- Page 1 MF-180 INSTRUCTION MANUAL INSTRUCTION MANUAL Heat Flow Sensor MF-180M HF-30S HF-10S...
- Page 2 7 - 2 . D ime ns ions 7 - 3 . Acc es s o r i es L is t APPENDIX A - 1 . Ap pl ica t io ns Pg. 1 EKO INSTRUEMTNS CO., LTD. Heat Flow Sensors Instruction Manual Ver.7...
-
Page 3: Important User Information
For warranty terms and conditions, contact EKO or your distributor for further details. EKO guarantees that the product delivered to customer has been verified, checked and tested to ensure that the product meets the appropriate specifications. The product warranty is valid only if the product has been installed and used according to the directives provided in this instruction manual. - Page 4 2-3. About This Instruction Manual Copy Rights Reserved by EKO INSTRUMENTS CO., LTD. Making copies of whole or parts of this document without permission from EKO is prohibited. This manual was issued: 2018/5/18 Version Number: 2-4. Environment 1. WEEE Directive 2002/96/EC...
-
Page 5: Safety Information
3. Safety Information EKO products are designed and manufactured under the consideration of the safety precautions. Please make sure to read and understand this instruction manual thoroughly in order to be able to operate the instrument safely and in the correct manner. -
Page 6: Main Functions
EKO heat flow sensors provide highly accurate measurements compared to heat flow measurements by a common thermometer. Due to their high sensitivity, EKO heat flow sensors perform well even with low heat flow measurements. The heat flow sensors are calibrated using the improved GHP method (JIS A 1412, ASTM C1777). -
Page 7: Package Contents
4-2. Package Contents Check the package contents first; if any missing item or damage is noticed, please contact EKO immediately. Table 4-1. Package Contents Standard Items Qty. Remarks Heat Flow Sensor 10m cable attached (*) Inspection Report Instruction Manual (*) HF-10S and HF-30S without cable are also available. -
Page 8: Getting Started
When heat flows from the side with serial number is indicated, plus voltage is HF-10S: output. When heat flows from the side with white dot marks is indicated, plus voltage is MF-180M: output. Pg. 7 EKO INSTRUEMTNS CO., LTD. Heat Flow Sensors Instruction Manual Ver.7... -
Page 9: Permanent Installation
To avoid getting effects from the surrounding radiation, paint the surface with same color. **Grease type silicon grease has high thermal conductivity and bonding effect. Optional accessories: YG6111 (200g、1kg) Pg. 8 EKO INSTRUEMTNS CO., LTD. Heat Flow Sensors Instruction Manual Ver.7... - Page 10 Expanded Urethane *Silicon grease with high thermal conductivity and bonding effect for temporary installation. Please see section 7-3. Accessory section and/or contact EKO for more details and purchasing. Pg. 9 EKO INSTRUEMTNS CO., LTD. Heat Flow Sensors Instruction Manual Ver.7...
-
Page 11: Data Collection
Also, when the Heat Flow Sensor is attached on a surface, the convective flow by the air current and radiation of the surrounding area will cause a measurement error. Pg. 10 EKO INSTRUEMTNS CO., LTD. Heat Flow Sensors Instruction Manual Ver.7... - Page 12 ・K/W) ・K/W) MF-180 0.014 0.96 Wood 0.31 HF-30S, HF-10S 0.0016 0.99 MF-180 0.014 0.88 Concrete HF-30S, HF-10S 0.0016 0.98 MF-180 0.014 0.07 Steel 0.001 HF-30S, HF-10S 0.0016 0.38 Pg. 11 EKO INSTRUEMTNS CO., LTD. Heat Flow Sensors Instruction Manual Ver.7...
-
Page 13: Maintenance And Troubleshooting
6-2. Calibration and Tr aceability 1. Calibration Method The calibration of these heat flow sensors are performed at EKO according to the following procedure. Set the calibrating heat flow sensor in between high temperature and low temperature plates. Set the high temperature plate to 45℃ and low temperature plate to 15℃ and start the calibration measurement. -
Page 14: Troubleshooting
(the heat flows in perpendicular to the sample). 6-3. Troubleshooting Check the following items in case of trouble with the instrument. If any questions should remain, contact EKO for further technical support. -
Page 15: Sensor Specification
Orange (-) Minus HF-30S φ3.2mm MF-180 Cable end: pin terminal Material: Teflon White (+) Plus Diameter: 0.24mm Blue Black (-) Minus ×2pins MF-180M Φ3.2mm Cable end: Y terminal Pg. 14 EKO INSTRUEMTNS CO., LTD. Heat Flow Sensors Instruction Manual Ver.7... - Page 16 7-2. Dimensions 1. MF-180 Thickness: 0.9mm 2. MF-180M Thickness: 1.2mm 3. HF-30S Thickness: 0.5mm 4. HF-10S Thickness: 0.5mm Figure 7-1. Dimensions (mm) Pg. 15 EKO INSTRUEMTNS CO., LTD. Heat Flow Sensors Instruction Manual Ver.7...
-
Page 17: Accessories List
7-3. Accessories List Table 7-3. Accessories List Option Items Remarks Silicon Grease YG6111(200g tube), YG6111(1kg metal can container) Pg. 16 EKO INSTRUEMTNS CO., LTD. Heat Flow Sensors Instruction Manual Ver.7... - Page 18 Heat-transfer engineering research, education material, chemical reaction (heat Research generation and absorption) analysis Thermal Conductivity of Refrigerator, automobile, train cart Machineries and Devices Applications on Devices Thermal conductivity measurement device (HFM Method), Calorie Meter Pg. 17 EKO INSTRUEMTNS CO., LTD. Heat Flow Sensors Instruction Manual Ver.7...
- Page 19 EKO Asia, Oceania 1-21-8 Hatagaya, Shibuya-ku, Tokyo 151-0072 P. +81.3.3469.6711 F. +81.3.3469.6719 info@eko.co.jp www.eko-asia.com EKO North America 95 South Market Street, Suite 300, San Jose, CA 95113, USA P. +1-408-977-7751 F. +1-408-977-7741 info@eko-usa.com www.eko-usa.com EKO Europe, Middle East, Africa, South America...
