Hanil R12 Quick Manual

Quick Guide
Display & Control Panel

Setting Speed

Press once : Setting RPM
Press twice : Setting RCF
Display Screen
Status of RPM /
RCF / Time /
Temperature /
Rotor ID / ACC /
DEC / Program

Setting Run Parameters

(RPM / RCF / Time /
Temperature / ACC / DEC)
Saving / Calling Up
a Program

Setting Temp. Limit

Temperature range that
stops operation when the
temperature is lower or
higher than the set
temperature.
Component R12 / R6
Cat. No. : CP-R12 / CP-R6

Setting Time

Setting Temperature

Up to < 100 hr Setting temperature
Continuous run (00:00) -10 to 40℃ (R12) / -20 to 40℃ (R6)
Setting temp. limit
Start Stop Lid Open

Setting ACC / DEC Rate

ACC (0 ~ 9 steps, Max.9)
DEC (0 ~ 9 steps, Natural DEC.0)
Press a parameter
to be changed
Press the
Save or call button
Press the
Temp. limit button
Serial No.

Setting the Rotor ID manually

Enter the rotor ID. manually, when
rotor id is not identified automatically
Enter the desired values
on the keypad
Enter the desired
program number on the keypad
Enter the desired temperature
range on the keypad
Installation Date
Component Max. RPM : 4,800 rpm
R12
Max. RCF : 7,470 xg
Component Max. RPM : 5,000 rpm
R6
Max. RCF : 7,261 xg

View Settings

Verifying the setting
parameters during
centrifugation

Program Save / Call

Saving a program
(up to 100)
Calling up a program
Press the
Enter button
Press the
Enter button
Press the
Enter button
