SCBA PHANTÖM MANUAL
SCBA PHANTÖM MANUAL
NFPA 1997 - 2002 - 2007
NFPA 1997 - 2002 - 2007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PHANTÖM NFPA 1997 and is the answer not in the manual?

Questions and answers

Related Manuals for Skold PHANTÖM NFPA 1997

Summary of Contents for Skold PHANTÖM NFPA 1997

  • Page 1 SCBA PHANTÖM MANUAL SCBA PHANTÖM MANUAL NFPA 1997 - 2002 - 2007 NFPA 1997 - 2002 - 2007...
  • Page 2 Sköld SCBA Phantöm NFPA 1997 INSTRUCTION MANUAL Sköld Safety Quick and complete guide to self-contained breathing apparatus in its Phantöm NFPA 1997, 2002 and 2007 version.
  • Page 3 Sköld PHANTÖM NFPA 1997 CERTIFICATION CE: EN 137:2006 Equivalent NFPA 1997 Models: SCBA-P30FC (30 minutes carbon fiber cylinder) SCBA-P60FC (60 minutes carbon fiber cylinder) SCBA-P120FC (2 cylinders of 120 minutes carbon fiber cylinder) IMPORTANT POINTS - PLEASE READ CAREFULLY IF NOT USED AND KEPP APPROPRIATE THIS PRODUCT MAY RESULT IN INJURY OR DEATH The Phantöm´s pneumatic system is designed to be simple to use and easy to maintain and will operate for many years if given proper maintenance and cleaning.
  • Page 4 Sköld SCBA Phantöm NFPA 1997 INSTRUCTION MANUAL WORKING TEMPERATURES: The Phantöm is approved for respiratory protection during entry or exit of oxygen deficient atmospheres, gas atmospheres, and atmospheres of vapors at temperatures above -25°F. When used below the freezing point, care must be taken to prevent moisture from entering the demand and exhalation valves.
  • Page 5 Sköld * If the supplied air fails, open the cylinder valve and exit to fresh air immediately. * Wear suitable skin protection when worn on gases and vapors that Poisoning by absorption through the skin (eg hydrocyanic acid gas). The Sköld Safety Phantöm is a self-contained breathing apparatus, compressed air and circuit which is approved by the National Institute of Occupational Safety and Health (NIOSH).

  • Page 6: Routine Checks

    Sköld SCBA Phantöm NFPA 1997 INSTRUCTION MANUAL Each valve has a safety feature and a double reading pressure gauge. The valve protection is provided by an elastomeric bumper. PRECAUTIONS OF HANDLING: NEVER STAND OR CARRY THE UNIT BY THE MASK HOSE OR BY ASSEMBLING THE GAUGE. IF THE HOSE OILS IS DAMAGED IN ANY WAY, IT MUST BE REPLACED.
  • Page 7 Sköld 2.3 ROUTINE CHECKS INSPECTIONS The following procedure should be used for daily and future inspections of the apparatus. an SCBA that is not routinely used, but stored for emergency use only, should be inspected at least once a month. All other appliances should be inspected after each use. WARNING THE APPLIANCE MUST NOT BE USED UNTIL THE FOLLOWING TESTS HAVE BEEN COMPLETELY COMPLETED.

  • Page 8: Normal Use

    Sköld SCBA Phantöm NFPA 1997 INSTRUCTION MANUAL 3.1.7 Open the cylinder valve slowly by turning it counterclockwise to a fully open position. The whistle must be activated when the cylinder valve is opened. There must be air flowing out of the Compact Demand Valve (CDV).

  • Page 9: Cleaning After Use

    Sköld 4.1.3 INSTRUCTIONS FOR CHANGING CYLINDERS 4.1.3.1 Make sure that the cylinder valve is closed and that all air has been emptied from the pneumatic system. 4.1.3.2 Lift the latch to release the tension of the cylinder belt. 4.1.3.3 Disconnect the handle from the cylinder valve and remove the cylinder by sliding it up through the cylinder strap.

