HEADBOARD ASSEMBLY INSTRUCTIONS
PARTS LIST:
(A) M8 bolts x4
(B) Washers x4
(C) Wrench x1
(D) M6 Bolts x4
(E) Washers x4
(F) Nuts x4
(G) Headboard Mount x2
(H) Wall Mount x2
(I) Screws x16
(J) Drywall Anchor x8
(K) Hex key
STEP ONE
Remove the headboard from the box and lay
it face down on the ground. Open the velcro
panel on the back and remove both the legs
and hardware.
STEP TWO
Using two (A) M8 bolts, two (B) washers and
the provided holes, secure both legs to the
headboard at your desired height with the
hex key provided. (see Figure 1)
STEP 3
(recommended)
Using the mounting blocks on the back of your headboard,
screw the two (G) headboard mounts to the top of your
headboard with the provided (I) screws. Using the remaining (I)
screws, attach the (H) wall mounts to your wall. Make sure to
place the wall mounts at the correct height to pair with your
previously installed (G) headboard mounts (see figure 2). If no
wall studs are available to secure the headboard to your wall,
use the provided (J) drywall anchors instead. Lift the headboard
and lower into place to join the (G) and (H) mounts together.
STEP 4
With the front side of the headboard facing the bed frame, attach
the headboard to the frame using the (D) M6 bolts, (E) washers
and (F) nuts.
If your bed frame doesn't fit the headboard, use the provided modification
plates to secure the bed frame to the headboard. More instructions are
included with the plates.
Failure to follow these warnings and assembly instructions could result
in serious injury or death. Read all instructions before assembling the
headboard. Keep the assembly instructions for future use. Before each
usage or assembly, inspect the headboard for damaged hardware, or
missing parts. DO NOT use the headboard if any parts are missing or
broken. If replacement parts and instructional literature are needed
contact us. DO NOT substitute parts.
A
B
D
E
G H
K
Figure
Figure
C
F
I
J
(A) Medium Bolts
(B) Washers
Mounting Block
(G) Headboard Mount
(G) Headboard Mount
Wall
(I) Screws x4
(I) Screws x4
(H) Wall Mount
(J) Drywall Anchor x2
(if needed in step 3)
Figure
Headboard
Bed Frame
(A) Medium Bolts
(B) Washers
Legs
(G) Headboard Mount
(E) Washers
(F) Nuts
(D) Long Bolts
