Tektronix 3 Series Service Manual page 41

Fig. &
index Tektronix part Serial no.
number number effective
-4 133-0194-XX
-5 211-1585-XX
-6 133-0192-XX
-7 878-1622-XX
-8 878-1620-XX
-9 380-1331-XX
-10 131-9410-XX
-11 361-1892-XX
-12 065-1038-XX
-13 260-3116-XX
-14 335-4091-XX
-15 065-1043-XX
065-1044-XX
-16 366-0944-XX
-17 366-0943-XX
Table continued...
3 Series MDO Mixed Domain Oscilloscope Service Manual
Serial no.
discont'd Qty Name & description
2 CONTACT, SPRING FRONTPANEL, LED BOARD TO CHASSIS,
INSTALLED ON SPACER
SCREW, DELTA-PT, 3MM X 8MM, T10
3
CONTACT, SPRING FRONT PANEL
3
1 ASSEMBLY, CIRCUIT BOARD, PROBE INTERFACE
Return the instrument to Tektronix for service.
1 ASSEMBLY, CIRCUIT BOARD, FRONT PANEL ENCODER
Return the instrument to Tektronix for service.
1 HOUSING, PROBE COMP
Return the instrument to Tektronix for service.
CONNECTOR,RECEPTACLE,GROUND JACK
1
1 SPACER, FRONT PANEL
Return the instrument to Tektronix for service.
MODULE ASSY:SERVICE REPLACEMENT KIT;FRONT PANEL DOME
1
SWITCH ARRAY, AND PCBA, FRONT PANEL-SWITCH/LED, MDO32
AND MDO34
Return the instrument to Tektronix for service.
1 EMAT, FRONT PANEL
Return the instrument to Tektronix for service.
1 LABEL, BLACKOUT, EMAT OVERLAY
Return the instrument to Tektronix for service.
1 SERVICE REPLACEMENT KIT; 2CH FRONT CASE ASSY, 3 SERIES
MDO (PLASTIC AND LABELS)
Return the instrument to Tektronix for service.
SERVICE REPLACEMENT KIT; 4CH FRONT CASE ASSY, 3 SERIES
1
MDO (PLASTIC AND LABELS)
Return the instrument to Tektronix for service.
2 KNOB, MEDIUM WITH OVERMOLD
3 KNOB, SMALL WITH OVERMOLD
Replaceable parts
31
