ASSEMBLY INSTRUCTIONS
ROUND STYLE GREENHOUSE
12Wx24Lx8H
Congratulations!
Congratulations on your purchase of a Round Extended
Style Greenhouse by MDM Products LLC. With proper
installation, use, and maintenance, your new unit will
provide many years of good and suitable service. Your
new Rhino Shelter greenhouse is a combination of
excellent engineering and well thought out design. The
unit is comprised of a rigid tubular frame, covered with a
long life polyethylene cover and double door ends.
The multiple part frame is pre-drilled for easy insertion of
hardware to assemble. The tubing is made from high-
grade galvanized steel tubing, to resist moisture and
oxidation over the life of the shelter. The covering
membrane is made from ASTM-5 approved polyethylene
materials. The cover is UV protected for continual
exposure to the sunlight.
It is suggested that you read the assembly instructions
completely before you begin. This will help attain the
best results for your installation the first time.
SAFETY & CODE WARNING
The installation of this unit must conform to the
requirements of all authorities having jurisdiction in
your specific local area. In the absence of such
requirements, the installation must conform to the
provided assembly and installation instructions.
MDM Products LLC will not be responsible for failure
to comply with any requirements in a given local
area. Consequential damages or injuries caused by
improper installation, alteration, or improper use are
strictly that of the user. Unit MUST be cleared of All
Snow Accumulation immediately to avoid overload.
Unit is not to be used for occupancy for any length
of time. No running internal combustion engines,
open flames, or contact with heated surfaces are
allowed.
For installation assistance or Customer Service, please
call 800-447-7079 or 203-877-7070, 8AM-5PM EST.
Cartons should be inspected upon delivery from carrier,
and any evident damages should be noted on the bill of
lading before signing. If upon opening the cartons
hidden damage is noted, contact carrier or its agent
immediately. Claims for shipping damage MUST be
made with the shipping company. An inspection of the
V1
Please Do NOT Return Assembly to Dealer or Store. For All questions or Shortages please call MDM Products directly
Assembly Instructions Greenhouse Round Style 12 x 24 x 8
Customer Service 800-447-7079 or 203-877-7070
goods will most likely be required. Do not discard
packing or any components before the freight company's
inspection. All claims for freight damage must be made
with 15 days of receipt of the goods in accordance with
ICC regulations.
ASSEMBLY PROCEDURE
The proper sequence and steps to install this unit will
produce a proper and good installation. Failure to read
and follow these guidelines may result in an improper
installation and will void all warranty and protection the
owner is entitled to with the product. The steps to be
undertaken are:
1. Perform an inventory check before beginning to be
certain all components are available for installation.
2. Prepare location and place both unit boxes near
location sight.
3. Assemble seven (7) frame arches of unit
4. Assemble unit end arch, first interior arch, and Wind
Braces with first base rails and side rail sections.
5. Add additional arch assemblies with each section of
base rails and side rails.
6. Place frame into desired position and level frame
both end-to-end and side-to-side. Measure interior
of frame feet across opposite corners and square
7. Anchor frame assembly to ground with provided
anchors, u-bolts and drive rod provided.
8. Install two(2) doors on both ends of frame assembly.
9. Install main cover over frame assembly.
TOOLS REQUIRED
The following hand tools will be needed for proper
installation of your new Rhino Shelter unit:
9/16" Open End Wrench
9/16" Socket or Box Wrench
Large Flat Tip Screwdriver
Maul or Sledgehammer
2 foot Level
6-Foot Step Ladder
INVENTORY CHECK
Start installation procedure by removing all components
from packaging and ensure all components are present
Qty No. Part Number
1 RUC-10000
2 DZD-5002
4 1 EUL-4021
Description
Main Unit Cover
–
122408RSK
End Panel Door with
Double Zippers
End Upright w/Foot
