I.H.T IDL707 Quick Start Manual

IDL707
(WIFI)
i.h.t Smart Lock Installation Instructions
Please read this manual carefully before use
Feature
5-Way Access Methods
Battery Type / Life
Storage Capacity
Identity Time
Low Voltage Warning
Privacy Password
Fire Rating
Installation
1. Installation Instructions
a. It is recommended to look for professionals to install, Watch the video carefully before
installing.
b. Please note that the connection line can't be pressed or folded during installation.
c. Before the installation, the lock must be positioned according to the door opening direction,
because the handle can't be adjusted after.
d. While installing, the door must be half opened until the installation is completed.
e. After the installation is completed, with the fingerprint, card, password (1234567890) and #,
APP and key unlocked, test whether the front and back handle can unlock/lock.
f. If it does not work properly, please check if there is an improper installation or if the power
cord is loose.
2. Installation Overview
Fingerprint, Password, Card, APP, Back-up Key
4×AA Battery / 1 Year
100 (Passwords, Fingerprints & Cards)
0.3 Seconds
≤4.6V
Random Numbers Can Be Added Before or After
120 Minutes (AU 1530.4:2014)
1. Front Panel
2. Connection Column
3. Square Steel
4. Lock Body
5. Connection Line
6. Back Panel
7. Battery Cover
8. Connection Column Screws
9. Back Handle
10. Connection Column Screws
11. Latch-bolt
12. Dead-bolt
13. Lock Body Screws
14. Connection Column
15. Key Hole
16. Emergency Power Port
17. Front Handle
18. 'SET' Button
