FIRST INSTRUCTIONS CAMERA INSTALLATION
Applicable to:
Mini rearview camera for V70, XC70, S60, S80 2000 - 2008 and XC90 2003-2012
Start point;
Your car is cleanly washed (makes sure you have less chances on making scratches while
working on the car.
Required tools;
Drill, 8.5 or 9mm (9mm preferred) and 3 or 4 mm drill.
Torx 20 screw driver
Plastic spoon/ Volvo fishbone tool.
Usage materials required:
Black tape
INDEX
First instructions Camera installation ..................................................................................................................... 1
Index ....................................................................................................................................................................... 1
Connect the P2 Litecam .......................................................................................................................................... 2
V70/S60/S80 ....................................................................................................................................................... 2
Camera installation ............................................................................................................................................. 7
For V70/XC70: ................................................................................................................................................. 7
CABLES .......................................................................................................................................................... 12
FOR S60/S80: ................................................................................................................................................ 14
XC90 ...................................................................................................................................................................... 19
Rearview camera .............................................................................................................................................. 20
FOR ALL MODELS AGAIN: ..................................................................................................................................... 27
FAQ: ...................................................................................................................................................................... 28
© 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com
Instruction# 1669
Version# 0.8
Part# -
EAN# SE-12
Installation manual
Litecam P2
Author: KW
1/30
Advertisement
Table of Contents
Related Manuals for SwedeSolutions Litecam P2
Summary of Contents for SwedeSolutions Litecam P2
-
Page 1: Table Of Contents
CABLES ................................12 FOR S60/S80: ..............................14 XC90 ..................................19 Rearview camera .............................. 20 FOR ALL MODELS AGAIN: ............................. 27 FAQ: ..................................28 © 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com Instruction# 1669 Version# 0.8 Part# - EAN# SE-12 Author: KW... -
Page 2: Connect The P2 Litecam
The S60/S80 part is easier, as you don’t have to remove these parts. Firstly remove the cover of the booth. Then remove the bolt shown in #1 Then pull the panel from the left side. © 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com Instruction# 1669 Version# 0.8... - Page 3 Now remove the green and grey connector as shown below. © 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com Instruction# 1669 Version# 0.8...
- Page 4 Now connect the grey and green connector to the litecam. Now connect the cables from the litecam to the RTI Computer. You can leave this step if you are not planning to use the RTI computer. © 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com Instruction# 1669 Version# 0.8...
- Page 5 Please note that if you have parking sensors that are not factory. It is possible that there is an additional har- ness is installed. This harness provides a ground and 12V for the parking sensor computer. Then you need the red/pink cable: © 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com Instruction# 1669 Version# 0.8 Part# - EAN# SE-12...
- Page 6 Litecam P2 After you’ve installed your camera you can plug in the camera using this cable. How to install the camera? Check the next chapters. © 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com Instruction# 1669 Version# 0.8 Part# -...
-
Page 7: Camera Installation
If the 4 TORX screws are removed, with a firm pull you can remove the panel. (push with 1 hand to the cover of the trunk (*1)) and pull with the other hand at the grip (*2)to pull the cover down. © 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com Instruction# 1669 Version# 0.8... - Page 8 Then remove the top cover parts, just pull down (no force required usually). Open the trunk. Then MAKE SURE ALL IS CLEAN TO AVOID SCRATCHING! Then cover the places near where you’ll have to drill to avoid damage. © 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com Instruction# 1669 Version# 0.8...
- Page 9 Drill with a 3 or 4 mm drill a small hole, then drill with the 9mm to finalize the hole in the cover. Place the camera as shown, but do not use the sticker cover yet, keep that sealed until later. © 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com Instruction# 1669 Version# 0.8...
- Page 10 Only remove the sticker once there’s image on the RTI screen and you can set the right angle. Inside the trunk you can now put the bolt on its place.Do not tighten to hard yet. © 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com Instruction# 1669 Version# 0.8...
