Software introduction

1. Aelos educational software is based on Blockly programming. You can build a program with drag-and-drop
graphical objects, each of which is a code block that can be assembled to perform simple functions, which are
then combined to build a program.
Command Bar
Coding Area
12
Menu Bar Serial Port
Action View Area
Servo Motor View Area
2. Click on the 'serial port' in the upper right corner, and select the serial port to be
connected in the drop-down menu. When the robot is successfully connected, "Serial
port has been opened" will pop up
3. Click "New" on menu bar, select the save path, select the application class in the
command bar, drag the block with the mouse to the editing area, and proceed with
programming. (Note: When launching the software, it defaults to creating a new
Aelos EDU project with 'sp' format. If you want to create a project in another format,
you need to create a new project and re-select the corresponding hardware.).