  • Page 10: User Maintenance

    Sköld SCBA Phantöm NFPA 1997 INSTRUCTION MANUAL NOTE: THE COMPACT DEMAND VALVE CAN BE PUT IN WATER. 6.1.2 Rinse thoroughly in clean water, allowing water to flow through the mask. 6.1.3 After rising, shake to get rid to excess water. Dry with soft, clean cloth. NOTE: Make sure that all head harness straps are fully extended, ready for use.
  • Page 11 Sköld CAUTION IF IT IS NECESSARY TO CLEAN THE EXTERIOR PART OF THE COMPACT DEMAND VALVE, CARE MUST BE CAREFUL TO ENSURE THAT WATER TRAILS WERE NOT LEFT AT THE OPENING OF THE CDV. CONNECT THE UNIT TO THE FULL AIR CYLINDER TO BLOW THE TEMPERATURES BELOW FREEZING POINT.
  • Page 12 Sköld SCBA Phantöm NFPA 1997 INSTRUCTION MANUAL 10.0 PHANTÖM GUARANTEE Sköld Safety warrants to the original owner that the Phantöm SCBA is free from defects in materials and workmanship for a period of one year from the date of original purchase to the Sköld Safety factories.
  • Page 13 Problems Possible causes Failure Elimination There is an exces- The diaphragm of exhalation valve Check and clean the components of exhalation valve. sive resistance gets tacky. when exhaling There is leakage in the junction of Check whether there is some material in the joint pressure-reducing valve and surface and whether the “O”...
  • Page 14 Sköld SCBA Phantöm NFPA 1997 INSTRUCTION MANUAL HUD INSTRUCTIONS FOR SCBA PHANTÖM NFPA 2002 FIRST PART: Outline. Wireless Pressure Head-Up Display Device (Names HUD) is an indicator, it displays the pressure change inside the cylinder, by wireless matching and then receiving the signal from the pressure sensor controller.
  • Page 15 Sköld 1. Air pressure state - Green light: The pressure is more than 10Mpa. - Yellow light: The pressure is more than 6Mpa and less than 10Mpa. - Red light: The pressure is less than 6Mpa, and at the same time, the shocking reminder will start.

  • Page 16: Main Technical Parameter

    Sköld SCBA Phantöm NFPA 1997 INSTRUCTION MANUAL 2. Main technical parameter Content Parameter Working pressure Continuous working time >24h Wireless communication ≥1.5m distance 0~40MPa Pressure indication range Explosion levels Exia II CT3 Ga (Intrinsically Safe) Protection class IP67 Working: -20°C ~ +60°C; Environment Storage: -10°C ~ +45°C Temperature...

  • Page 17: Low-Pressure Alarm

    Sköld 3. Replacing the battery When the battery is in low power, the yellow light will flash, HUD can still work for more than 2 hrs. remove the battery, replace the specified type of special batteries. Battery type: CR123A Digital/Analog Manometer Digital Display 1.

  • Page 18: Replace The Battery

    Sköld SCBA Phantöm NFPA 1997 INSTRUCTION MANUAL 9. Wireless transmission function Under the power-on state, the Pressure Sensor Controller will send the air pressure data 2 seconds one time, at the same time, the Azimuth indicator will flash shortly. 10. Replace the battery When the indicator shows the battery is not sufficient, please replace the battery, with a special screwdriver to unscrew the battery compartment cover crews, open the cover, remove the battery, follow the prompts to the battery positive and negative direction to...

  • Page 19: Components Introduction

    Sköld 4. Warning 4.0 Please check if the microphone is tightened on mask after wearing. 4.1 Make sure the power is on when working. 4.2 Close the power and take the battery out when not working 5. Components introduction 5.0 Full facemask 5.5 Connect walkie-takie 5.1 Power 5.6 Battery compartment...
  • Page 20 Sköld SCBA Phantöm NFPA 1997 INSTRUCTION MANUAL Auriculares Mascarilla completa Encendido/Apagado Compartimiento de la batería Altavoz Conectar walkie-talkie Colocar filtro Ajuste de volumen Sköld Safety...

  • Page 21: Safety Specification

    Sköld PHANTÖM NFPA 2007 Self-Contained Positive Pressure Air Breathing Apparatus with LCD-HUD 1. Use and scope of application Self-Contained Positive Pressure Air Breathing Apparatus with LCD-HUD (LCD-HUD SCBA), can be applied to other polluted regions that may be lack of oxygen, the scene of fire, rescuing measures and repairing in the fields of firefighting, chemical industry, metallurgy, miner, petroleum, etc.

