Key Points:
Check your contents
•
Read thoroughly before
•
attempting to assemble or
operate.
Do not attempt to fit the battery
•
until both assembly tasks have
been completed!
Thank you for your purchase, please call if you need any help or advice. Your support online would be
much appreciated. Kind Regards Andrew Davidson Managing Director of WJ Bowman (1984) LTD.
Check contents
Having moved the protective card from around the clay pigeon trap, check its contents to ensure they are
all present. You should have included:
•
Trap fixed to a plywood base
•
Carousel (pre-mounted)
•
Coil of 50m cable & button unit or wireless radio control (if purchased)
•
Yellow safety ring
•
Bowman mini barrow (if purchased with the trap)
Positioning and fixing clay pigeon trap
Your clay pigeon trap can be fixed onto and operated from a pallet however, we could recommend a more
permanent bolted position or the bowman mini barrow. If you have purchased a Bowman mini barrow
position the trap onto the barrow and line up the 4 bolt holes. Use the 10mm bolts provided to secure your
trap to the mini barrow. A washer should be placed on either side, a spring washer goes on before the nut
to secure.
COMPACT 150
INSTRUCTIONS
Think! Safety First!
These machines can cause serious injury, read these
instructions prior to assembly and use.
If you are missing any contents, are unsure or concerned
about the use of your clay pigeon trap then please don't
hesitate to call bowman's directly on 01777 870243.
Tools Required to assemble: 2 x 17mm spanners & wire
cutters / scissors.
WJ Bowman
High Street East Markham
Nottinghamshire NG220RE
01777 870243
www.bowmantraps.co.uk
@bowmantraps
01
Advertisement
Table of Contents
Related Manuals for BOWMAN COMPACT 150
Summary of Contents for BOWMAN COMPACT 150
- Page 1 Your clay pigeon trap can be fixed onto and operated from a pallet however, we could recommend a more permanent bolted position or the bowman mini barrow. If you have purchased a Bowman mini barrow position the trap onto the barrow and line up the 4 bolt holes. Use the 10mm bolts provided to secure your trap to the mini barrow.
- Page 2 1. First task: fit your safety ring Screw the 10mm studding into the Locate steel tabs on either side of Push the ends of the safety rings onto front of the steel body and lock off the traps main frame the steel mounts on each side of the with the 10mm nut trap to secure.
- Page 3 Use of the clay pigeon trap With both tasks complete, the trap is now ready to connect to the battery. When preparing to connect the battery move to a safe position at the rear of the trap and make sure that NO-ONE is in the DANGER ZONE in front of the trap or inside the area marked out by the safety ring.
- Page 4 Electric Box The motor is protected by either a fuse or circuit breaker housed in the control box. If the fuse is activated it can easily be replaced. Two spare fuses are supplied in the control box. If the circuit breaker is activated the Thermal Overload reset button will pop up to cut the power.
