Owner's Guide
Installation manual
Please read this manual before installing
and using your Exhale fan to avoid injury and
We recommend to ask for a qualified electrician to
Keep this manual in a safe location for future
reference. The manual can also be downloaded from
Exhale Europe – 806 route Antibes 06410 BIOT France
www.exhale-europe.com
&
product damage.
install the fan for you.
our Website
- +33 4 92 38 96 50 – contact@exhale-europe.com
.
GB
V6
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EF34 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Exhale Fans EF34

Summary of Contents for Exhale Fans EF34

  • Page 1 Owner’s Guide & Installation manual Please read this manual before installing and using your Exhale fan to avoid injury and product damage. We recommend to ask for a qualified electrician to install the fan for you. Keep this manual in a safe location for future reference.

  • Page 2: Part List

    MODEL EF34 Part List Ceiling Mount LED Light Exhale Fan (Prebuilt) Flat countersunk head screw, Quantity 5, for fixing the fan on the underside of the motor DC Motor Wire nuts Quantity 3 Screw flat rounded heads, for mounting the motor...
  • Page 3 Please read this manual entirely before starting the installation of the Exhale fan and keep it. If necessary, you can download this manual again from the Exhale online shop To reduce the risk of electric shock, ensure that the power has been turned off at the Children (even if supervised) must not play circuit breaker or fuse box before with the device.

  • Page 4: Installation

    Installation Step 1. Determine the location The preferred location for the EF34 is in the center of the room, this position will provide the best performance of the fan. If you intend to place multiple fans in the same room you should divide the room into equal sections and place the fans in the center of each section.
  • Page 5 MODEL EF34 Step 4. Ceiling Mount a. Pass the electrical wires from ceiling through the ceiling mount center hole as shown on Figure 1 b. Fix the support to the ceiling with suitable screws c. Using a level make sure the mount is plumb and level to the floor, adjust if necessary.
  • Page 6 MODEL EF34 Household phase and neutral Figure 3. ground Red wire with household phase Black wire with household neutral Phase = Red Yellow / Green wire with household ground Neutral = Black Step 6 Mounting the motor Pre-install 2 of the included #10-24 screws half-way...
  • Page 7 MODEL EF34 Step 7. Hanging the Disc Array a. Using only 2 of the included ¼-20 flat head motor mount screws, install them full rotation as shown on figure 5 NOTE: these screws will be tightened completely in a later step...

  • Page 8: Remote Operation

    MODEL EF34 Step 8. Install the plastic cover (If LED Option go to next step) Install the plastic cover by sliding it over the centre of the disc block (see figure 8). The cover is held in place by friction. There is no need to force it on, just push lightly Figure 8.
  • Page 9 MODEL EF34 Remote Operation (cont.) Operating Functions of the Remote: The motor has 6 speeds (1 to 6) • To turn the fan ON and OFF select the button labeled POWER. • To Increase or Decrease fan speed select SPEED UP or SPEED DOWN button. The illuminated scale at the top of the remote will indicate the speed selected 1 through 6.

  • Page 10: Optional Accessories

    MODEL EF34 Optional Accessories A- Concrete Mounting Hardware Concrete mounting hardware MUST be used when installing directly to concrete without the use of a juntion box. Installation step 1-3 should be completed prior to installation of the ceiling mount. Place the ceiling mount flush onto the ceiling in the location where the fan will be mounted.
  • Page 11 Optional Accessories (continued) B. LEDS Lighting system Part List WARNING: Turn off all electrical power prior to making any electrical connections. Failure to do so will damage the led and could result in electrical shock, personal injury or death Main housing LED Warm / Cool Spacers a.
  • Page 12 MODEL EF34 Optional Accessories (continued) C. WIRELESS WALL SWITCH LIGHT DIMMER CHANGE FAN ROTATION 20 to 100 % CW/ CCW LIGHT ON/OFF POWER ON (from 1 to 6) PROGRAMMER POWER OFF 1 - 2 - 4 - 8 H a. Installation...
  • Page 13 MODEL EF34 Optional Accessories (continued) b. Synchronisation of the wall switch (wireless wall control) • Turn off the electricity at the electrical panel and wait at least 10 seconds. • Reconnect the electricity • Within 60 seconds of turning on the power, hold down the LED (orange) button (center button) until you hear a beep (about 5-10 seconds).
  • Page 14 This rod is suitable for fixing the fan to a sloping ceiling Tiltable from 0 to 45° 5 levels of adjustment It has 5 levels of adjustment (from 29 to 39 cms in total) It supports slope angles of up to 45 degrees It has been developed especially for Exhale fans...
  • Page 15 MODEL EF34 SPECIFICATIONS TECHNIQUES DIMENSIONS VOLTAGE OTIONS Height: 7,5 in / 18,4 cm AC INPUT 220 V, 50 Hz Width: 34 in / 86,4 cm 50 W, max 0,5A Weight: 25 lbs / 11,4 kg ENERGY USAGE SOUND (dB) Level 1...
  • Page 16 MODEL EF34 LEXICON LEVEL 1 Black metal mounting bracket with holes for ceiling mounting. On the circumference four threaded holes to receive the 4 golden curved fixing screws for connection with the top of the engine and this support. A hook for engine support the time of the electrical connection with the ceiling wires.
