Ultra UF17200 Installation

Replacement Parts / Pièces de rechange / Repuestos
NO. Description Part No.
1 Spring 5T3005600CC/AP/HA/HBW0
2 Hose 5G0024900CP/AP/HA/HBW0
3 Spray Head 5F0014300CP/AP/HA/HBW0
4a Flange 9Q171400CP/AP/HA/HBW
4b Deckplate Assembly 5Y0165500CP/AP/HA/HBW0
5 Flow-Limiting Valve 5X0P0086PL
6 Clamping Ring 5M0004500NT0
7 Cartridge 5D0004300PL0
8 Bonnet 5T1A0003AL
9 Cap 5L0P0506CP/AP/HA/HBW
10 Handle Assembly 5Y0263800CP/AP/HA/HBW0
11 Guide 53001413PL
12 Mounting Hardware 5Q0M0207NT
Limited Lifetime Warranty
Ultra Faucets warrants to the original purchaser that its products will be free from defects in workmanship and materials. All Ultra
Faucets are provided with a life time limited warranty. This warranty does not cover any other labor or service charges associated with
the removal, repair, or reinstallation of Ultra Faucets products. This express warranty does not apply to products that have been
damaged as a result of misuse, abuse, negligence, accident, faulty installation or maintenance practices and/or used in any manner
contrary to those recommended by the manufacturer.
Need help? Please call our toll-free customer service line at 1-888-658-5872 for additional assistance or service.
Besoin d'aide? Veuillez communiquer avec notre service à la clientèle au numéro gratuit 1-888-658-5872 pour tous renseignements
ou services complémentaires.
¿Requiere asistencia? Llame a nuestro Servicio al Cliente, sin costo, al 1-888-658-5872 para asistencia adicional o servicio.
UF17200
UF17203
UF17205
UF17207
1
5
6
2
3
7
8
9
4a
10
4b
11
12
Revised 12-2019
Euro Collection
Spring Spout Kitchen Faucet
Installation/Installation/Instalación
CUSTOMER SERVICE
TOLL-FREE 1-888-OK-ULTRA (658-5872)
UF17200 - Polished Chrome
UF17203 - PVD Brushed Nickel
UF17205 - Oil Rubbed Bronze
UF17207 - Matte Black
Tools You Will Need / Outils dont vous aurez besoin / Herramientas necesarias
Adjustable Wrench
Clé à molette
Llave ajustable
• If you use soldering for the installation of the faucet, the seats, cartridges and washers will have to be removed
before using flame. Otherwise, warranty will be void on those parts.
• Cover your drain to avoid losing parts.
• 0℃~55℃.
CONSIGNES DE SÉCURITÉ
• Si vous posez le robinet par brasage, il est essentiel de retirer les sièges, les cartouches et les rondelles avant
d'appliquer la flamme, faute de quoi la garantie sur ces pièces sera annulée.
• Couvrez le drain pour ne pas perdre des pièces.
• 0℃~55℃.
CONSEJOS DE SEGURIDAD
• En el caso de utilizar soldadura para instalar el grifo, remueva los asientos, cartuchos y arandelas antes de usar la
llama. De lo contrario, se anulará la garantía para esos componentes.
• Tape la boca del desagüe para prevenir la pérdida de piezas pequeñas.
• 0℃~55℃.
Phillips Screwdriver
Tournevis Phillips
Destornillador cruciforme
SAFETY TIPS
Revised 12-2019
