Opening The Stroller - Chelino APACHE TRAVEL SYSTEM Manual

(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
1. PEEP WINDOW
2.CANOPY
3. EASY FOLD MECHANISM
4. FRONT BABY TRAY
5. LATCH
OPENING AND ASSEMBLING INSTRUCTIONS

OPENING THE STROLLER

1、
• FIRST CHECK WHETHER YOUR STROLLER IS EQUIPPED WITH A LATCH,
WHICH HOLDS THE STROLLER'S FRAME TOGETHER.
• LIFT THE HANDLE BAR AS SHOWN IN FIG 1A, UNTIL THE TOP
AND BOTTOM PART OF THE FRAME LOCKS INTO ONE ANOTHER.
(SEE FIG.1B)
• IF YOUR STROLLER IS EQUIPPED WITH A SECOND SAFETY
LOCK, PLEASE ENGAGE IT NOW.
6. BACKREST ADJUST SYSTEM
7.BASKET
8. REAR WHEEL
9. BRAKE PEDAL
10. FRONT WHEEL
3-8
