GB
BEFORE USING THE APPLIANCE FOR THE FIRST TIME:
•
FOLLOW THE "INSTALLATION INSTRUCTIONS".
•
REMOVE THE TRANSIT BOLTS BEFORE USING THE MACHINE FOR THE FIRST
TIME.
•
First wash cycle without laundry:
1. Turn on the water supply tap.
2. Close the door.
3. Pour a small amount of detergent
4. Select a short programme (see programme chart).
5. Press the "ON/OFF" button.
The "Power on" indicator shows that the appliance is switched on.
This will remove any water remaining in the machine from the manufacturer's test run.
24
QUICK REFERENCE GUIDE
(approx. 30 ml) into the detergent dispenser.
Advertisement
Table of Contents
Related Manuals for Bauknecht wt 1530
Summary of Contents for Bauknecht wt 1530
- Page 1 QUICK REFERENCE GUIDE BEFORE USING THE APPLIANCE FOR THE FIRST TIME: • FOLLOW THE “INSTALLATION INSTRUCTIONS”. • REMOVE THE TRANSIT BOLTS BEFORE USING THE MACHINE FOR THE FIRST TIME. • First wash cycle without laundry: 1. Turn on the water supply tap. 2.
-
Page 2: Table Of Contents
CONTENTS INSTALLATION INSTRUCTIONS Page APPLIANCE AND ACCESSORIES Page CHILD SAFETY DEVICE Page PROTECTING THE ENVIRONMENT Page SAFETY INSTRUCTIONS Page MOVING AND TRANSPORTING THE APPLIANCE Page WASHING - PREPARING THE LAUNDRY Page WASHING - DETERGENT AND ADDITIVES 33+34 Page WASHING - DYEING AND BLEACHING Page WASHING - SELECTING THE PROGRAMME / PROGRAMME START... -
Page 3: Installation Instructions
INSTALLATION INSTRUCTIONS TRANSIT BOLTS The appliance is fitted with transit bolts to prevent internal damage while it is being moved. Before using the appliance the transit bolts MUST be removed (fig. 1). 1. Slacken the bolts with the spanner supplied (Fig. - Page 4 INSTALLATION INSTRUCTIONS INSTALLATION • Install the appliance on a solid and level floor surface, preferably in a corner of the room. • Make sure that all four feet are resting firmly on the floor and check that the appliance is perfectly level (use a spirit level).
- Page 5 INSTALLATION INSTRUCTIONS WATER SUPPLY • Supply: Cold water only • Tap: 3/4” threaded hose connection • Water pressure : 100 - 1000 kPa (1- 10 bar). INLET HOSE 1. If no permanent filter is installed, the supplied filter must be fitted into the threaded hose connection. 2.
- Page 6 INSTALLATION INSTRUCTIONS DRAIN HOSE • Fitting the drain hose. Remove elbow from the drum and insert into the free end of the drain hose. Install drain hose either a the siphon trap or, using the elbow, hang over the edge of a wash basin or sink (see Fig.).
