Omnitracs Active Mobile
Gateway (AMG-C)
User Reference Manual
80-JE177-1 Rev. B
June 2019

Advertisement

loading
Need help?

Need help?

Do you have a question about the CV90-JE103 and is the answer not in the manual?

Questions and answers

Summary of Contents for Omnitracs CV90-JE103

  • Page 1 Omnitracs Active Mobile Gateway (AMG-C) User Reference Manual 80-JE177-1 Rev. B June 2019...
  • Page 2: Table Of Contents

    Contents 1. Product Overview ........................2 2. Product Feature Introduction ....................3 3. Interface Description ......................6 Front View ..........................6 Rear View ..........................7 4. Installation Instructions ......................8 Warning statement: ........................ 9 IC Statement: ........................10 80-JE177-1 Rev. B MAY CONTAIN U.S.
  • Page 3: Product Overview

    1. Product Overview Product name: ACTIVE MOBILE GATEWAY WITH COMM (AMG-C) Model No.: CV90-JE103 Brand: OMNITRACS The AMG-C system components include: • Power I/O cable • AMG-C hardware and fasteners 80-JE177-1 Rev. B MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...
  • Page 4: Product Feature Introduction

    2. Product Feature Introduction Network: • EVDO / CDMA / UMTS / LTE / GPS / GLONASS Body: • Dimensions: 165 x 95 x 32.5 mm • Weight: 375g • SIM Card: Non-Removable Dual SIM card slot (AT&T, Sprint) Platform: •...
  • Page 5 Comms: • WLAN: 2.4 GHz / 5GHz dual band IEEE802.11 a/b/g/n/ac Wave2 WLAN (Build in APP will be used for Wi-Fi feature set up and link up) 80-JE177-1 Rev. B MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...
  • Page 6 • Bluetooth: 4.2 BR/EDR/LE Battery: • 710 mAh polymer Li-ion backup battery (Not used as main power supply source) 80-JE177-1 Rev. B MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION...
  • Page 7: Interface Description

    3. Interface Description Front View • USB OTG Connector: This connector can be used for charging USB powered device and is able to transfer logging data. • Driver Notification LED: This RGB LED is used to provide notifications to drivers if there are any activity happens to the unit.
  • Page 8: Rear View

    Rear View • Main Power Connector: This connector is used to connect the power cable from vehicle battery power supply. • Expansion I/O Connector: This connector is used to connect the optional I/O expansion cable. The I/O expansion cable consist of a protected external 5V power supply, protected external vehicle battery power supply, Driver Notification &...
  • Page 9: Installation Instructions

    4. Installation Instructions Before starting the installation, inspect the vehicle to determine an installation location. DO locate the display where it: • Has a flat mounting surface that is strong enough to support the mounting hardware • Is clear of dash controls and gauges •...
  • Page 10: Warning Statement

    Warning statement: Class A Device FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a commercial installation.
  • Page 11: Ic Statement

    IC Statement: ICES-003 statement CAN ICES-3 (A)/NMB-3 (A) RSS-Gen statement Canada, Industry Canada (IC) Notices This device complies with Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 12 RSS-247 statement Caution: User should also be advised that: (i) the maximum antenna gain permitted for devices in the bands 5250-5350 MHz shall comply with the e.i.r.p. limit. High-power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350 MHz, 5470-5600 MHz and 5650-5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices.
  • Page 13 Dallas, TX 75201 U.S.A. © 2019 Omnitracs, LLC. All rights reserved. Omnitracs is a trademark of Omnitracs, LLC. All other trademarks are the property of their respective owners. Omnitracs endeavors to ensure that the information in this document is correct and fairly stated, but Omnitracs is not liable for any errors or omissions.
