- Page 1 -Montage- und Betriebsanleitung STÜTZVORRICHTUNG MODUL Installation and operating instructions for the L ANDING GEAR MODUL Instructions de montage et d´utilisation pour T ÉLESCOPIQUE MODUL Istruzioni per il montaggio e l’uso del TE LESCOPICO MODUL Instrucciones de montaje y funcionamiento para el TELESCÓPICO MODUL...
-
Page 2: Table Of Contents
Foreword Table of contents Page This landing gear is not an independent, functional unit. It is designed for 1 Safety information mounting on a semi-trailer. Safety information for operation It must not be used until such time as it has been established that the trailer Safety information for servicing with the landing gear conforms to the national regulations for road trans- Safety information for installation... -
Page 3: Servicing
Safety informations The following safety information must be observed for the operation, ser- Do not use the trailer if the landing gear is damaged, if necessary mend the landing gear or remove it. vicing, assembly and repair of the landing gear. The safety information for There must be nobody under the trailer when coupling and uncou- the tractor vehicle and the trailer vehicle are also applicable. -
Page 4: Proper Usage
The landing gear can be used for laden and unladen trailers. In addition a supported trailer can be loaded, observing the appropriate Low gear (3): For lifting and lowering the laden or unladen trailer safety information. vehicle. Any other use requires the written approval of JOST-Werke. -
Page 5: To Uncouple The Semi-Trailer
Operation Gear change Change from high gear into low gear before the foot touches the High gear (2): Take the crank out of the parking hook and pull it ground. out until the gear engages. A slight rotary motion Uncouple the tractor vehicle (see manuals for tractor and trailer) will facilitate the gear change. -
Page 6: Cleaning
Turn the spindle in and out as far as it will go and then back in again. Seal the lubrication hole again with the sealing stopper (1). Only use the genuine JOST part JS E0084000 when using a grease nipple. -
Page 7: Disposal Instructions For Lubricant
Servicing Troubleshooting Disposal instructions for lubricant Fault Cause Remedy The disposal instructions for used lubricants are supplied by the lubricant manufacturer. Connection shaft too long Reduce the length of the connection The landing gear BP JS 14-2 / Renolit LZR 2H special grease shaft cannot be extended Spindle or gear defective... -
Page 8: Technical Data
Technical data 1495 Order No. 1470 Module B 01 01 900 mm 560 mm 630 mm Module B 02 01 850 mm 520 mm 580 mm Module B 03 01 800 mm 470 mm 530 mm Module B 04 01... - Page 9 Technical data Installation 190 Nm 190 Nm min 45˚ min 45˚ 190 Nm Made in Germany / Neu-Isenburg JSK-ST/27 JSK-ST/28 During the installation work ensure that when you extend the landing gear, both landing gear legs touch the ground at the same time. If the legs are exposed to different loads, damage will ensue.
- Page 10 Siemensstraße 2, D-63263 Neu Isenburg, Telefon (0 61 02) 2 95-0 Fax (0 61 02) 2 95-98 www.jost-world.com ZDE 199 006 052 05/2005...