-
Page 7: Appliance And Accessories
APPLIANCE AND ACCESSORIES 1. Worktop. 2. Control panel. 3. Detergent dispenser. 4. After-Sales Service sticker (inside door). 5. Door with touch protection. 6. Door handle. to open the door: pull the handle out. press the door firmly (the lock will click into place). 7. -
Page 8: Protecting The Environment
PROTECTING THE ENVIRONMENT • Packing Only use stain remover if absolutely The packing consists of 100% recyclable necessary. material and is labelled with the recycling After emergency drainage the appliance will symbol be completely empty. After installing the filter, • Appliance we therefore recommend pouring approx. -
Page 9: Washing - Preparing The Laundry
WASHING - PREPARING THE LAUNDRY 1. Sort laundry as follows... • Fabric type / Care label Cotton, cotton/synthetic mix, synthetics, wool. • Colour Separate white from coloured items. Wash new coloured items separately. • Size Washing articles of different size together improves wash efficiency and distributes the load better in the drum. -
Page 10: Washing - Detergent And Additives
WASHING - DETERGENT AND ADDITIVES SELECTION • Do not machine wash or dry fabrics that have been treated with wax, benzene or The type of detergent depends on: flammable liquids. The fumes can cause a • the type of fabric (cotton, synthetics, fire or explosion hazard. -
Page 11: Washing - Dyeing And Bleaching
WASHING - DETERGENT AND ADDITIVES Notes: • For programmes with prewash, liquid detergents can be used for the prewash. In • When using highly concentrated detergents, this case only use powder detergents for the use the detergent ball provided with the main wash. -
Page 12: Washing - Selecting Special Options
WASHING - SELECTING SPECIAL OPTIONS 1. Intensive Rinse • Finish rinse hold: Press the Rinse hold button again: spinning continues automatically • leads to extended rinsing time and higher according to the programme. water level, thereby improving rinsing performance. 3. Spin Speed Reduction •... -
Page 13: Washing - Door Lock / Programme End
WASHING - DOOR LOCK / PROGRAMME END DOOR LOCK PROGRAMME END After a washing programme has finished,the The door locks automatically after the door can be opened in position of the programme start until the end of the programme. programme sequence and the laundry removed. After the appliance has been switched on and the desired programme has been selected, the Switch off the appliance by pressing the... -
Page 14: Drying - Preparing The Laundry
DRYING - GENERAL INFORMATION Programme interruption Not suitable for machine drying • The drying process should not be interrupted! Particularly delicate textiles, e.g. B. Curtains Possible consequences: Heavy creasing and made of synthetic fibres, wool items, silk, fabrics risk of scorching! with metal inserts, nylon stockings, large items, e.g. -
Page 15: Drying - Selecting The Programme
DRYING - SELECTING THE PROGRAMME Different drying times may be chosen, depending on the load and the desired degree of drying. Drying times see enclosed programme chart. Washing and drying continuous Load: Cotton max. 2.5 kg Synthetics max. 2.0 kg •... -
Page 16: Drying
DRYING Drying Note: If a detergent dosing aid was used it must be removed prior to drying. First cycle • Load laundry and close door • Set programme selector knob to red position. • Set the drying time according to load and degree of drying. -
Page 17: Drying - Cold Phase / Programme End
DRYING - COLD PHASE / PROGRAMME END Cold phase • Each programme contains a 10-minute cold phase prior to program completion to allow the laundry and the drum to cool down. • The cold phase must not be shortened, interrupted or even left out: increased creasing and danger of burning. -
Page 18: Removing The Filter / Draining Residual Water
REMOVING THE FILTER / DRAINING RESIDUAL WATER WHEN SHOULD THE FILTER BE REMOVED? • Check/clean the filter regularly, at least 2 or 3 times per year. • When the appliance does not drain or spin properly. • If the pump is blocked by a foreign body (button, coin, safety pin, ...). -
Page 19: Care And Maintenance
CARE AND MAINTENANCE APPLIANCE EXTERIOR AND CONTROL PANEL • Clean using standard household detergent (do not use abrasive products). • Dry with a soft cloth. DETERGENT DISPENSER 1. Press down the release lever in the prewash dispenser and pull out the dispenser. 2. -
Page 20: Troubleshooting Guide
TROUBLESHOOTING GUIDE If the water stop was released: Your washing machine is equipped with safety functions, which can detect faults early and react A released water stop can be recognised by the accordingly. fact that the water flow is interrupted and a Often these are no more than minor problems continuous pumping noise can be heard. -
Page 21: After-Sales Service
TROUBLE SHOOTING GUIDE Detergents and fabric conditioners are • For subsequent or separate drying: has the not fully delivered: washing programme selector knob been set Please check whether: to the red position? • The siphon device is seated correctly and is The laundry does not have the desired clean (see “Care and Maintenance”/ “Detergent Dispenser”).
