- Page 2 MD100H Start Up Instructions Page 1/2 Wiring This is for use by persons familiar with vfds and is intended to highlight details specfic to this model for the purpose of commissioning. It is assumed personnel using this document are familiar with local code requirements for wire size & circuit protection, the dangers associated with high voltage, and are capable of safely mechanically mounting the VFD.
- Page 3 Page 2/2 Display Overview & Easy Start 3. EXECUTE "EASY START" FUNCTION This function will set up motor data, permit selection of a macro, and configure automatic 1. POWER UP restart criteria. If you are using an analog speed reference, and are using P1 on the terminal block, this will permit operation in auto mode in only a few minutes.
- Page 4 IOM_MarathonDrive_MD100G_QuickStart_0615...
