- Page 1 USER MANUAL ™ Replacement Board Kit for EnviroMonitor Gateway and Vantage Connect Product number 6682 Davis Instruments, 3465 Diablo Avenue, Hayward, CA 94545-2778 U.S.A. • 510-732-9229 • www.davisinstruments.com...
- Page 3 LTE Replacement Board Kit You can use this kit to convert a Vantage Connect (product numbers 6620, 6621, 6622) or older EnviroMonitor Gateway (product numbers 6800 or 6801) into a 6802 LTE Gateway. Note: This kit is for systems installed in the US only.
-
Page 4: Tools Needed
Vantage Connect: Remove the Old Board Tools Needed: Phillips head screwdrivers: #3 (small) and #2 (medium) Remove screws Main power jack Vantage Connect DID: AA123456789 Old cell modem Cover antenna Old weather receiver antenna Main power cable 1. Open your Vantage Connect shelter. 2. - Page 5 EnviroMonitor Gateway: Remove the old Board Remove screws Main Power Jack Old Cellular Cover Antenna Old Mesh Antenna Main Power Cable 1. Open your Gateway shelter. 2. Unplug the main power cable from the main power jack and disconnect the battery cables to allow for easier access to the board.
- Page 6 Install the LTE Replacement Board 1. Being careful with the antenna cables, center the new board with the screw holes above the appropriate bosses in the shelter. 2. Using the three #4 x 3/8” screws, attach the board. 3 #4 X 3/8” screws Use these holes 3.
- Page 7 You can leave these two stations as is, or you can merge the old data into the new. 1. Log into your account on WeatherLink.com and select the new EnviroMonitor Gateway. 2. Click Tools icon (it looks like a wrench).
-
Page 8: Contacting Davis Technical Support
Now you are ready to connect and remount your Gateway and add Nodes as desired. For instructions on how to do this, please refer to the EnviroMonitor Gateway and Node User Guide. It can be found in the support section of www.davisinstruments.com.
