- Page 1 EcoAdvance Compact EcoAdvance Compact INSTALLATION & USER MANUAL Save this manual with the interface unit...
- Page 2 EcoAdvance Compact Symbols WARNING, general warning WARNING, electricity, chance of shock or injury WARNING, hot surface, chance of burns Important 230 V Alternating current 230 V Dispose of part Recycle if possible Open-ended spanner Torx-screwdriver Torx Electric drill Manual processing...
-
Page 3: Table Of Contents
EcoAdvance Compact Inhoud Overview of components Hydraulic scheme User manual Installation conditions Maintenance and inspection Technische specificaties Heat exchanger 40 plates Delivery range Additional items required Dimensions Installation Room thermostat (optional) Commisioning Cover sealing Errors (end user) Errors (installer) Guarantee... -
Page 4: Overview Of Components
EcoAdvance Compact Overview of components 1 Rear cover 10 Temperature sensor district heating network 2 Domestic water control valve 11 CH control valve 3 230V power adaptor 12 Temperature sensor district heating network 4 Heat exchanger supply 5 Differential pressure regulator impulse line... -
Page 5: Hydraulic Scheme
EcoAdvance Compact Hydraulic scheme... -
Page 6: User Manual
EcoAdvance Compact User manual INTRODUCTION This manual covers the installation of the heat interface unit and the relative applicable instructions. These must be followed to ensure the proper and trouble-free operation of the heat interface unit. You will also find general technical details and information about maintenance, any errors occurring and their possible causes. -
Page 7: Installation Conditions
EcoAdvance Compact Hot domestic water The interface unit features a double wall heat exchanger which transfers the heat supplied by the district heating network to the domestic water supply. Electronic control together with an electronic control valve and a flow sensor in the interface unit ensure a domestic water temperature of approx. 55 ºC. The interface unit has a low tapping threshold of 1 l/min. -
Page 8: Maintenance And Inspection
EcoAdvance Compact Maintenance and inspection For proper operation of the interface unit it is advised to have the following points inspected and maintained at least once every 24 months on the interface unit. Ask your heat supplier or your installer about the options for service and inspection. -
Page 9: Technische Specificaties
EcoAdvance Compact Technische specificaties Types and specifications Domestic Hot Water Domestic hot water temperature °C Nominal flowrate litre/min Nominal power (at 10°C - 55°C) Pressure loss at nominal flowrate Pressure class design PN10 Maximal working pressure Minimal hot water draw off... -
Page 10: Heat Exchanger 40 Plates
EcoAdvance Compact Heat exchanger 40 plates Hot domestic water temperature =55 °C old domestic water temperature = 10 °C Pressure drop tapping side over interface unit Pressure drop tapping side Power [kW] Domestic water flow [litres/minute] District heating network return temperature 30.0... - Page 11 EcoAdvance Compact Pressure drop district heating network over interface unit District heating network = 65°C District heating network = 70°C District heating network = 80°C Power [kW] Domestic water flow [litres/minute] District heating network flow 20.0 17.5 15.0 12.5 10.0...
-
Page 12: Delivery Range
EcoAdvance Compact HSF EcoAdvance Compact HSF EcoAdvance Compact HSF EcoAdvance Compact Leveromvang Leveromvang Leveromvang Delivery range Benodigdheden Additional items required Benodigdheden 14, 22, 14, 22, 14, 22, 24, 30 mm Torx 25 230 V 24, 30 mm 24, 30 mm... -
Page 13: Installation
HSF EcoAdvance Compact EcoAdvance Compact Installatie Installation 1. Warmtedistributienet aanvoer. 1. District heating return 2. Warmtedistributienet retour. 2. District heating supply 3. Warm tapwater 3. Domestic cold water 4. Koud tapwater 4. Domestic hot water 5. CV aanvoer 5. CH supply 6. - Page 14 EcoAdvance Compact 30 mm...
- Page 15 EcoAdvance Compact Option 1 22 mm 14 mm option 1 option 2 Option 2 22 mm 30 mm 24 mm ?? mm Note! Spool piece must be removed and replaced by heat meter or steel spool piece (Art Nº 44452). Contact your...
- Page 16 EcoAdvance Compact 30 mm option 1 option 2 Connection: Connection: ½" BN M10 x 1 BN...
-
Page 17: Room Thermostat (Optional)
EcoAdvance Compact Room thermostat (optional) Connecting the room thermostat: Remove the conductor. (only when a thermostat is used) Connect the room thermostat cable, with an isolated conductor*, to the room thermostat. sold separately CAUTION! The unit can (optionally) be connected to a room thermostat. For eligable types of thermostats see chapter... -
Page 18: Commisioning
EcoAdvance Compact Commisioning Follow the steps below to start up the unit. If there are leaks or other defects we refer you to the ERRORS section. NOTE! Exercise caution when handling the unit. Components can be hot or electrically charged. Contact can result in injury. -
Page 19: Cover Sealing
EcoAdvance Compact Cover sealing torx 25... -
Page 20: Errors (End User)
EcoAdvance Compact Errors (end user) STATUS INDICATION LED LIGHT Flashing green : Interface unit is in normal position (rest or CH position) Flashing blue : Interface unit is in hot domestic water position Flashing red : Interface unit failure Continuously white... -
Page 21: Errors (Installer)
EcoAdvance Compact Errors (installer) Complaint LED indicator light Cause Solution Leak (Immediately close all valves on the pre-fix bracket under the interface unit and the drinking water main valve!) Leak at connection nut Gasket leaking Tighten nut and check gasket... -
Page 22: Guarantee
15 December 2004 on the approximation of the laws of the Member States relating to electromagnetic compatibility and repealing Directive 89/336/EE 3) EC Declaration of Conformity Number: EC281 4) Equipment or protective system: Electronic DHW system, Model: EcoAdvance Compact 5) Manufacturer: HSF B.V. 6) Address: Marketing 23, Duiven, The Netherlands 7) This equipment or protective system and any acceptable variation thereto is specified in the schedule to this declaration and the documents therein referred to. - Page 23 EcoAdvance Compact...
- Page 24 EcoAdvance Compact...
- Page 25 EcoAdvance Compact...
- Page 26 EcoAdvance Compact...
- Page 27 EcoAdvance Compact...
- Page 28 EcoAdvance Compact...
