- Page 1 F30-ATS 30amp 125V Automatic Transfer Switch Furrions ATS is used to safely switch automatically between mutiple power sources...
-
Page 2: Installation
120 volt AC power sources, these power sources can be from a generator, shore power cord or inverter. The function of the 30amp Furrion Automatic Transfer Switch is to provide a safe and smooth switch over from an inverter or shore power cord automatically when a generator is started... - Page 3 INSTALLING YOUR F30-ATS: There are 3 common installation configurations for the Furrion ATS series: Configuration 1: Double power feed This is the standard installation used between a shore power cord and generator. EXAMPLE. 1 DISTRIBUTION PANEL / BRANCH CIRCUITS Typical RV Wiring Layout...
- Page 4 POWER INVERTER Transfer switch MAX 3000W Input 1 Input 2 DISTRIBUTION PANEL 1 GENERATOR SHORE POWER CORD 30Amp 125 VAC 3.75KW Generator 30Amp 125 VAC 3.75KW FURRION PULL SMART PLUG FEATURED BELOW Output feed F50-ATS Transfer switch Input 2 Input 1...
- Page 5 1 x Philips screw driver #2 MOUNTING YOUR F30-ATS: The Furrion ATS is best mounted indoors or in a location sheltered from outdoor elements. The selected area must be free from the possibility of contaminates and away from water pipes, pumps, battery compartments and storage areas for flammable liquids.
- Page 6 Strip 4” of outer jacket from each of the incoming cables. Strip 3/8” of jacket from each of the wire conductors. Using the copper spade terminals which are supplied on the terminals of the F30-ATS relay, crimp these to the ends on the incoming cables.
- Page 7 PLEASE READ THE FOLLOWING SAFETY INSTRUCTIONS... Follow the below steps to test the function of the F30-ATS. BEFORE TESTING Ensure air conditioning units and other high current users are switched off. It is harmful for the transfer switch to switch over power sources while under load.
- Page 8 ATS SWITCHING TESTING: To test the switching function after both function tests have passed: 1. Turn on the shore cord shore side breaker to engage the shower power contactor, power is now being supplied to the RV by the shore power. 2a.Start the generator and wait for it to warm up, after 20-30 seconds you will hear a click as the unit automatically switches over power sources from shore power to generator.
- Page 9 TROUBLESHOOTING YOUR F30-ATS: In the event of a problem with your F30-ATS, contact a qualified electrician for advice. COMMON PROBLEMS: Transfer switch will not switch over from Shore Power to Generator feed. Possible cause: Bad PCB. How to check: Open the transfer Switch lid so the PCB in visible, do not put your hands or touch anything parts inside the box.
- Page 10 Mounting the Furrion F30-ATS: Using the external lugs which are located on the outside of the box. Mounting dimensions for the external lugs are: Outer Lugs : 139 x 182mm (5 / x 11 / ) 187.33 34.5 76.5 136.5...
- Page 12 Furrion Innovation Center & Institute of Technology ● 52567 Independence Ct., Elkhart, IN 46514, USA ● Toll free:1-888-354-5792 ● Email: info@furrion.com ©2007-2018 Furrion Ltd. Furrion® and the Furrion logo are trademarks licensed for use by Furrion Ltd. and registered in the U.S. and other countries. FURRION.COM...
