- Page 1 User Manual for Forecourt Controllers Version 02 23 February, 2021 1414 Radcliffe St. Suite 120 Bristol, PA 19007 Phone: 215.785.6200 Fax: 215.785.0230 COPYRIGHT © 2021 ALLIED ELECTRONICS, INC. Page 1 of 9 User Manual...
- Page 2 Revision History Version 02 February 23, 2021 User Manual Established, Refer to Installation Guide for wiring and programming Version 01 February 16, 2021 Initial version NeXGen Prime Page 2 of 9...
-
Page 3: Table Of Contents
Table of Contents 1 General Information ...................... 4 1.1 Scope ........................4 1.2 Warranty ........................ 4 1.3 FCC Warning ......................5 1.4 PCI PA-DSS ......................5 1.5 Installation Environment ..................5 1.6 Power and Data line protection ................6 1.7 Forecourt Peripherals Overview ................6 2 Connections ......................... -
Page 4: General Information
General Information NeXGen Prime (NXG-P) provides NeXGen (NXG) functionality using more powerful and modern hardware. The Compact Flash and SRAM have been replaced by an SSD (Solid State Drive). Operationally, NXG-P includes the ANDI forecourt controller functionality and is similar to Aegis, but without the presence of the Windows Embedded system. -
Page 5: Fcc Warning
Support or through the Allied Sharefile site. 1.5 Installation Environment 1. The Allied Electronics NXG-P Controller operates on 115 VAC @60Hz, 36 Watts. The NXG- P controller is supplied with approximately 8 feet of 115 VAC power cord, and should be connected to an approved isolated ground receptacle on its own dedicated circuit. -
Page 6: Power And Data Line Protection
1.6 Power and Data line protection Allied Electronics recommends that the controller be installed with the appropriate power and data line protection devices in order to protect against power surges, transients, low voltage (brown outs), and lightning. Note: Due to the magnitude of power that is contained within a lightning strike, it is impossible to eliminate totally the possibility of damage, but we feel with the introduction of high-quality protection devices the incidence of failure can be greatly reduced. -
Page 7: Connections
Tank Gauge Veeder-Root TLS 250, 350 & 350R or equivalent tank gauge system via an RS-232 port or the TLS 450 through Ethernet Any Tank Gauge system that supports the Veeder Root protocol. Car Wash Ryko III, Ryko IV, Unitec POS 4000, Unitec/Enterlink, Unitec Portal Ti, Unitec Smart Terminal, PDQ, Kesseltronics and Exacta Car Wash controllers via a fully populated RS-232 board Ryko protocol/compatible controllers Fuel Price Sign... -
Page 8: Peripheral Access
If a shutdown is initiated, it is critical to wait for the shutdown to complete before removing the power cord. Shutdown is complete when the power and disk LEDs go out and the fan stops spinning. Firmware Download ANDI firmware downloads are completed via the Allied DGS utility. NeXGen Prime Page 8 of 9... -
Page 9: Using Dgs
4.1 Using DGS Follow the normal Allied DGS procedures, exactly as you would with a NXG or Aegis controllers. Sign on using Administrative credentials, navigate to the Utilities tab and click “Download,” then supply the location for the RTA file and the INI file. Configuration XML Files 5.1 INI files NexgenIni.xml has been deprecated.
