TrueRMSMultímetro
5-10.Prueba de Diodo
1. Ajuste el selector de función a la
posición verde deΩCAP
2. Pulsela tecla delMenú.Mueva el selector
delmenú a la opciónDiodo.Pulsela
tecla deDiodo.
3.Inserteelcablede prueba negroen el
conector negativoCOM.Inserteelcable de
prueba r o j o en la entrada positiva 5.El
siguiente voltajeindicará de 0.400
a3.200V.El voltajeinverso indicará
"OL ".Dispositivos en corto indicarán cerca
de 0V y uno abierto indicará "OL"
en ambas polaridades.
18
.
VΩCAP
Temp Hz
%
Bluetooth
CATIII600V
