- Page 1 INSTRUCTION MANUAL H4905A Hydraulic Sign Post Puller Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. Register this product at www.greenlee.com 99936755 REV 3 © 2010 Greenlee Textron Inc. 1/10...
-
Page 2: Table Of Contents
Authorized Greenlee Utility Service Centers Service Manual: Publication 99916045 All specifications are nominal and may change as design improvements occur. Greenlee Textron Inc. shall not be liable for damages resulting from misapplication or misuse of its products. KEEP THIS MANUAL Greenlee / A Textron Company 4455 Boeing Dr. -
Page 3: Important Safety Information
Failure to observe this warning could Wear hearing protection when using result in severe injury or death. this tool. Long-term exposure to high noise levels could result in hearing loss. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... - Page 4 64 kN (14,400 lb) minimum breaking strength injury or death. An underrated chain may break during operation. Failure to observe this warning could result in severe injury or death. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070...
- Page 5 Nearby personnel may be injured by flying or falling debris or by flying parts in the event of a tool malfunction. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070...
-
Page 6: Identification
3. Serrated Jaws 4. Cylinder 5. Handle 6. Guide 7. Serial Number 8. Bracket 9. Control Lever 10. Pressure (supply) Port 11. Tank (return) Port Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 7: Specifications
138 bar (2000 psi) at your tool’s maximum flow. Locate the pressure relief valve in the supply circuit to limit excessive hydraulic pressure to the tool. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 8: Hoses And Fittings
4. Disconnect the tank hose from the tool, and then from the hydraulic power source. 5. Install dust caps over the ports to prevent contamination. Typical Setup Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 9: Operation
Note: Maintain proper footing and balance while using the tool. Do not overreach. Unsuitable footing and balance may not allow counteracting normal or unex- pected movement of the tool. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 10: Maintenance
Greenlee Utility Authorized Service Center. Emergency stop procedure/power supply failure: 1. Release the control lever. 2. Shut off the hydraulic power source. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 11: Troubleshooting
Use hydraulic fluid with the correct viscosity. Hydraulic fluid dirty. Refer to the power source owner’s manual for procedure to replace hydraulic oil and filter. Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 12: Illustration And Parts List
H4905A Hydraulic Sign Post Puller Illustration Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... - Page 13 Washer, flat, .265 x .734 x .059" .....2 43836 50438360 Spacer, .271 x .437 x .656" ....1 41663 50416631 Spring, compression, .576 x .720 x 1.75" .........1 Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070...
- Page 14 800-435-0786 Fax: 800-451-2632 815-397-7070 Fax: 815-397-1865 Canada 800-435-0786 Fax: 800-524-2853 International +1-815-397-7070 Fax: +1-815-397-9247 4455 Boeing Drive • Rockford, IL 61109-2988 • USA • 815-397-7070 • An ISO 9001 Company Greenlee Textron Inc. is a subsidiary of Textron Inc. www.greenlee.com...
