Raynor General II WLEDRGD Manual

LED Wi-Fi Garage
®
Door Opener
Model WLEDRGD
FOR RESIDENTIAL USE ONLY
Please read this manual and the enclosed safety materials carefully!
Fasten the manual near the garage door after installation.
The door WILL NOT CLOSE unless the Protector System
aligned.
Periodic checks of the garage door opener are required to ensure safe operation.
The model number label is located on the front panel of your garage door opener.
This garage door opener is ONLY compatible with myQ
ONLY enable the Timer-to-Close or myQ remote operation feature when the garage
door opener is installed on a sectional door.
NOTE: If you are installing the garage door opener on a one-piece door, visit
www.raynor.com for installation instructions.
SERIAL NUMBER:
Please write the myQ Serial number in the box above. See page 2.
Register online at: http://blog.raynor.com/warranty-registration
Preparation . . . . . . . . . . . . . . . .2-5
Assembly . . . . . . . . . . . . . . . . .6-7
Installation . . . . . . . . . . . . . . . 8-15
Install the Door Control . . . . . . 16-17
Install the Protector System
Power. . . . . . . . . . . . . . . . . . 22-23
Adjustments . . . . . . . . . . . . . 24-26
Battery Backup. . . . . . . . . . . . 27-28
Operation . . . . . . . . . . . . . . . 29-34
Remote Control . . . . . . . . . . . 35-36
Maintenance . . . . . . . . . . . . . . . 37
Troubleshooting. . . . . . . . . . . 38-39
® is connected and properly
Accessories. . . . . . . . . . . . . . . . 40
Warranty. . . . . . . . . . . . . . . . . . 41
Repair Parts . . . . . . . . . . . . . 42-43
® Security+ 2.0 ® accessories.
CONTENTS
® . . 18-21
www.raynor.com
Raynor Garage Doors
1101 E. River Rd.
Dixon, Illinois 61021
