Bakers Pride PDC Specifications

Pretzel display cabinet

Advertisement

Quick Links

PRETZEL DISPLAY
BAKERS
PRIDE
SPECIFICATIONS
The PDC Pretzel Display Cabinet features tempered clear glass on
all three sides and a clear Plexiglass hinged door making the
cabinet an attractive merchandising and display product.
The PDC features an electric powered, revolving stainless steel
pretzel tree with three tiers and four arms per tier. A 120V light, 6
foot cord and NEMA 5-15P plug are standard features. 240V Model
with 6 foot cord and without plug is available.
The exterior front, sides, top and bottom are fabricated of stainless
steel. Overall dimensions are 25 7/8" (657mm) tall by 14 13/16"
(376mm) wide by 14 13/16" (376mm) deep. Overall depth with
door open is 19 5/8" (752mm).
Interior dimension from floor to ceiling is 20 1/4" (514mm) high.
Standard colored graphics are provided.
1-Year limited parts and labor warranty included.
BAKERS PRIDE OVEN COMPANY, INC.
30 Pine Street, New Rochelle, NY 10801
BAKERS
914/576-0200 • 1-800-431-2745 • fax 914/576-0605
PRIDE
PDC SERIES
CABINET
Model PDC
Job ____________
HEATED DISPLAY CABINETS
Model PDC
q
STANDARD FEATURES
120V, 2 Amps or 240V, .94 Amps
q
120V with 6 foot cord and NEMA 15-5P plug
q
240V with 6 foot cord without plug
q
Electric, revolving pretzel tree
q
Interior light
q
All stainless steel exterior
q
Tempered clear glass on three sides
q
Clear Plexiglass hinged door
q
Limited 1-year parts & labor warranty
q
OPTIONS & ACCESSORIES
Tough, colored acrylic enamel finish in lieu of stainless steel
q
Two tier pretzel tree in lieu of three tier pretzel tree
q
Custom graphics
q
CERTIFICATIONS
®
Continuous product improvement is a policy of Bakers Pride Oven Company.
Therefore, specifications and design are subject to change without notification
Item # ___________
U L
®

Advertisement

loading
Need help?

Need help?

Do you have a question about the PDC and is the answer not in the manual?

Questions and answers

Summary of Contents for Bakers Pride PDC

  • Page 1 PRIDE Model PDC SPECIFICATIONS The PDC Pretzel Display Cabinet features tempered clear glass on all three sides and a clear Plexiglass hinged door making the cabinet an attractive merchandising and display product. The PDC features an electric powered, revolving stainless steel pretzel tree with three tiers and four arms per tier.
  • Page 2 WATTS Model Height Cubic Cubic Inches Feet Meter Height 14 13/16" (376mm) SIDE VIEW VOLTAGE PHASE AMPS 2.00 Continuous product improvement is a policy of Bakers Pride Oven Company. Therefore, specifications and design are subject to change without notification TS:10/00...
