Power Outlet Strip
POWER OUTLET STRIP — MOUNTED
LIST OF
COMPONENTS
For the Assembly of the
Power Outlet Strip
Item Description
A. Cord Ended Plugmold
B. Supporting Clip
C. Screw - Flat HD, #6-32x
D. Nut - Hex, #6-32
E. Washer - Lock, Split #6
F. Ty Rap Cable Tie
NOTE: The Power Outlet Strip can be
mounted on either the 48BHC or 60BHC bin
holder.
®
Qty.
1
A
4
1
/
Lg. 4
2
4
4
2
InterMetro Industries Corporation
North Washington Street, Wilkes-Barre, PA 18705
For Product Information Call: 1-800-433-2232
Visit Our Web Site: www.metro.com
INSTRUCTIONS
B
C
D
E
F
ASSEMBLY
Model Number PS36
ASSEMBLY
INSTRUCTIONS
For Power Outlet Strip
Advertisement
Table of Contents
Related Manuals for Metro DataVac PS36
Summary of Contents for Metro DataVac PS36
- Page 1 ASSEMBLY INSTRUCTIONS Power Outlet Strip Model Number PS36 POWER OUTLET STRIP — MOUNTED LIST OF COMPONENTS For the Assembly of the Power Outlet Strip Item Description Qty. A. Cord Ended Plugmold B. Supporting Clip C. Screw - Flat HD, #6-32x Lg.
- Page 2 Power Outlet Strip 3. Repeat operation #2 for the 5. If desired secure the outlet cord to ASSEMBLY remaining three supporting clips. the post with the Ty Rap Cable Ties INSTRUCTIONS Make certain all four supporting clips (Fig. 4). Cut off the excess cable tie are parallel with the bin holder, then and remove the sharp end by melting For Power Outlet Strip...
