Exhale Fans EF34 Owner's Manual
Hide thumbs
Also See for EF34:
- Owner manual & installation manual (15 pages) ,
- Owner manual & installation manual (12 pages) ,
- Owner's manual and installation manual (16 pages)
Table of Contents
Advertisement
Quick Links
GB
V5.1
M O D E L E F 3 4
F A N S
Owner's Guide & Installation Manual
Please read this manual before installing
and using your Exhale fan to avoid injury and product damage.
We recommend to ask for a qualified electrician
to install the fan for you.
Keep this manual in a safe location for future reference.
The manual can also be downloaded from our Website.
Exhale Europe/Freerise – La Noria 14 – 806 route d'Antibes, 06410 BIOT, France
www.exhale-europe.com – contact@exhale-europe.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Exhale Fans EF34
Summary of Contents for Exhale Fans EF34
- Page 1 V5.1 M O D E L E F 3 4 F A N S Owner's Guide & Installation Manual Please read this manual before installing and using your Exhale fan to avoid injury and product damage. We recommend to ask for a qualified electrician to install the fan for you.
-
Page 2: Parts List
F A N S must be able to support at least 25 Wireless Remote kg (fan is 11.3 kilos) Protected by one or more of the following US patents: (D652.133S, 29/341,859, 29/391,310, 13/662,910) © Exhale Fans, LLC 2018. All rights reserved... -
Page 3: Installation
Step 1. Determine the location The preferred location for the EF34 is in the center of the room, this position will provide the best performance of the fan. If you intend to place multiple fans in the same room you should divide the room into equal sections and place the fans in the center of each section. -
Page 4: Step 4. Ceiling Mount
WARNING: To reduce the risk of electrical shock, DO NOT use a wall-mounted speed control with this fan. Protected by one or more of the following US patents: (D652.133S, 29/341,859, 29/391,310, 13/662,910) © Exhale Fans, LLC 2018. All rights reserved... - Page 5 Be sure an align the two twist lock channels with the 2 pre-installed screws added first. Figure 5. Protected by one or more of the following US patents: (D652.133S, 29/341,859, 29/391,310, 13/662,910) © Exhale Fans, LLC 2018. All rights reserved...
- Page 6 WARNING: Not tightening the motor mounting screws properly could result in a weak connection of disc array to the motor and cause the fan to become unstable or fall. Protected by one or more of the following US patents: (D652.133S, 29/341,859, 29/391,310, 13/662,910) © Exhale Fans, LLC 2018. All rights reserved...
- Page 7 F A N S assistance. Figure 9a. Protected by one or more of the following US patents: (D652.133S, 29/341,859, 29/391,310, 13/662,910) © Exhale Fans, LLC 2018. All rights reserved...
- Page 8 Please note that if a Power Failure occurs you may have select the CW / CCW direction button since it is not remembered by the fan. Protected by one or more of the following US patents: (D652.133S, 29/341,859, 29/391,310, 13/662,910) © Exhale Fans, LLC 2018. All rights reserved...
-
Page 9: Energy Usage
WARNING: Make sure the fan is turned off and is not spinning before attempting to clean with either of the methods listed above. Protected by one or more of the following US patents: (D652.133S, 29/341,859, 29/391,310, 13/662,910) © Exhale Fans, LLC 2018. All rights reserved... -
Page 10: Optional Accessories
Please make all electrical connections within the terminal block according to your local standards and regulations. Protected by one or more of the following US patents: (D652.133S, 29/341,859, 29/391,310, 13/662,910) © Exhale Fans, LLC 2018. All rights reserved... - Page 11 You can now line up the tangs of the Main Housing to the retainer clips from the LED Housing and gently rotate clockwise to lock them in place. Protected by one or more of the following US patents: (D652.133S, 29/341,859, 29/391,310, 13/662,910) © Exhale Fans, LLC 2018. All rights reserved...
- Page 12 Level 5 Black plastic case for LED lighting support (warm W or C cold light) or replacement cover. Protected by one or more of the following US patents: (D652.133S, 29/341,859, 29/391,310, 13/662,910) © Exhale Fans, LLC 2018. All rights reserved...
