Illustrated
Parts Manual
Beginning S/N: 168631
P/N 6000-34

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C19i and is the answer not in the manual?

Questions and answers

Related Manuals for Walker C19i

Summary of Contents for Walker C19i

  • Page 1 Illustrated Parts Manual Beginning S/N: 168631 P/N 6000-34...
  • Page 2 LH ......................Left Hand (orientated with operator on seat) LP ................................Low Profile mm (Dimension) ............................millimeters MS (Fastener) ............................Machine Screw NS (as part number)..................Item is not sold by Walker Manufacturing OD ..............................Outside Diameter oz..................................ounce PFH (Fastener) ..........................Phillips Flat Head P/N................................Part Number...

  • Page 3: Table Of Contents

    Limited Warranty ............ 37 Steering Control Assemblies ........16 Throttle Control Assembly ........18 Parking Brake Assembly .........20 GHS Group .............22 GHS Powerfil Assembly (7.0) ........24 ® GHS 7.0 Bushel Catcher Assembly......26 Beginning S/N 168631 Use only genuine Walker replacement parts. ®...

  • Page 4: Tractor Decals

    TRACTOR DECALS ITEM PART DESCRIPTION LOCATION REQUIRED Walker Product and Operation Decals 8600-33 RH Fender Body, RH Near Seat 5813-2 Decal, 4" Grass-Pak Powerfil Powerfil Cover Plate ® ® 5800-11 Walker (8" Round) 7.0 Bushel Catcher (one on each side) 8600-37 LH Fender...
  • Page 5 TRACTOR DECALS Refer to Decks Parts Manual for Deck Decals Beginning S/N 168631 Use only genuine Walker replacement parts. ®...

  • Page 6: Body / Chassis Assembly

    May be ordered as a factory-installed option or for dealer in- (Includes Item # F413) stallation. Narrow Drive Tires are used when installing a 36" 5270-1 Ball Bearing Deck. Contact your Walker dealer. 5420-2 Tail Wheel Fork 8769-12 Bearing Cup (1/2 ID) Complete Tilt-Up Latch Kit available by ordering kit P/N 5747.
  • Page 7 F004 F342 F004 GHS Group F038 F342 F009 F025 F009 F014 F004 0-12 F002 F413 F413 F009 F051 F014 F040 F009 F292 F637 F016 F637 F009 Refer to Electrical Assembly F157 Beginning S/N 168631 Use only genuine Walker replacement parts. ®...

  • Page 8: Rear Body Assembly

    10-24 x 3/8 Truss Head Torx 5105-6 Rear Body, Catcher Support Frame NOTE: Rear Bumper Assembly is not shown here. Refer to BODY / 8515-13 Catcher Handle Plate, LH CHASSIS ASSEMBLY, Page 4. Beginning S/N 168631 Use only genuine Walker replacement parts. ®...
  • Page 9 Refer to GHS 7.0 Bushel Catcher Assembly F390 F032 F390 F009 F617 F615 F031 F023 F569 F569 F569 F569 F009 F002 F026 F026 Refer to Body / Chassis Assembly F002 Beginning S/N 168631 Use only genuine Walker replacement parts. ®...

  • Page 10: Main Component Power Transmission

    8349-4 Idler Arm joined to the tractor spline shaft on the PTO gearbox. 7201-4 Inner Race (1-1/2) 5221-1 Extension Spring (3/4 x 5) Beginning S/N 168631 Use only genuine Walker replacement parts. ®...
  • Page 11 Refer to Hydrostatic Ground F002 F132 Drive Assemblies F025 Refer to Hydrostatic Ground F171 F012 Drive Assemblies F171 F090 F004 F004 F012 F042 F012 F041 Refer to F168 GHS Group F226 Beginning S/N 168631 Use only genuine Walker replacement parts. ®...

  • Page 12: Engine Group

    6013-14 Muffler Δ 6013-18 Muffler Heat Shield Refer to the Operator’s Manual for recommended part num- 6013-19 Muffler Brace ber. 8021-2 Engine Brace, Chassis NOTE: Refer to Kohler Engine Decal (NS) for Engine Identification 8021-1 Engine Brace Sensor, Oxygen (Kohler) Numbers. Beginning S/N 168631 Use only genuine Walker replacement parts. ®...
  • Page 13 F004 F482 F184 F185 F198 F175 F285 F009 F646 F091 F051 F009 F063 F570 F151 F050 F646 F061 F049 F031 F049 F034 F009 F038 Refer to Body / Chassis Assembly Beginning S/N 168631 Use only genuine Walker replacement parts. ®...

