMBLY 8R36-40 &...
  • Page 91 PARTS GUIDE Hyrdraulic TripPing System - Manifold to tractor (Rigid) Item Number Part # Description 333246 HOSE ASSEMBLY 72” LONG 12 FJIC - 8 MORB 333245 8 ORB ISO TRACTOR 1/2” QUICK COUPLER 333248 FITTING 12 FJIC TO 12 MORB COUPLER STRAIGHT 333242 STRIPCAT™...
  • Page 92 PARTS GUIDE Hyrdraulic TripPing System - Manifold & Bracket Parts Item Number Part # Description 333244 STRIPCAT™ MANIFOLD BRACKET 415127 3/8-16 UBOLT 4W X 6H 413009 3/8 FLAT WASHER SAE 410006 3/8-16 NUT CENTER LOCK 333241 STRIPCAT™ MANIFOLD & GAUGE 411138 5/16-18 X 5 GR 5 BOLT 413005...
  • Page 93 PARTS GUIDE Hyrdraulic TripPing System - Mount Bracket Item Number Part # Description 333224 STRIPCAT™ HYDRAULIC TRIP MOUNT BRACKET 411586 3/4-10 X 2-1/2 BOLT GR5 4W X 6H 413072 3/4 FLAT WASHER SAE 410012 3/4-10 NUT CENTER LOCK 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 01/21...
  • Page 94 PARTS GUIDE Strip Freshener Disc Assembly Left Hand 5 Down Top View Front View Front of Machine Item Number Part # Description Quantity 333142 LH COULTER MOUNT 5 DOWN 333199 HUB ASSEMBLY 333118 16” WAVY COULTER BLADE 333141 REAR COULTER SPACERS 411185 1/2-13 X 2 1/4 GR5 BOLT 413007...
  • Page 95 PARTS GUIDE Strip Freshener Disc Assembly Right Hand 5 Down Top View Front View Front of Machine Item Number Part # Description Quantity 333143 RH COULTER MOUNT 5 DOWN 333199 HUB ASSEMBLY 333118 16” WAVY COULTER BLADE 333141 REAR COULTER SPACERS 411185 1/2-13 X 2 1/4 GR5 BOLT 413007...
  • Page 96 PARTS GUIDE Strip Freshener Disc Assembly LEFt Hand 5+5 Front View Top View Front of Machine Item Number Part # Description Quantity 333315 LH DUAL COULTER MOUNT 5+5 333199 HUB ASSEMBLY 333118 16” WAVY COULTER BLADE 333141 REAR COULTER SPACERS 411185 1/2-13 X 2 1/4 GR5 BOLT 413007...
  • Page 97 PARTS GUIDE Strip Freshener Disc Assembly RIGHT Hand 5+5 Top View Front View Front of Machine Item Number Part # Description Quantity 333316 RH DUAL COULTER MOUNT 5+5 333199 HUB ASSEMBLY 333118 16” WAVY COULTER BLADE 333141 REAR COULTER SPACERS 411185 1/2-13 X 2 1/4 GR5 BOLT 413007...
