Operating Instructions
Bottle rinsing machine GS 21
NOW NEW
WTH RINSER
FUNCTION
Inventor of the bottle
washing machine with
the smart bottle basket
Installation, First commissioning
Rinsing
Emptying the machine, Internal cleaning
Possible Troubleshooting / Decalcification Page
Wiring diagram
Technical data
Bottle basket (Assembly)
Setting the rinsing nozzles
Please read all of the Operating Instructions
before using the machine
Technical changes reserved
Edition: November 2020
Erich Baumgartner
Gastronomiemaschinengroßhandel
Hauptstraße 4
A - 5222 Munderfing
Phone: 0043 / (0)664 / 18 16 5 18
Fax: 0043 / 7744 / 20 12 12
E-mail:
erich@gastrohandel.at
Page
Page
Page
Page
Page
Page
Page
2 - 3
3 - 4
5 - 6
7
8 - 10
11
12 - 16
17 - 18
Advertisement
Related Manuals for ebatec GS 21
Summary of Contents for ebatec GS 21
- Page 1 Operating Instructions Bottle rinsing machine GS 21 Edition: November 2020 NOW NEW WTH RINSER Erich Baumgartner Gastronomiemaschinengroßhandel FUNCTION Hauptstraße 4 A - 5222 Munderfing Phone: 0043 / (0)664 / 18 16 5 18 Fax: 0043 / 7744 / 20 12 12 E-mail: erich@gastrohandel.at...
- Page 2 Installation and Connection of the Machine The machine is equipped with the following accessories: - Power supply 5 x 2.5 mm² connected to the rinsing machine - Supply hose with matching connectors and joints - Draining hose, 1 bottle carrier basket, 1 carrier for crates, 1 template - The following conditions described on the installation plan would be necessary - The water outlet should not be higher than 60 mm from the machine base (refer to the illustration)
- Page 3 Assemble the bottle basket, after having correctly installed and connected the machine Refer to the instructions on page 12 to 16. Then, adjust the rinsing nozzles. Refer to the instructions on page 17 to 18. First commissioning Remove the panel below the door, by unscrewing the 2 screws on the left and right.
- Page 4 Close the door and press the mains switch (1) The green indicator light (3) is illuminated. Switch Continuous rinsing (7) Main switch (1) Button Washing program (2) Button Rinsing (8) Rinsing Temperature (4) Permanent washing (9) Indicator light Washing cycle (5) Main switch (3) The automatic filling of the tank is performed via the inlet valve, the pressure increase pump and via the rinsing system.
- Page 5 Emptying the Machine Press the mains switch (1). The control lamp is switched off. Open the door, take out the basket with the clean bottles or the crate (if there is a basket in the machine), pull out the overflow pipe the rinse water will automatically drain out of the tank. Make sure that the water drains at even amounts and rapidly out of the tank.
- Page 6 Take off the pump filter and the surface filter and rinse them under flowing water. Take out the rinsing arms by slightly turning them to the left. To perform the cleaning, it is recommended to place the beer crates on the crate carrier included in the delivery.
- Page 7 Possible Troubleshooting / Decalcification Malfunction Possible cause / Remedy It is not possible to switch on the The power supply to the machine is machine interrupted, cause within the machine, Contact the after-sales service The machine is not being filled with The check valve provided by the water customer is closed, the air trap is soiled –...
- Page 8 Page 8...
- Page 9 Page 9...
- Page 10 Electric diagram Manual flushing MOD: GS-21 III AB of the machine No. Switch Commissioning Micro door Switch Push button Manual rinsing Button manual rinsing Motor capacitor Heater protection water heater Heater protection tank Contactor heating Relay micro door Pump capacitor rinsing Manual rinsing relay Program switch Thermostat temperature controller tank...
- Page 11 Technical data: Hourly output about 190 bottles/h Rinsing time: 6 min 30 sec. Pump capacity: 736 W Circulation rate: 330 ltr. / min. Tank heater: 2 x 4500 W Overall connected load: 9736 W Voltage: 400 Volt Tank contents: 29 ltr. Water consumption/rinsing cycle: about 8,7 ltr.
- Page 12 Bottle Basket The system of our bottle basket suits/fits almost all types of bottles. No matter if you need to rinse NRW, long necked, NF or flip-top bottles, wine bottles, juice bottles, milk bottles, yoghurt jar, and much more. Scope of delivery: 1 pcs Basic basket 8 pcs...
- Page 13 Assembly of the bottle basket Put the template on the table and put the bottle basket over the template. Attention: The template is marked with the word FRONT Also mark the basket with a cable tie or the like. The basket is square, but it only has one correct front.
- Page 14 Mount the support rail at different heights depending on the bottle type or bottle neck. Also check how many bottles can be used in the bottle basket depending on the type or size of the bottle. Also the number of the transversally mounted support bars would change depending on the number of bottles.
- Page 15 Then inset the support bars into the support rails from the front to the rear. Max. 8 pcs for 4 rows of bottles. Also position them above the recesses of the template. Always check the exact position of the bottle mouth with the recess of the template.
- Page 16 First mount the support rails, as for the bottom level. Here too, make sure that the support rails need to be mounted at the same height and the lateral support rails need to be mounted by one hole to the bottom on the basket frame. Then place the support bars from the left to the right as well as from the front to the rear on the support rails.
- Page 17 Setting the rinsing nozzles Condition of the machine: The machine is switched off. The tank is empty. Open the door and remove the surface filter as well as the overflow pipe from the machine. Remove the upper rinsing arm by turning the grey plastic nut. Insert the Allen screw included in the delivery into the thread;...
- Page 18 The door remains open. Press the main switch (1) The green indicator light (3) is illuminated. Switch Continuous rinsing (7) Main switch (1) Button Washing program (2) Button Rinsing (8) Rinsing Temperature (4) Permanent washing (9) Indicator light Washing cycle (5) Main switch (3) Take the magnet which is included in the delivery and insert...
