- Page 1 SPECIFICATION, INSTALLATION AND OPERATION MANUAL READ ALL INSTRUCTIONS BEFORE USE Models: Revision: 01 - 28/10/2020 - A...
- Page 2 Page Intentionally Left Blank Due to continuous product research and development, the information contained herein is subject to change without notice. www.stoddart.com.au www.stoddart.co.nz Page 1...
- Page 3 Your New Adande Product ........
- Page 4 Thank you for choosing this quality Adande product. All Adande products are designed and manufactured to meet the needs of food service professionals. By caring for and maintaining your new Adande product in accordance with these instructions, will provide many years of reliable service.
-
Page 5: Warranty Period
Introduction Warranty & Registration Australia and New Zealand Warranty Warranty Period All Stoddart manufactured and distributed products are covered by Stoddart’s standard Australia and New Zealand Product Warranty (minimum 12 month on-site parts and labour, terms and conditions apply). Further to this standard warranty, certain products have access to an extended warranty. -
Page 6: Safety Symbols
Introduction Warnings WARNING Follow the IMPORTANT SAFETY INSTRUCTIONS outlined in this user guide before operating this appliance. Failing to do so can result in death, electric shock, fire or injury to persons DO NOT store explosive substances such as aerosol cans with a flammable propellant in or near this unit This product is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning the use of the product by a person responsible for their safety. -
Page 7: Important Safety Instructions
Should a fault occur with the appliance immediately isolate/disconnect the incoming power supply • Only Adande trained engineers are permitted to service or carry out repairs to this appliance Due to continuous product research and development, the information contained herein is subject to change without notice. -
Page 8: Installation
Installation What is Adande ® Adande is a new method of cold storage developed as a series of refrigerated drawers that offer storage temperature flexibility in 1°C ® increments between 22°C and 15°C. – Each refrigerated drawer: • Provides stable temperature storage •... - Page 9 Ensure the unit is positioned on a level surface to allow all the condensation to properly burn off and prevent the burn off tray overflowing • It is important that the Adande drawer is installed and maintained on a flat, clean and level surface to ensure correct operation ®...
- Page 10 Refrigeration The system is fully operational as soon as it leaves the factory. No addition setup is required. Warning FLAMMABLE GAS R600a SYSTEM CHARGED WITH FLAMMABLE REFRIGERANT AND MUST BE SERVICED BY A QUALIFIED TECHNICIAN Climate Classes The unit has been designed and tested to operate at climate class 4. Refer to the Technical Specifications of this manual or the unit rating label for the climate class number.
-
Page 11: Specification
Specification General Drawing VCC1.SCW / VCC1.GCW 450mm wide Specifications 728mm 800mm deep 300mm drawer opening Model VCC1.SCW tub width W x D x H (mm) 450 x 800 x 845 560mm tub depth Weight 113kg Capacity 60 Litres Operation -22°C to +15°C Refrigerant R600a 350mm... -
Page 12: Initial Start-Up & Operation
Set Temperature/Scroll Menu Decrease Temperature/Manual Defrost Increase Temperature Manual Defrost • A helpful video tutorial for the Adande controller can be viewed using the QR Code: Initial Start Up • Before switching ON the unit, ensure the unit is installed correctly •... -
Page 13: Temperature Adjustment
Operation Temperature adjustment Press and hold the “set temperature” button, this will display the current set point Adjust the set point by holding the “set temperature” button and press the +/- buttons until desired set point is displayed Release all buttons. The temperature is now set Locking and Unlocking the Display Panel Press and hold the “set temperature”... -
Page 14: Drawer Alarm
If the drawer is open for more than 3 minutes, the Drawer Open alarm will be triggered, an audible alarm will sound and “DO” will flash on the display panel. When the alarm has been activated, the Adande ® drawer will alarm both visually and audibly. -
Page 15: Temperature Alarm
7°C and product core temperature should be checked. This alarm may also be triggered if the Adande® drawer has recently been turned on loaded with warm product or left open for a long period of time. If the temperature does not return to the set point temperature, contact the Stoddart service department. -
Page 16: Cleaning And Maintenance
Cleaning and Maintenance Cleaning General Information • Cleaning is recommended for health and safety purposes and to prolong the life of the unit • DO NOT use abrasive pads or cleaners on the stainless steel or any other metal parts of the unit •... - Page 17 It is recommended that cleaning should be performed at minimum weekly or in accordance with local codes. • The airflow through the Adande drawer is designed to deposit grease and dirt on the outside surface of the insulated container and internal surfaces of the drawer housing.
-
Page 18: Troubleshooting Procedures
Cleaning and Maintenance Troubleshooting Troubleshooting Procedures • If any faults/issues occur with the unit, follow the below troubleshooting procedures • If the troubleshooting procedures do not correct the problem, contact the Stoddart Service Department WARNING Technician tasks are only to be completed by qualified service people. -
Page 19: Declaration Of Conformity
Date of issue: 03/03/20 Name: Ian Wood Position: Managing Director Signature: The technical file for this machinery will be prepared on demand by Adande Refrigeration Due to continuous product research and development, the information contained herein is subject to change without notice. www.stoddart.com.au www.stoddart.co.nz... - Page 20 Australia Service / Spare Parts Sales Tel: 1300 307 289 Tel: 1300 79 1954 Email: service@stoddart.com.au Email: sales@stoddart.com.au Email: spares@stoddart.com.au www.stoddart.com.au Australian Business Number: 16009690251 New Zealand Service / Spare Parts Sales Tel: 0800 935 714 Tel: 0800 79 1954 Email: service@stoddart.co.nz Email: sales@stoddart.co.nz Email: spares@stoddart.co.nz...
