Livestock Tent
SSL202012H 20'x20'x12'
W6.0xL6.0xH3.7m
Assembly Instructions
RECOMMENDED TOOLS
Please read instructions COMPLETELY before assembly. This shelter MUST be securely anchored.
THIS IS A TEMPORARY STRUCTURE AND NOT RECOMMENDED AS A PERMANENT STRUCTURE.
Before you start: 4+ individual recommended for assembly, approximate time 5 hr.
Page 1
Advertisement
Related Manuals for East Cover SSL202012H
Summary of Contents for East Cover SSL202012H
- Page 1 Livestock Tent SSL202012H 20’x20’x12’ W6.0xL6.0xH3.7m Assembly Instructions RECOMMENDED TOOLS Please read instructions COMPLETELY before assembly. This shelter MUST be securely anchored. THIS IS A TEMPORARY STRUCTURE AND NOT RECOMMENDED AS A PERMANENT STRUCTURE. Before you start: 4+ individual recommended for assembly, approximate time 5 hr.
- Page 2 ATTENTION: This shelter product is manufactured with quality materials. It is designed to fit our custom fabric cover included. Our shelters offer storage and protection from damage caused by sun, light rain, tree sap, animal - bird excrement and light snow. Please anchor this structure properly.
- Page 3 Livestock Tent SSL202012H (W6.0xL6.0xH3.7m) Parts List Part Qty/ Description Code Top Bent Joist Roof Bent Joist Sidewall Bent Joist Upright for front and back end (left) Upright for front and back end (right) Upright for middle arch Purlin Portal for front end Portal for back end Portal for front end with hole for No.11...
- Page 4 Base Plate for corners Base Plate for middle arch Base Plate for front and back end Stake Peg Roof Cover Front Cover Back Cover Webbing for Winch Tensioning Tube for roof cover 2 sets (3pcs/set) Knitting Rope for roof cover 1 bundle Plastic Plug for No.24 Carriage Bolt M10x80 for purlins...
-
Page 5: Frame Installation
Frame Installation Step 1: base plates and stake pegs Page 5... - Page 6 Step 2: arch No.1 and portals and fences Page 6...
- Page 7 Step 3: middle arches No.2 & 3 Page 7...
- Page 8 Step 4: arch No.4 and portals and fences Page 8...
- Page 9 Step 5: purlins and sidewall fences Page 9...
- Page 10 Step 6: squaring up the frame and fix base plates by stake peg Page 10...
-
Page 11: Cover Installation
Cover Installation Step 1: front cover with door Step 2: back cover Page 11... - Page 12 Step 3: roof cover Now your assembly is completed. Page 12...
