21. Have repairs carried out only by a qualified
electrician
- This electric tool complies with the pertinent
safety regulations. Repairs are to be carried out
only by a qualified electrician or the user may
suffer an accident.
22. Connect up a vacuum extraction system
- If there are provisions for connecting up a
vacuum extraction system, make sure that such
a system is fitted and in use.
23. Noise
- The noise level of this electric tool is measured
in accordance with ISO 3744 and NFS 31-031
(84/537/EEC). Noise at the workplace may
exceed 85 dB(A). In this case, the operator must
wear ear-muffs or similar.
Keep these safety instructions in a safe place.
The Grinding and Engraving Set is designed to
perform drilling, grinding, deburring, polishing,
engraving, cutting, milling and cleaning jobs on
wood, metal and plastic in model-making,
workshop and household applications. Use the
tool and accessories only for those applications
described.
1. Items supplied (Fig. 1)
1 Drive unit
2 Plastic case
3 Flexible shaft
4 Vice
5 Telescopic stand rod
6 Set of accessory parts

2. Technical data

Operating voltage of the drive unit: 230V ~ 50 Hz
Idle speed n : 10,000 - 35,000 min
0
Clamping range:
Weight of tool (without packing):
Sound pressure level: 73.4 dB(A)
Sound power level: 86.4 dB(A)
Vibration a :
w
Totally insulated
3. Description
1 On/Off switch
2 Speed regulator
3 Drill chuck nut
4 Button catch for drill chuck
8
06.06.2006 9:06 Uhr Seite 8
4. Using the tool for the first time
Make sure that the drive unit is switched off.
Check that the mains voltage specified on the
rating plate of the power supply unit is the same
as your mains supply. Only then should you
insert the plug of the power supply unit into a
socket-outlet.
Using the stand (Fig. 5)
Fit the stand to a workbench
The stand is adjustable in height and can be
adjusted as shown in Fig. 5.
The multi-tool can now be attached to the stand.
Fitting the various tools
Switch off the drive unit and disconnect it from the
power supply unit each time before you insert a tool
(and change a tool).
1. Press the button catch and turn the drill chuck
until the pin latches in place.
2. Unscrew the drill chuck nut.
3. Insert the tool of your choice in the chuck sleeve
as far as the stop and tighten the drill chuck nut.
On/Off switch
Switch on the drive unit with the power switch. You
can set the required speed with the speed regulator.
The correct speed depends on the tool you are using
and on the material you are processing.
Tips
Exert only moderate pressure on the workpiece
and allow it to be processed at uniform speed.
You will not finish your work sooner by exerting
heavy pressure. On the contrary, heavy pressure
will cause the drive unit to slow down or stop and
will overload the motor.
-1 For your own safety, use a vise or screw clamp to
secure small workpieces.
3.2 mm
0.61 kg
Directions for use
With small milling cutters / grinding pins: Use a
3.5 m/s 2
high speed.
With large milling cutters / grinding pins: Use a
II /
low speed.
Precision work / engraving: Hold the drive unit
like a pen.
Rough work: Hold the drive unit like a hammer.
