GROLAB POWERBOT Installation Manual page 6

1
110~
EN
ES
2
Module reset bu on
FR
3
Manual switch bu ons
4
External switch input
5
Temperature & humidity sensor outlet
6
Type-B USB outlet
7
Mul sensor connec on outlet
8
Module status signal LED
9
Output status signal LED
10
Brackets for wall-moun ng
11
Universal socket outlet
12
Flood detector outlet
13
RF antenna outlet
5
230V power outlet
AC
(for Firmware update)
