General Information How To Use This Manual This manual is divided into sections. The first section contains a Table of Contents, General Information, Installation Guide and a Part Number Index. The remaining sections divide the machine into assemblies and sub-assemblies which illustrate and list all parts. Hawkins Ag parts in this manual are specially designed for this machine and should be replaced with Hawkins Ag parts only.
If determined that the product is defective in material and/or workmanship, the necessary parts will be replaced and/or repaired. All warranty repair or labor is to be performed by an AGROdeviate authorized party. AGROdeviate obligation under this warranty shall be limited to repairing or replacing parts deemed defective.
General Information SAFETY TAKE NOTE! THIS SAFETY ALERT SYMBOL FOUND THROUGHOUT THIS MANUAL IS USED TO CALL YOUR ATTENTION TO INSTRUCTIONS INVOLVING YOUR PERSONAL SAFETY AND THE SAFETY OF OTHERS. FAILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN INJURY OR DEATH. THIS SYMBOL MEANS: -ATTENTION! -BECOME ALERT!
General Information SAFETY... YOU CAN LIVE WITH IT! EQUipment Safety Guidelines Safety of the operator is one of the main concerns in designing and developing a new piece of equipment. Designers and manufacturers build in as many safety features as possible.
Operational Safety REmember Your best assurance against accidents is a careful and responsible operator. If there is any portion of this manual or function you do not understand, contact Hawkins Ag. Before Operation • Carefully study and understand this manual. •...
Page 10
Operational Safety Following Operation • Store the unit in an area away from human activity. • Do not park equipment where it will be exposed to livestock for long periods of time. Damage and livestock injury could result. • Do not permit children to play on or around the stored unit. •...
INstallation Guide Needed Tools: For 5/8” Axle Kit, you will need: For All Kits • Safety Glasses • 15/16” Impact Socket • 3/4” Impact Socket • Protective Gloves • 15/16” Combination Wrench • 3/4” Combination Wrench • Rubber Mallet For 3/4” Axle Kit, you will need: •...
Page 13
INstallation Guide (1) Remove Orthman™ 1tRIPr™ Residue Manager (1.3) (1.1) (1.2) 11 - Pull pin. 12 - Using leather gloves, carefully remove residue manager. 13 - Remove the depth band scraper for easier installation of Trailblazer™ - STO. CAUTION DO NOT place any body part beneath the residue manager as you remove it. 308.708.8185 | Hawkins@HawkinsAg.com| Rev.
Page 14
INstallation Guide (2) Remove nut & washer from bolt on depth band 5/8” Axle Kit: 21 - Use 15/16” Socket and Wrench to loosen nut and washer. Then remove nut and washer. 22 - DO NOT remove the bolt from depth band at this time. 3/4”...
Page 15
INstallation Guide (3) - Use new axle & rubber mallet to replace bolt on depth band New Axle 5/8” Kit (305073) 3/4” Kit (305023) 5/8” Axle Kit: 31 - Aligning the New Axle (305073) with the threaded end of the bolt, use rubber mallet to tap in the new axle in place of the bolt.
Page 16
INstallation Guide (4) - Add new hardware as shown Washer (413011) Sleeve (250013) 5/8” Axle Kit: 41 - Slide one (1) 5/8” SAE Washer (413011) over each end of the axle. 42 - Slide one (1) 5/8” to 3/4” Sleeve (250013) over each end of the axle. Washer (413072) 3/4”...
Page 17
Installation Guide (5) - Add Arms with Blades RH Arm with Blades 1 x (602413) LH Arm with Blades 1 x (602412) 5/8” Axle Kit: 51 - Slide RH Arm with Blade (602413) over the 5/8” to 3/4” Sleeve (250013). 52 - Slide LH Arm with Blade (602412) over the 5/8”...
Page 18
Installation Guide (6) - Add retaining hardware Washer 5/8” - (413011) 3/4” - (413072) Lock Nut 5/8” - (409009) 3/4” - (305101) 5/8” Axle Kit: 61 - Slide two (2) SAE Washers (413011) over the axle. 62 - Tighten one (1) Lock Nut (409009) on each end of the axle. 63 - Start with 15/16”...
Page 19
Installation Guide (7) - Add rear arms Bolt (413011) Washer (413009) 5/8” AND 3/4” Axle Kits: 71 - Place Top Cap with Logo (321530) on top of arms. 72 - Bolt Top Cap with Logo (321530) to both side arms with four (4) Bolts (411143) and four (4) Washers (413009).
Operation What to expect in the field NOTE: Pre-Production model shown. Production model may vary. • Trailblazer™ - STO operates best at speeds above 4 mph. Failure to operate above this speed will cause residue to not move properly • When set properly, Trailblazer™...
Operation Adjustments Setting Depth Your Trailblazer™ – STO unit comes equipped with depth adjustment bolts on each side of the unit. Adjust these bolts on the back to set the desired operating depth. The Trailblazer™ - STO is designed to run on depth band and float. Bolts limit downward travel to decrease aggressiveness or disengage.
Page 23
Operation Adjustments Adjust Blade Orientation Meshed Option: Factory setting. Both finger blades set to the front hole. This the more aggressive option for moving residue. Front Hole Setting Offset Option: This is the less aggressive option for moving lighter residue. In this option, one Finger Blade is set in the front hole while other is set in the rear hole.
Operation Blade Adjustment Chart Trailblazer- STO has two adjustments that can be made that affect how aggressive the residue movement is. Varying soil and residue conditions will require adjustments of both the Blade Orientation and the Aggressiveness of the depth. See chart below for the recommended settings.
Operation TROUBLESHOOTING Troubleshooting Problem Possible Cause Solution Blade not making contact with the ground. Adjust depth adjustment bolts to ensure blades touch ground. Residue build-up is preventing the blade from turning. Remove residue build-up from the row cleaner. Blade is not turning. Bearing hub bolt is bent or warped.
Page 26
Bolt Torque Checking Bolt Torque The table shown below gives correct torque values for various bolts and capscrews. Tighten all bolts to the torques specified in chart unless otherwise noted. Check tightness of bolts periodically, using bolt torque chart as a guide. Replace hardware with the same grade bolt. Torque Specifications Bolt Diameter Bolt Torque*...
Parts GUide ARm Assemblies with Blades Item Number Part # Description Quantity 321530 Top Cap with Hawkins Logo 411143 3/8-16 x 1 1/4 GR5 413009 3/8 Flat Washer SAE 308.708.8185 | Hawkins@HawkinsAg.com| Rev. 08/20...
Page 29
Parts GUIDE Left Hand Arm Assemby with Blades Item Number Part # Description Quantity 321537 Left Hand Arm Weldment 305146 1/2-13 X 3 Full Thread GR5 412408 1/2-13 Jam Nut 321547 Hub Assembly 321541 Depth Band 411590 3/4-10 X 3 1/2 GR5 410012 3/4-10 Nut Center Lock GWX20016...
Parts GUIDE Right Hand Arm Assembly With Blades Item Number Part # Description Quantity 321540 Right Hand Arm Weldment 305146 1/2-13 X 3 Full Thread GR5 412408 1/2-13 Jam Nut 321547 Hub Assembly 321541 Depth Band 411590 3/4-10 X 3 1/2 GR5 410012 3/4-10 Nut Center Lock GWX20016...