  • Page 14: Engine Group (Fuel Components)

    NOTE: Refer to Kohler Engine Decal (NS) for Engine Identification 5977-7 Roll Over Grommet (.900 x 1-1/2) Numbers. 5083-1 Bushing, Rubber 8055-2 Fuel Tank Gauge 5083-8 Tank Tube (13") M246 Fuel Line (1/4 x 20") 8016-6 ECU Mount Beginning S/N 168631 Use only genuine Walker replacement parts. ®...
  • Page 15 Engine Vapor Line F129 From F128 Fuel Pump Fuel Pump F002 Engine Engine Vapor Line Refer to Engine Group F029 F061 F079 F061 F029 Refer to Body / Chassis Assembly Beginning S/N 168631 Use only genuine Walker replacement parts. ®...

  • Page 16: Hydrostatic Ground Drive Assemblies

    1/8 x 1/8 x 3/4 Key 5847 Plastic Tip Service Part Only 5057 Lockout Cam Part not used on Jackshaft side of tractor. (Includes Item # F081) 5028-5 Lockout Lever 5027-5 Lockout Mount Beginning S/N 168631 Use only genuine Walker replacement parts. ®...
  • Page 17 F063 F569 F569 F004 F359 F064 F036 F032 F178 F043 F063 F023 F244 F040 F081 F053 F064 F027 F043 F063 F063 F200 F053 F160 F194 F053 F244 F194 F053 F200 Beginning S/N 168631 Use only genuine Walker replacement parts. ®...

  • Page 18: Steering Control Assemblies

    1/4-20 LP Nylock F353 3/8-16 ESNA LP Nut F401 .504 x .751 x .030 Washer F562 5/16-18 x 1 Set Screw F582 Washer 5/16 x 7/8 x .125 Service Part Only Beginning S/N 168631 Use only genuine Walker replacement parts. ®...
  • Page 19 F146 F193 Hydrostatic Ground Drive Assemblies F007 F010 F562 F050 F064 F188 F192 F345 F038 F198 F024 F007 F093 F008 F051 F029 F009 F183 F353 F068 F004 F010 F582 F034 Beginning S/N 168631 Use only genuine Walker replacement parts. ®...

  • Page 20: Throttle Control Assembly

    Bushing, SS (.375 x .188 x .290) F202 10-24 x 5/8 SHC Screw GR 5 8121-1 Throttle Cable F638 1/4-20 x 1 Carriage Bolt 8123 Insulating Sleeve (3/8 x 6) 5975-1 Cable Tie (18# x 3-3/4") Beginning S/N 168631 Use only genuine Walker replacement parts. ®...
  • Page 21 THROTTLE CONTROL ASSEMBLY Refer to Body / Chassis Assembly F638 F005 F201 Refer to Engine Group F202 F085 F002 Refer to GHS Group Beginning S/N 168631 Use only genuine Walker replacement parts. ®...

  • Page 22: Parking Brake Assembly

    Cable Clamp (1/4) F287 1/4-28 Keps Nut 7410 Brake Control Cable, LH (25.5") 7409 Brake Control Cable, RH (20.5") 7401-3 Cable Mount Bracket 7401-1 Cable Pull Rod 5552 Ball Joint (1/4-28) Beginning S/N 168631 Use only genuine Walker replacement parts. ®...
  • Page 23 F086 F086 F072 F109 F127 F261 F054 F086 F002 14 F112 F025 F086 F127 F109 F072 F002 F127 F025 F261 F054 14 F112 Refer to Hydrostatic F127 Ground Drive Assemblies Beginning S/N 168631 Use only genuine Walker replacement parts. ®...

  • Page 24: Ghs Group

    Broom Attachment and Snowblower Attachment. Use of this 7543-1 Blower Faceplate (10.5") part may be replaced by installing Blower Lockout Kit 7526 Intake Tube (10.5" Blower) (P/N 7541-1). 5595-2 Intake Cover, GHS 7528-5 Skid Bar Beginning S/N 168631 Use only genuine Walker replacement parts. ®...
  • Page 25 15 14 GHS Powerfil F090 F132 Assembly (7.0) F426 F042 F004 F168 F009 F131 F029 F050 F004 Refer to Body / Chassis Assembly F217 F218 F009 F039 F051 F034 F012 F281 Beginning S/N 168631 Use only genuine Walker replacement parts. ®...

