PicC Electronics SMS ALERT 15 Alarm Plus User Manual

Hide thumbs
1
2
3
4
5
6
7
8
9
Table of Contents

Advertisement

Quick Links

Download this manual
Main features
11 Zone Alarm module.
-
15 inputs, reports to 8 users.
-
No Relay outputs.
-
Additional Power Loss/Restore, Panic, Key and Battery Low inputs.
-
Silent listen-in microphone.
-
Zones can be switched on and off via SMS, or changed from NC to NO.
-
Siren output.
-
Silent mode operation without siren activation.
-
The first 4 users receive all the SMS'e, and the last 4 users only receive Panic SMS'e.
-
Technician mode available.
-
No wal- through or test mode available as per SA9 Alarm Plus.
-
Page 1 of 9
Copyright Reserved ©: PicC Electronics (2019)
For technical support, contact: 011 202 5884 or 083 235 4916.
SMS ALERT 15 Alarm Plus
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMS ALERT 15 Alarm Plus and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PicC Electronics SMS ALERT 15 Alarm Plus

Summary of Contents for PicC Electronics SMS ALERT 15 Alarm Plus

  • Page 1 Copyright Reserved ©: PicC Electronics (2019) For technical support, contact: 011 202 5884 or 083 235 4916. SMS ALERT 15 Alarm Plus User Manual Main features 11 Zone Alarm module. 15 inputs, reports to 8 users. No Relay outputs. Additional Power Loss/Restore, Panic, Key and Battery Low inputs.

  • Page 2: Quick Start Steps

    Copyright Reserved ©: PicC Electronics (2019) Quick Start Steps 1. Preparing SIM-card - Buy an MTN, Vodacom or Cell C starter pack (prepaid or contract) and RICA it (you need your id and proof of address for this). Ensure that you can send an SMS out from the SIM-card, before you put it in the SIM-card slot of the SMS Alert.

  • Page 3: Other Commands

    Copyright Reserved ©: PicC Electronics (2019) 1234 b.27821231234 (only use 1234 b,c etc., with no phone number if it is not a remote number) 1234 e.27821231234 If a user is already loaded, then the command will first delete it (toggle off). It then needs to be sent again. The international setting must be activated for use outside of SA before this can be done (not tested).
  • Page 4 Copyright Reserved ©: PicC Electronics (2019) Auto-answer (silent listen-in) This applies to SMS Alerts fitted with a microphone. By default Auto-Answer is on. When you dial the SMS Alert from any cellphone, the unit will ring twice silently, pick up the call and you will be able to hear surrounding noises via the microphone.

  • Page 5: How To Insert The Sim-Card

    Copyright Reserved ©: PicC Electronics (2019) Transfer airtime from one cellphone Dial *141*6328*, insert the recipient’s to another cellphone number, *, insert the rand amount, # and press call. For example, *141*6328*0831234567*50# press call. Airtime on prepaid SIM-cards can also be checked by registering the cellphone number of the SMS Alert on www.vodacom4me.co.za...

  • Page 6: Technical Specifications

    Copyright Reserved ©: PicC Electronics (2019) SMS Alert PCB top view 9 – Panic (NO) - Key – Pulse with +12V for Arm/Disarm 8 – Zone 8a (NC) 7 – Zone 7a (NC) Zone 10 (NC) -10 6 – Zone 6a (NC) Zone 11 (NC) -11 5 –...
  • Page 7 Copyright Reserved ©: PicC Electronics (2019) Refer to the following table if you want to switch zones on/off. E.g. to switch Zone 12 off, SMS 1234 10. Input Description Other 1234 01 Will turn off Zone 1 (Input 8), send again to...

  • Page 8: Fault Finding / Troubleshooting

    Copyright Reserved ©: PicC Electronics (2019) Fault finding / Troubleshooting No or bad cellphone signal Ensure the SIM-card holder contacts are clean. Use an earbud. Try to use an external aerial (available from supplier). Flashing green LED Re-power the SMS Alert system. This happens when the SMS Alert’s power is connected (reset) three times in a short period.
  • Page 9 SIM-card, or to limit SMS’s - should a malfunction occur where many SMS’s are sent and unforeseen costs are incurred. It is recommended to test your SMS Alert on a regular basis. A product of PicC Electronics must be installed by an installer trained by PicC Electronics or with relevant installation experience.
