ASSEMBLY INSTRUCTIONS
ROUND STYLE 30x30x15
Please read instructions completely before you
begin. This will help attain the best results for your
installation.
CONGRATULATIONS!
Congratulations on your purchase of a Rhino Shelter
30x30x15 Round Style Portable Building. With proper
installation, use and maintenance, your new unit will
provide many years of good and suitable service. Your
new Rhino Shelter portable enclosure is a combination
of excellent engineering and well thought out design.
The unit is comprised of a rigid tubular frame, covered
with a long life polyethylene cover and double door ends.
The multiple part frame assembly is pre-drilled for easy
insertion of frame bolts. The tubing is made from high-
grade galvanized steel., resisting moisture and oxidation
over the life of the shelter. The cover and doors are
made from ASTM-5 approved polyethylene materials.
The cover is UV protected for exposure to sunlight.
SAFETY WARNING
The installation of this unit must conform to the
requirements of all authorities having jurisdiction in
your specific local area. In the absence of such
requirements, the assembly and installation must
conform to the provided assembly and installation
instructions. Rhino Shelter will not responsible for
failure to comply with any requirements in a given
local area. Damages, consequential damages, or
injuries caused by improper installation, alteration,
improper use, or damages caused by snow, wind, or
any acts of nature are strictly that of the user. Unit is
not intended for occupancy for any length of time.
NO running of internal combustion engines, open
flames or contact with heated surfaces is allowed.
For installation assistance or Customer Service, please
call 800-447-7079 or 203-877-7070, 8AM-5PM EST.
Cartons should be inspected upon delivery from carrier,
and any evident damages should be noted on the bill of
lading before signing. If upon opening the cartons hidden
damage is discovered, contact carrier or it's agent
immediately. Claims for shipping damage MUST be
made with the shipping company. An inspection of the
goods will most likely be required. Do not discard
Version 2.3
Please DO NOT return unit to store or dealer. For all questions or shortages please contact
Assembly Instructions 30x30x15 Round Style Portable Building
Customer Service at: 800-447-7079 or 203-877-7070
packing or any components before the freight company
inspection. All claims for freight damage must be made
within 15 days of receipt of the goods in accordance with
ICC regulations.
ASSEMBLY PROCEDURE
The proper sequence and steps to install this unit will
produce a proper and good installation. Failure to read
and follow these guidelines may result in an improper
installation and will void all warranty and protection the
owner is entitled to with the product. The steps to be
undertaken are:
1. Perform an inventory check before beginning, to
be certain all components are available for
installation.
2. Prepare location and place all unit boxes near
location sight.
3. Assemble Seven (7) Arch Assemblies of unit.
4. Assemble unit End Arch, first Interior Arch, and
Wind Braces with the first ridge crest, base, and
side rail sections.
5. Add additional Arch Assemblies with each
section of base rails and side rails.
6. Level and square Frame of Unit.
7. Anchor frame assembly to ground with provided
anchors, U-bolts and drive rod.
8. Install Doors (2) on ends of frame assembly.
9. Install Main Cover over frame assembly.
10. Install Door Roll-up kits
TOOLS REQUIRED
The following hand tools will be needed for proper
installation of your new Rhino Shelter building:
9/16 Open End Wrench
9/16 Socket or Box Wrench
Large Flat Head Screwdriver
2lb maul or Sledgehammer
2 Foot Level
12' Step Ladder
Stakes & String for squaring Frame
INVENTORY CHECK
Start installation procedure by removing all components
from packaging to ensure all components are present.
Inventory chart appears on the last page of this manual.
1
