  • Page 2 HUD INSTRUCTIONS FOR SCBA Phantöm NFPA 2002 FIRST PART: Outline Wireless Pressure Head-Up Display Device (Names HUD) is an indicator, it displays the pressure change inside the cylinder, by wireless matching and then receiving the signal from the pressu- re sensor controller. HUD supplies a visual system for monitoring the air volume inside the cylinder.

  • Page 3: System Components

    Sköld SCBA Phantöm NFPA 2002 INSTRUCTION MANUAL 6.- When the air pressure is lower than alarm threshold, it will alarm. 7.- There are warning lights. 8.- Using a large capacity battery. 9.- Display the battery power, low voltage will voice prompts. 10.- There are directional light function.

  • Page 4: Main Technical Parameter

    1.- Main technical parameter Content Parameter Working pressure DC 3.6V Maximum working <25mA 83.6v) electric current Continuous > working time Wireless > communication 1.5m distance Pressure 0-30Pa indication range Pressure LED light: green, yellow, red indication mode Explosion levels Exia II CT3 Ga Protection class IP65 Working: -20°C ~ +60°C;...
  • Page 5 Sköld SCBA Phantöm NFPA 2002 INSTRUCTION MANUAL 1.- ON/OFF Open the device: After fixing the HUD press the red button and then release, all the indicators light after 2 seconds, the device is on. Close the device: The HUD will close automatically, after the HUD hasn´t received any air pressu- re data in 180 minutes.
  • Page 6 2.- Pressure Display There are 3 digits on the LCD screen shows the air pressure, it shows 0-30MPs. Under normal operating conditions, the pressure refreshed every two seconds. 3.- Backlighting, field temperature, and residual gas usage time switch. Press the right button, lit the backlight display, it will display the air pressure, press the right button again display the scene temperature when the backlight is on, and it also can display the site temperature.

  • Page 7: Application Description

    Sköld SCBA Phantöm NFPA 2002 INSTRUCTION MANUAL The HUD is installed inside the facemask, install it and fix it then can use directly. Digital Display After interface with hog-pressure pipe connected, plugged in fixed pin stuck interface, the fixed pin bracket securely installed before use. THIRD PART: Cautions in use 1.- When using and transporting, try to avoid falling and impact.
  • Page 8 Auriculares Mascarilla completa Encendido/Apagado Compartimiento de la batería Altavoz Conectar walkie-talkie Colocar filtro Ajuste de volumen...
  • Page 9 Sköld SCBA Phantöm NFPA 2002 INSTRUCTION MANUAL WARNING THE APPLIANCE MUST NOT BE USED UNTIL THE FOLLOWING TEST HAVE BEEN COMPLETED. ANDY DISCREPANCY NOTED DURING THE PRE-USE AND INSPECTION CHECK SHOULD ONLY BE CORRECTED BY AN AUTHORIZED PERSONNEL BEFORE BEGINNING TO USE THE APPLIANCE. Manual SCBA SKÖLD PHANTÖM Certification CE: EN 137:2006 /Equivalent NFPA 1997 Models:...

  • Page 10: Precautions And Limitations

    WORKING TEMPERATURES The Phantöm is approved for respiratory protection during entry or exit of oxygen deficient atmospheres, gas atmospheres, and atmospheres of vapors at temperatures above -25°F. When used below the freezing point, care must be taken to prevent moisture from entering the demand and exhalation valves.
  • Page 11 Sköld SCBA Phantöm NFPA 2002 INSTRUCTION MANUAL The Sköld Safety Phantöm is a self-contained breathing apparatus, compressed air and circuit. Which is approved by the National Institute of Occupational Safety and Health (NIOSH). The positive pressure is maintained inside the mask during use, this providing the highest degree of protection.

  • Page 12: Routine Checks

    PSIG Average duration Valve and cylinder Free air Material Cylinder’s diameter Hydrostatic Interval Pressure @40 lpm NIOSH weight capacity Carbon and 1287 liters 4500 11.0 lbs. 5.4 in 3 years 30 min Epoxy 45 ft Carbon and 2516 liters 4500 19.2 lbs.
  • Page 13 Sköld SCBA Phantöm NFPA 2002 INSTRUCTION MANUAL 2.3.1 Visually inspect the entire appliance for worm parts and damaged components. 2.3.2 The basic cylinder inspection shall include: A ) Inspect the indicator for damage. B ) Inspect for mechanical damage to the cylinder (cracks, dents) or signs of heat or chemical damage.

  • Page 14: Normal Use

    3.19 Turn and pull out the Compact Demand Valve (CDV) to verify that it is secured in the mask or hood. 3.1.10 With the Compact Demand valve (CDV) secured, the whistle be turned off. 3.1.11 If the Compact Demand Valve (CDV) is attached to the hood or mask before putting it on, open the cylinder valve before putting on the mask or hood.
  • Page 15 Sköld SCBA Phantöm NFPA 2002 INSTRUCTION MANUAL 4.1.3 INSTRUCTIONS FOR CHANGING CYLINDERS 4.1.3.1 Make sure that the cylinder valve is closed an that all air has been emptied from the pneumatic system. 4.1.3.2 Lift the latch to release the tension of the cylinder belt. 4.1.3.3 Disconnect the handle from the cylinder valve and remove the cylinder by sliding it up through the cylinder strap.
  • Page 16 NOTE: THE COMPACT DEMAND VALVE CAN BE PUT IN WATER. 6.12 Rinse thoroughly in clean water, allowing water to flow through the mask. 6.13 After rising, shake to get rid of excess water. Dry with soft, clean cloth. NOTE: Make sure that all head harness straps are fully extended, ready for use.
  • Page 17 Sköld SCBA Phantöm NFPA 2002 INSTRUCTION MANUAL F. Check that the safety disk outlet is clean and free of debris. G. If you notice any of the situations listed above, decompress the cylinder to a slight positive pressure, label it and remove it from service.
  • Page 18 10.0 PHANTÖM GUARANTY Skold Safety warrants to the original owner that the Phantom SCBA is free from defects in materials and workmanship for a period of one year from the date of original purchase to the Sköld Safety factories. Sköld Safety’s obligation under this guaranty is limited to replacing or repairing at Sköld Safety’s option, any deective parts if returned to Sköld Safety in Monterrey...
  • Page 19 Sköld SCBA Phantöm NFPA 2002 INSTRUCTION MANUAL Problems Possible causes Failure Elimination Check whether there is some material in the joint There leakage surface and whether the “O” sealing ring is aging junction of pressure-reducing and cracking. It should be replaced with a new one. valve and cylinder valve.
