- Page 1 EK-AC Twin Edge RTX 3070 USER GUIDE...
- Page 2 Before you start using this product, please follow these basic This product is made from aluminum and can be only used guidelines: with other aluminum liquid cooling components, such as Al fittings, water blocks and radiators. Mixing aluminum with Carefully read the manual before beginning with the copper and brass products can cause galvanic corrosion installation process.
-
Page 3: Table Of Contents
TABLE OF CONTENTS BOX CONTENTS WATER BLOCK DIMENSIONS WATER BLOCK SPECIFICATIONS AND MAIN PARTS PREPARING YOUR GRAPHICS CARD REMOVING THE STOCK COOLER CLEANING THE PCB CUTTING AND PLACING THERMAL PADS APPLYING THERMAL COMPOUND INSTALLING THE WATER BLOCK PLACING THE BLOCK ON THE GRAPHICS CARD ATTACHING THE BLOCK TO THE GRAPHICS CARD INSTALLING THE BACKPLATE BACKPLATE DIMENSIONS... - Page 4 Universal Mounting Mechanism – You may not need every screw from this package. M2.5x4 AX1 Screw (22 pcs) M2.5x7 AX1 Screw (8 pcs) EK-AC Twin Edge RTX 3070 + Backplate EK-Loop Multi Allen Key (1 pc) PVC Washer M2.5 (22 pcs) EK-Plug G1/4 Acetal (2 pcs) Thermal Pad F 1.0 mm (4 pcs)
-
Page 5: Water Block Dimensions
WATER BLOCK DIMENSIONS 209.90 mm 198.40 mm 19.85 mm / 5 /... -
Page 6: Water Block Specifications And Main Parts
WATER BLOCK SPECIFICATIONS AND MAIN PARTS Technical Specification: - Dimensions (LxHxW): 210 x 110 x 20 mm - D-RGB (Addressable RGB) Cable - Length: 500 mm - D-RGB LED Count: 7 M3x10 DIN7991 SCREW - D-RGB Connector: Standard 3-Pin (+5V, Data, Blocked, Ground) M4x10 DIN7991 SCREW TOP PLATE LED COVER... -
Page 7: Preparing Your Graphics Card
Place your graphics card on the flat surface and carefully remove the stock cooler. Do not forget to unplug all the LED and fan connectors. Pay attention to the following steps in order to install EK-AC Twin Edge RTX 3070 water block onto the graphics card. -
Page 8: Cutting And Placing Thermal Pads
CUTTING AND PLACING THERMAL PADS STEP 1 Your GPU water block comes with thermal pads that have to be cut into smaller pieces to cover all the VRM components, such as COILs, MOSFETs, and drivers. Thermal Pad F – 1.0 mm (120 x 16 mm) You must remove the protective foil from both sides of the thermal pad before installation. -
Page 9: Applying Thermal Compound
APPLYING THERMAL COMPOUND STEP 1 Apply the enclosed EK-TIM Ectotherm thermal grease (thermal compound) on the CPU heat spreader – IHS – as shown in the image. The layer of the thermal compound must be thin and even over the entire surface of the IHS. The excessive or uneven application of thermal grease may lead to poor performance! For this Step, you will need:... -
Page 10: Installing The Water Block
INSTALLING THE WATER BLOCK STEP 1 PLACING THE BLOCK ON THE GRAPHICS CARD This procedure is the same for all full-cover water blocks. Carefully position the water block with preinstalled standoffs on the graphics card. During this process, make sure you have aligned mounting holes of the PCB with holes of the water block (same applies to other tops). -
Page 11: Installing The Backplate
INSTALLING THE BACKPLATE BACKPLATE DIMENSIONS 183.90 mm REQUIRED TOOLS Phillips Head Screwdriver / 11 /... -
Page 12: Attaching The Backplate
ATTACHING THE BACKPLATE Place the backplate on the PCB and make sure all holes are aligned. Position an M2.5X7 AX1 screw in each of the five (5) mounting holes (as shown in the image) and tighten them evenly with a Phillips head screwdriver. -
Page 13: Inserting The Graphics Card Into The Chassis
INSERTING THE GRAPHICS CARD INTO THE CHASSIS Carefully lift your graphics card with the installed water block and insert it into your PC’s motherboard PCIexpress expansion slot. Please keep in mind that your graphics card is heavier than before it was equipped with the water block. You need to be very careful when handling the graphics card. - Page 14 CONNECTING THE D-RGB LED STRIP STEP 1 Plug the 4-pin D-RGB connector from the GPU water block to the D-RGB Header on your motherboard or controller. The LED strip will work only if the pin layout on the header is as follows: +5V, Data, Empty, Ground. Incorrect installation or installation to a wrong header can damage to the LED strip or the header itself! D-RGB HEADER...
