- Page 1 PIC 688 User Manual PICMG 1.3 Half Size CPU Board CADMUS ELECTRONIC CO., LTD. 2018/5/4 PIC688 User Manual...
-
Page 2: Table Of Contents
Contents Preface Copyright ....................3 Disclaimer....................3 Acknowledgements................3 RoHS Compliance................3 Package Contents…………………………………………………………….4 Ordering information……………………………………………………….4 Chapter 1: Product Introduction Overview....................6 Hardware Specifications..............6 Block Diagram..................7 Knowing Your PIC 688…..............7 Chapter 2: Jumpers and Connectors Locations of the Jumpers and Connectors........8 Jumpers....................8 Connector pin define................9-11 External Connectors................9 Internal Connectors................10-11 2018/5/4... -
Page 3: Preface
Any implied warranties of merchantability or fitness for any particular purpose is also disclaimed. Acknowledgements PIC 688 is a trademark of CADMUS ELECTRONIC CO.,LTD. All other product names mentioned herein are registered trademarks of their respective owners. RoHS Compliance... -
Page 4: Package Contents
Package Contents Before continuing, verify that the PIC 688 package that you received is complete. Your package should have all the items listed in the following table. Item Part Number Name Description 343280000104 USB cable x2 port with bracket CABLE2xUSB AF-6P(2.5) L=240mm 343820030002 Supportive power cable CABLE;3P-3P P=3.96mm L=120mm... -
Page 5: Processor Support
Backplane Selection Guide NBP1468 NBP1465 NBP1037 NBP1257 NBP1052 PIC688-H Support Support Support Support Support PIC688-Q Support Support Support Support PIC688-C PCIex16 PCIe x 8 Slot PCIe x 4 PCIe x 1 NBP1037 10 slot NBP1468 14 slot NBP1465 14 slot... -
Page 6: Chapter 1: Product Introduction
Chapter 1: Product Introduction Main Features Complies with PCIMG1.3 standard Intel® Xeon/ Intel® Core™ i7/i5/i3 LGA1151 processor with 100 Series chipset Up to 32 GB of dual-channel DDR4 1866/2133 MHz PCIe 3.0, USB 3.0, SATA 3.0, and SW Raid 0, 1, 5, 10 Supports triple display Supports TPM modules Multiple PCIe Gen3 Lanes , up to 30 port PCIe lanes... -
Page 7: Block Diagram
http://www.cadmus.com.tw Block Diagram Knowing Your PIC688 2018/5/4 PIC688 User Manual We reserve the right to change specifications and product descriptions at any time without prior notice. Last Update: 5/4/2018... -
Page 8: Chapter 2: Jumpers And Connectors
Chapter 2: Jumpers and Connectors Locations of the Jumpers and Connectors Jumpers C M O S C l e a r S e l e c t Connector type: 1x3 3-pin header Connector location:JBAT1 Settings 1-2 On *Normal 2-3 On Clear BIOS Setting A T / A T X m o d e S e l e c t Connector type: 1x3 3-pin header Connector location: ATX1... -
Page 9: Connector Pin Define
Connector Pin Definitions - External Connectors Connector location: DVI U23 D V I - I Signal Signal Signal Signal DVIdata 2- DVIdata 1- 17 DVIdata 0- C1 Analog Red DVIdata 2+ DVIdata 1+ 18 DVIdata 0+ C2 Analog Green Analog Blue CRT DDC clock 12 VGA_SCL C4 Analog horiz. -
Page 10: Internal Connectors
Connector Pin Definitions - Internal Connectors U S B 2 . 0 P o w e r i n p u t c o n n e c t o r Connector location: JUSB2 Connector location : JCON1 Definition Definition Pin Definition Pin Definition 1 P5V_OC45_C 2 USB4-... - Page 11 Connector Pin Definitions - Internal Connectors C O M p o r t ( R S 2 3 2 ) L P C C o n n e c t o r ( o p t i o n a l T P M ) Connector location :COM1/ Connector location : JDB1 COM2 /COM3 / COM4...
