Exitronix RMW Series Installation Instructions

READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
When using electrical equipment, basic safety precautions should always be followed including the following:
• DISCONNECT AC POWER SUPPLY BEFORE SERVICING.
• Installation and servicing of this equipment should be performed by qualified service personnel only.
• Ensure that the electrical wiring conforms to the National Electrical Code NEC® and local regulations if applicable.
• Do not mount near gas or electrical heaters.
• Do not use outdoors.
• Equipment should be mounted in locations and at heights where it will not be readily subjected to tampering by
unauthorized personnel.
• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
• Any modification or use of non-original components will void the warranty and product liability.
• Do not use this equipment for other than intended use.
• Allow battery to charge for 24 hours before first use.
1. Trace and cut an 8 1/8" x 10 3/4" rectangular hole in the ceiling.
2. Knockout the appropriate mounting holes and wire pass-through hole.
3. Insert back box inside rectangular cutout and secure in place using cables/chains and the appropriate hardware
for the application. (supplied by others) (Fig.1).
4. All electrical connections should be made inside the junction box (supplied by others).
120VAC
White - Common
Black - 120V
Green - Ground
CAUTION! Failure to cap unused wires may result in a shock hazard or unsafe condition as well as equipment
failure.
10070210 Rev 2 - 04/19

IMPORTANT SAFEGUARDS

SAVE THESE INSTRUCTIONS!
Cable/Chains
Fig. 1
277VAC
White - Common
Orange - 277V
Green - Ground
INSTALLATION INSTRUCTIONS
Cable / Chains
1
RMW Series
800.533.3948 • www.barronltg.com