- Page 11 Take the extention wire and connect to camera. Although connection is tight already between the 2 wires, please do seal it with some tape so it just can’t get loose at all. © 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com Instruction# 1669 Version# 0.8...
-
Page 12: Cables
Next cut the black point from the rubber (red circle) and cut some material away from the rub- ber (arrow) so the cable can go through. © 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com Instruction# 1669 Version# 0.8... - Page 13 Next just drop the cable down (behind the speaker cover; remove that cover if the cable won’t drop down totally) and connect it to the green connector at the iMIV/MII/LE+ © 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com Instruction# 1669 Version# 0.8...
-
Page 14: For S60/S80
Final Camera location: Start with removing the left license plate light. (please see Volvo owners manual in case you doubt on how-to) and clean the surrounding area! © 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com Instruction# 1669 Version# 0.8 Part# -... - Page 15 Mark the center of the cross (point 2) with a sharp object to be able to drill trough later: Please DO check that particular point, by using the sticker sheet of the camera. Should be nicely centered.. © 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com Instruction# 1669 Version# 0.8...
- Page 16 Push the camera wire trough the rubber to the inside of the trunk cover. (you might need to take the rubber out first, and make a whole to be able to get the wire trough!) © 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com Instruction# 1669 Version# 0.8...
- Page 17 Use some tape to tighten the camera harness to the original wiring. Last point is to push the camera harness into the car again, trough the rubber as well at this point. © 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com Instruction# 1669 Version# 0.8...
- Page 18 Installation manual Litecam P2 © 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com Instruction# 1669 Version# 0.8 Part# - EAN# SE-12 Author: KW 18/30...
-
Page 19: Xc90
Now hookup the Litecam to the RTI computer. The extra cable needs to go to the re- verse lights. So route that to the reverse lights in the back. © 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com Instruction# 1669 Version# 0.8... -
Page 20: Rearview Camera
Then remove the handle-bar cover on the right ide Then remove the TORX screws on the right hind side where you just removed the handle-bar cover. © 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com Instruction# 1669 Version# 0.8... - Page 21 Remove the connector from the light-unit. Remove the parts from the side and tilt the floor cover. Drill a 8.5 mm hole and push the camera and cable in. © 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com Instruction# 1669 Version# 0.8...
- Page 22 Guide (and tape) the cable set (directly connected to the camera) to the LEFT part of the trunk. Connect the extention cable now. Guide the cables between the windshield and the metal to the roof of the car (do NOT push too hard!) © 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com Instruction# 1669 Version# 0.8...
- Page 23 Now hookup the wiring to the car here as done in the set and as labeled for you. Then continue to push the Video/Switchcord cable to the front. © 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com Instruction# 1669 Version# 0.8...
- Page 24 Then guide the wiring below the rails , and bring it back up next to the seat handle of the 3 seating row. Pull upwards the covers and put the cables under them. © 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com Instruction# 1669 Version# 0.8...
- Page 25 And there the cabling can be put under the floor cover, under the drivers seat! (please find the place where 2 floor cover parts are connected, if you push the rear part down, you can slip the cables in!) © 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com Instruction# 1669 Version# 0.8...
- Page 26 Pull the cables up under the drivers seat and connect them to the litecam! The activation wire needs to go to the oposite side. As it needs to be connected to the reverse light in the back. © 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com Instruction# 1669 Version# 0.8...
-
Page 27: For All Models Again
RTi screen. Now adjust the camera as you want and decide which position is the one you like. END OF INSTRUCTION © 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com Instruction# 1669 Version# 0.8... -
Page 28: Faq
A: this is as designed. To avoid very fast and rapid switching while you’re parking the car (re- versing, back in 1 gear, reversing etc.) the camera will stay active for about 6-7 seconds after the reverse gear is switched off. © 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com Instruction# 1669 Version# 0.8 Part# -...