  • Page 22: Description Of The Product

    Sköld SCBA Phantöm NFPA 1997 INSTRUCTION MANUAL 3. Description of the Product The air shall be stored in the cylinder of LCD-HUD SCBA by using the method of compres- sing air, the high-pressure air shall be transmitted to the middle-pressure tube after being subjected to primary pressure reduction by using the reducer, and the positive-pressure air shall be supplied to the user by using the mask after secondary pressure reduction by using the demand valve.
  • Page 23 Sköld 3.1.1 Introduction of Functions The pressure head-up display (HUD) is designed integrally with the demand valve; the master transmission box is connected with the HUD system by the wire to transmit the data and information, wherein the LCD-HUD system can display the compass, the time, the low voltage, SOS indication, the remaining time available of the air bottle, the pressure of the cylinder, the ambient temperature and the pressure, and can implement the functions of position indication, digital display of clock, low-voltage warning, SOS and low-pressure...
  • Page 24 Sköld SCBA Phantöm NFPA 1997 INSTRUCTION MANUAL 3.1.3 Sketch Map of HUD Front Functions Front SOS Light The front alarm device of the HUD demand valve has the functions of indicating low-voltage and cylinder pressure, emergency SOS indication, Yellow light: alarming.
  • Page 25 Sköld Note: - The cylinder shall be taken and placed slightly and prevented from the collision. - The cylinder shall be scrapped immediately when finding that the fiber of the cylinder is broken. - The pressure shall not be higher than the nominal pressure when charging the cylinder. - The cylinder shall be kept far from the fire, heat, the harmful and toxic gas when charging, and the surroundings shall be clean.
  • Page 26 Sköld SCBA Phantöm NFPA 1997 INSTRUCTION MANUAL 5. Connect the charger with the charging socket, 4. Insert the USB plug into the the battery shall be charged fully when all power charging port. display lights are lighted on. Note: - The power of the lithium battery must be inspected before use. - Please recharge the lithium battery when the power is low.
  • Page 27 Sköld 3.5.1 Operating Steps of Quick-filling Device Relevant warning and notes, and the method of selecting, using and maintain this product are included in this manual. All people who will use or maintain the product must read the manual carefully and comply with the manual. The SCBA can be used safely and the high-quality services can be acquired only when the user reads the following instruction carefully.
  • Page 28 Sköld SCBA Phantöm NFPA 1997 INSTRUCTION MANUAL 3.6 Pressure Gauge & Alarm Device The pressure gauge has a scale of (0-40) Mpa and Level 1.6 accuracy; it is connected with pressure reducer and high-pressure pipe. The dial plate adopts fluorescence materials, so the pressure valve can be observed distinctively in darkness.

  • Page 29: Operating Steps

    Sköld 1. Master transmission box 2. Lithium battery box 3. PTT switch 4. Connecting pin of pressure eye level display 5. Connecting pin of interphone 4. Operating Steps 4.1 Rapid Test Before Usage 1. Power display: press the power display switch on the lithium battery to see whether the power display light of lithium battery indicates sufficiency (5 lights indicate fullness).
  • Page 30 Sköld SCBA Phantöm NFPA 1997 INSTRUCTION MANUAL 4.3. List of Indicator Lights, Buzzer and Vibrating Function Alarm function SOS alarm Low air 60º Low voltage Rescue Evacuation pressure temperature alarm pressure Pre-alarm Alarm status alarm alarm Alarm mode Light flases Light flases Back SOS light every 1s...

  • Page 31: Maintenance

    Sköld 5. Maintenance 5.1 Air Cylinder The cylinders must be regularly checked in accordance with relevant laws and regulations of the state, and by professional institutions and personnel authorized for testing, and records shall be made. In terms of daily use, you should check valve and ensure the sealing is without leakage, and the valve and reducer interface is screwed up.
  • Page 32 Sköld SCBA Phantöm NFPA 1997 INSTRUCTION MANUAL 5.4 Storage Only the cleaned, disinfected, checked, maintained and recorded respirator can be stored. It shall be kept in dustless and cool place at ambient temperature. It shall get rid of direct sunlight and thermal source, and humid and corrosive materials. The storage temperature shall be 15 °C-30°C.
  • Page 33 Sköld 6.2.Daily Maintenance Record See the below table: Name Date Head strap Cylinder valve Pressure reducer Demand valve Mask 7. Common Fault and Elimination Measures See the below table: Part name Fault phenomenon Possible cause Elimination measures Leakage in high-pressure 1.
  • Page 34 Sköld SCBA Phantöm NFPA 1997 INSTRUCTION MANUAL Record form of regular inspection Specification Code: Product Code: Items Records Inspection date Face mask Air supply valve Back-up Names of Cylinder components inspection parts Pressure reducer Alarm and table Performance check Cleanliness Other aspects Marks sample: O indicates passing the inspection Q indicates passing the inspection after maintenance.
  • Page 35 DISTIBUTOR INFO. SCBA PHANTÖM MANUAL BY Sköld For more information www.skoldsafety.com Guadalajara #4025 Col. Los Altos Monterrey N.L. C.P. 64370 +52 1 (81) 1872.7848 / skold@skoldsafety.com...
