- Page 1 PEAK980 www.cadmus.com.tw User's Manual PEAK980 Ver 1.0 PEAK980 PICMG1.3...
- Page 2 PEAK980 www.cadmus.com.tw Jumpers / Headers and Connectors JFW1 SPI Rom Down Pin header / Clean CMOS Connector type：PIN‐M‐180‐2.0mm Function Function Pin No. Pin No. S_RTCRST# +3V3_SPI SPI_CS#_R SPI_CLK_R SPI_DO_R SPI_DI_R Clean CMOS Setting： Pin No. Function 1‐2 Normal default 2‐4 Clear CMOS PEAK980 PICMG1.3...
- Page 3 PEAK980 www.cadmus.com.tw JFP1 Front panel connector Connector type：PIN‐M‐180‐2.54mm Pin No. Function Pin No. Function HDD_LED PWR_LED HDD LED PWR LED HDD_LED# PWRBTN RESET + SHB_PWR_BTN# SHB_RST_BTN# GPIO1 GPIO connector Connector type：PIN‐M‐180‐2.0mm Function Function Pin No. Pin No. +5VGPIO GP74(GPO0) GPIO70(GPI0) GP75(GPO1) GPIO71(GPI1) GP76(GPO2) GPIO72(GPI2) GP77(GPO3) GPIO73(GPI3) PEAK980 PICMG1.3...
- Page 4 PEAK980 www.cadmus.com.tw ATX12V_PWR1 12V POWER connector Connector type：ATX‐F‐180‐3.5mm Pin No. Function Pin No. Function +12V +12V 5PW1 DC IN connector Connector type：POWER‐M‐180‐3.96mm Pin No. Function PEAK980 PICMG1.3...
- Page 5 PEAK980 www.cadmus.com.tw USB1 & USB2 & USB3 USB connector Connector type：PIN‐M‐180‐2.54mm Pin No. Function Pin No. Function +5V_USB2_78 +5V_USB2_78 USB2N_7 USB2N_8 USB2P_7 USB2P_8 JCOM1~ JCOM4 (RS422/RS485 by COM 1) COM PORT connector Connector type：WAFER‐M‐180‐1mm Pin No. Function RS422 RS485 COM_DCD TX‐ D‐ COM_RXD COM_TXD COM_DTR RX‐ COM_DSR RTS+ COM_RTS RTS‐ COM_CTS CTS‐ COM_RI CTS+ PEAK980...
- Page 6 PEAK980 www.cadmus.com.tw BAT1 RTC Backup Battery Connector Connector type：WIRE TO BD 1x2 1.25mm MALE 180D SMD Pin No. Function 3V_BAT Display connector Connector type：LCD‐M‐180‐1.25mm Pin No. Function Pin No. Function +3V3_DP_PWR +3V3_DP_PWR LANE1_N LANE3_N LANE1_P LANE3_P LANE0_N LANE2_N LANE0_P LANE2_P AUX_P AUX_N PEAK980 PICMG1.3...
- Page 7 PEAK980 www.cadmus.com.tw CPUF1/ SYSF1 FAN connector Connector type：W/FAN‐M‐180‐2.54mm Function Pin No. +12V FANIN1 FANOUT1 JSP1~JSP2 SATA POWER connector Connector type：WIRE‐M‐180‐2.5mm Pin No. Function PEAK980 PICMG1.3...
- Page 8 PEAK980 www.cadmus.com.tw JDB1 80 PORT connector Connector type：WAFER‐M‐180‐1mm Pin No. Function PLTRST#_BUFF_1 CLKOUT_LPC1 LFRAME# LPC_D3 LPC_D2 LPC_D1 LPC_D0 SERIRQ_R +3V3 High speed connector (EXT60P) Connector type：BD‐F‐180‐0.635mm For 2*PCIex4 , 1*PCIex1 PEAK980 PICMG1.3...
-
Page 9: Black Diagram
PEAK980 www.cadmus.com.tw Black Diagram Ordering Information Bare bone Power Requirement PEAK980 (P/N: 93710980Q370 ) • Power source from Backplane through Golden Finger Intel® 8th/9th Coffee lake Core™ I TDP 95W, Q370, LGA1151, and AUX +12V 2x2 connector 2x DDR4 up to 64GB, DVI‐I, DP , 2 x USB 3.1 (Gen1), 6x USB2.0, 2x GbE LAN , 4x SATAIII, Dimensions 3x RS232, 1x RS232/422/485, 1x 60pin connector , 1x M.2. • PICMG1.3 Form Factor, 8.9”x4.9” (228mm x 126mm) PEAK980‐H (P/N:93710980H310 ) Environment Intel® 8th/9th Coffee lake Core™ I TDP 95W, H310, LGA1151, Board level operation temperature: ‐0°C to 60°C • 2x DDR4 up to 64GB, DVI‐I, DP , 2 x USB 3.1 (Gen1), 6x USB2.0, Storage temperature: ‐40˚C to 85˚C • 2x GbE LAN , 4x SATAIII, • Relative humidity: 3x RS232, 1x RS232/422/485. – 10% to 95% (operating, non‐condensing) – 5% to 95% (non‐operating, non‐condensing) Certifications ...
