Summary of Contents for Showa Denki WINDBAG
- Page 1 ０３２１（Ｅ）－Ａ WINDBAG Operating Instruction Manual Caution List...
-
Page 2: Table Of Contents
Thank you for purchasing a Showa Denki WINDBAG. This operating instruction manual contains operating instructions and cautions for【WINDBAG】. In order to use the WINDBAG『safely』and『efficiently』,please read these instructions and cautions【particularly those marked 】 thoroughly. Keep this manual carefully where it can be referred to when necessary. -
Page 3: How To Read This Operating Instruction Manual/ Cautions List
WARNING Do not expose to water. The WINDBAG is not water-/drip-proof. Do not splash water on the product or expose to rain. Water can damage the motor and cause rusting - 1 -... - Page 4 WARNING Do not disassemble. Do not use after removing any parts. Disassembly by an unauthorized or untrained person will lead not only to possibly decreased performance, but also an accident or injury. WARNING •Do not operate near flammable air nor an area with high temperatures (over 40℃).
- Page 5 CAUTION To prevent electric shock, make sure to use the ground wire. When removing the electrical plug, do not touch any conductive parts. CAUTION If the motor operation suddenly stops, proceed according to the following instructions. ①Turn off the power source. ②Confirm wire connections and remove any garbage and dust from the intake side.
- Page 6 CAUTION •Please stay aware of your surroundings and avoid any dangers. Keep children away. •Place and use the product on a stable and horizontal surface. •Do not use in areas with dusts or chips. CAUTION •Be sure to connect to a power supply with an appropriate capacity. •Cord extension is not recommended.
-
Page 7: Inspection When Unpacking
Inspection when unpacking The units are shipped after careful inspection; however, be sure to check the following points regarding your purchased WINDBAG. ・Is the product the one you ordered? ・Did any abnormalities such as breakage or deformation occur during transportation? ・Are any accessories omitted? -
Page 8: Name Of Each Parts
6. Name of each parts Shoulder belt (sold separately) Cord clamp Shoulder belt (sold separately) Cord stopper mounting bracket Exhaust guard Exhaust port Electrical plug Suction port Shoulder belt (sold separately) mounting bracket Side Top part Casing Warning label Product nameplate Switch Handle Stand... -
Page 9: Indication Label Details And Attachment Position
7. Indication label details and attachment position (1) Model plate Displays the product classification, rated voltage, rated frequency, rated current, insulation class, maximum static pressure, maximum blow volume, product model, etc. Note 1: “Rated” means operating limits. (2) Warning/Caution label For safe machine use, the label indicates the most important content and the wind discharge direction. -
Page 10: Application
9. Application •Drying a floor after cleaning with a water or wax. •Indoor concrete curing. •As a ventilation fan for bad smells. •As a circulation fan. •Various cooling and drying purposes. 10. How to use ① Place the machine suitably for your use. ②When using the shoulder belt (sold separately), be sure to remove it before using. -
Page 11: Maintenance Inspection
Follow the instructions below when storing or turning off the machine. • Store indoor where there is little temperature change and little warmth. • While the WINDBAG is stopped, make sure it is unaffected by vibration or heat from another machine. -
Page 12: Warranty
12. Warranty (1) Scope of warranty When a malfunction occurs even if operating the unit according to the instruction manual and the cautions on the attachment labels, etc. within the warranty period, we will repair the failure for free. However, if this unit is assembled into the customers other equipment, expenses for removal from the equipment and attachment to the equipment, accompanying work expenses, transportation costs, and other indirect damages cost such as opportunity loss or operational loss of customers are... -
Page 13: Contact Information
13. Contact Information (1) Contact the following department regarding specifications and technical questions. To: Showa Denki Co., Ltd., Daito Factory. Tel: +81-72-870-5708 Fax: +81-72-870-7243 (2) If the unit malfunctions or requires repair, contact our nearest branch or sales on the back cover. At that time, inform us of the type and manufacturing (No.) on the name plate. - Page 14 Memo...
- Page 15 Memo...
