Barco MDU–268 Specifications

6x8 inch avionics-grade mission display unit.
Hide thumbs


Advertisement

Main features:
High-resolution 6 x 8 inch XGA screen (> 125 dpi)
Multiple configurable inputs:
1 Digital video input (DVI)
Up to 6 analog video inputs
Night vision compatibility (optional)
Unique state-of-the-art LED backlight
Extra wide viewing angle
Input resolution from VGA to XGA
Very compact design
Extensive Built-In Test (BIT)
RS422 external keyboard communication
Ambient luminance control
Compatible with Barco MOSArt
Configurable softkey legend via OSD
6x8 inch avionics-grade Mission Display Unit
TM
processing unit
The MDU-268 is an avionics-grade 6x8 inch Mission Display Unit
derived from Barco's field-proven CHDD family. The MDU-268
has both a digital video input (DVI) and most of the currently
available analog video inputs (Composite, RGB, STANAG,...).
Equipped with the latest, sunlight-readable AMLCD technology,
the MDU-268 delivers excellent brightness and contrast values,
as well as a wide viewing angle of 80° in all directions. It
allows the same unit to be used in portrait as well as landscape
mode.
The use of advanced electronics has enabled a very compact
footprint (maximum 4" depth) and low power consumption.
Because of this, the MDU-268 can be integrated in virtually any
cockpit or cabin environment.
Compatible with FLIR, daylight video cameras, moving maps,
computers and radar, the MDU-268 Display Unit offers a
dedicated imaging solution, wherever your mission takes you.
The unit is DO-178B and DO-254 certified up to level C for the
DVI input.
MDU–268

Advertisement

Table of Contents

   Also See for Barco MDU–268

   Related Manuals for Barco MDU–268

   Summary of Contents for Barco MDU–268

  • Page 1 The use of advanced electronics has enabled a very compact footprint (maximum 4” depth) and low power consumption. Because of this, the MDU-268 can be integrated in virtually any cockpit or cabin environment. Compatible with FLIR, daylight video cameras, moving maps, computers and radar, the MDU-268 Display Unit offers a dedicated imaging solution, wherever your mission takes you.
  • Page 2: Technical Specifications

    Automatic Light Control Keys: Programmable softkeys IMAGE PROCESSING Functionality: Picture-In-Picture (PIP), scaling, rotating, image dithering grayscale rendering 00.03 0607 © 2007 Barco Technical specifications are subject to change without prior notice www.barcoaerospace.com 90 mm / 3.54 inch INTERFACES Inputs: I/O: ENVIRONMENTAL Compliance:...