  • Page 26: Ghs Powerfil ® Assembly (7.0)

    10-24 x 1/2 Truss Head Torx 5517-2 Pivot Mount 5519-5 Actuator Motor (12V) Service Part Only (Includes Items # 11 & 12) 5519-2 Motor Mount Washer 5519-3 Motor Mount Nut (5/8-24) 5554 Actuator Arm Beginning S/N 168631 Use only genuine Walker replacement parts. ®...
  • Page 27 Refer to Electrical Assemblies (GHS 7.0 Bushel F054 Components) F023 F023 Refer to GHS 7.0 Bushel Catcher Assembly F287 F612 F613 F612 F613 F023 F023 F612 Refer to GHS Group Beginning S/N 168631 Use only genuine Walker replacement parts. ®...

  • Page 28: Ghs 7.0 Bushel Catcher Assembly

    Door Arm Stop 7505 Mustache Spring 5598-2 Optional Dump Bag (Not Shown) 7509-6 C-Channel With Spring May be ordered as an option. Contact your Walker dealer. (Includes Items # 7 & F340) 7509-8 Channel Top, RH Fasteners 7.0 Exhaust Deflector Door Assembly...
  • Page 29 F618 Refer to F618 Rear Body Assembly F411 F351 F411 F411 F390 F618 F411 F023 Refer to F023 F613 Rear Body Assembly Refer to F613 Electrical Assembly F023 F613 F023 Beginning S/N 168631 Use only genuine Walker replacement parts. ®...

  • Page 30: Electrical Assembly

    Cable Tie (18# x 3-3/4") 5844-3 Battery Hold-Down Bar 5839 Hook Bolt 6390-2 Battery Pan Battery (12V/350 CCA/Wet/SP-40) 5932 Battery Terminal Insul., Black (-) 5933 Battery Terminal Insul., Red (+) 6923 Battery Cable (-) Beginning S/N 168631 Use only genuine Walker replacement parts. ®...
  • Page 31 P/N-7942-9 P/N-7942-4 END VIEWS ARE SHOWN FROM BACK OF PLUG DETAIL L DETAIL M DETAIL N DETAIL O DETAIL P DETAIL Q BRN/ BRN/WHT P/N-7942-2 P/N-7942-2 P/N-7942-5 P/N-7942-5 P/N-7942-5 P/N-NS Beginning S/N 168631 Use only genuine Walker replacement parts. ®...

  • Page 32: Electrical Assemblies (Ghs 7.0 Bushel Components)

    10-24 x 5/8 Truss Head Torx 8950-4 Powerfil Wire Harness (7.0/10.0) F613 10-24 x 1/2 Truss Head Torx 5833 Cable Clamp (1/4) 5594-6 Aluminum Shaft & Vane Assembly Service Part Only ® 5592-20 Grass-Pak Switch Assembly Beginning S/N 168631 Use only genuine Walker replacement parts. ®...
  • Page 33 Refer to GHS Group F025 GHS Group F023 F002 DETAIL A BLK/WHT F509 P/N-NS P/N-NS F612 DETAIL B F509 F508 END VIEWS ARE SHOWN FROM BACK OF PLUG BLK/WHT P/N-8942 Beginning S/N 168631 Use only genuine Walker replacement parts. ®...

  • Page 34: Lubrication Points

    Jackshaft Drive and Gear Axles. PTO Clutch Lever Pivot Grease Clutch Actuator Push Rod Grease NOTE: See Model C19i Operator’s Manual (P/N 6000-33) Belt Tightener Pivot, Grease for proper lubrication intervals. PTO Clutch Beginning S/N 168631 Use only genuine Walker replacement parts.
  • Page 35 LUBRICATION POINTS 21 & 25 Beginning S/N 168631 Use only genuine Walker replacement parts. ®...

  • Page 36: Wiring Schematic

    WIRING SCHEMATIC WALKER MODEL C19i Beginning S/N 154995 IGNITION SWITCH CIRCUITS RELAY - A POWERFIL MOTOR CASE GROUND IGNITION RELAY G + M TO MOTOR MOUNT START B + A / S1 + S2 30 + 87A B + A...

  • Page 37: Maintenance And Service Record Sheet

    ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ Beginning S/N 168631 Use only genuine Walker replacement parts. ®...
  • Page 38 ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ ______________________________________________________________________________________________________________ Beginning S/N 168631 Use only genuine Walker replacement parts. ®...

  • Page 39: Limited Warranty

    (2) years* after the date of sale to the original retail pur- chaser unless the product is used for rental purposes, in which case this warranty is limited to ninety (90) days. At Walker’s request, customer will make the defective part available for inspection by Walker and/or return the defective part to Walker, transportation charges prepaid.
  • Page 40 WALKER MFG. CO. • 5925 E. HARMONY ROAD, FORT COLLINS, CO 80528 • (970) 221-5614 FORM NO. 051821 PRINTED IN USA www.walker.com ©2021 WALKER MFG. CO...
