Parts List - Drive RTL11158KDR Manual

6
3

parts list

1. Commode frame
2. Bucket frame
3. Legs (4)
4. Backrest
assembly instructions
1. Open commode frame (1) as shown below and place on
the floor.
7
5
1
4
2
5. Toilet seat
6. Cover
7. Pail & lid
2. Slide the hook on the bucket frame (2) over the
receptacle located on the back of the commode frame.
3. Secure bucket frame in place by inserting the front
cross brace into the receptacles located on the front of
the commode frame. The push buttons will "click" in
place when they are secure.
4. Turn the frame upside-down. Insert the legs (3) into
each receptacle by depressing the push pins and sliding
into place. The push buttons will "click" in place when
they are secure.
