- Page 1 USER MANUAL FOR AC-26 POOL FILTER AC-26 POOL FILTER INSTALLATION OPERATION MANUAL...
- Page 2 USER MANUAL FOR AC-26 POOL FILTER KNOW YOUR PLANT: Name of parts: Water outlet Underwater light Plant box Water inlet (Fig. 1-Front View) AC-25 FILTRATION SYSTEM AC-25 FILTRATION SYSTEM INCLUDES TWO PARTS： ——“FILTER AREA” is immerged in the swimming pool，with underwater light. It includes 1 skimmer, 2 jets, 2xFiltering drums and union pipes.
-
Page 3: Installation Instruction
USER MANUAL FOR AC-26 POOL FILTER ——Pipe free, no plant room，low pump power consumption； ——LED underwater light, low power consumption(7.5w)； ——Inter cooling system, hot air is removed from the technical house by vacuum suction created by the water jets; ——Filter bag is easy to clean(using high pressure water） ；... - Page 4 USER MANUAL FOR AC-26 POOL FILTER (Fig. 2- Dimensions) (Fig.3- Plan Layout)
- Page 5 USER MANUAL FOR AC-26 POOL FILTER Ⅱ. Electrical installation instruction: NOTE: Electrical installation must be operated by the qualified technician. (Fig. 4- Wiring of Connection box) (Fig. 5- Wiring of control box)
- Page 6 USER MANUAL FOR AC-26 POOL FILTER OPERATION INSTRUCTION FOR DIGITAL CONTROL PANEL: (Fig. 6- control panel) Ⅰ. Instructions for manual operation: ON/OFF key: Connect the power supply and press ON/OFF key, pump 1 and Ozone disinfection system will go into working automatically.
- Page 7 USER MANUAL FOR AC-26 POOL FILTER during the set operation periods. Set automatic operation periods: Remark: Before setting the automatic operation periods, set the water temperature lower than the actual water temperature. Otherwise, the pump 1 will work all the time, and can’t controlled by operation periods time.
-
Page 8: Troubleshooting
USER MANUAL FOR AC-26 POOL FILTER TROUBLE SHOOTING PROBLEM REASON SOLUTION Filter bag is removed; Put back the filter bags, replace Pump is running Filter bag is not placed correctly in with clean bags but filtering the drums Filter bag is dirty... -
Page 9: Notes For Maintenance
USER MANUAL FOR AC-26 POOL FILTER SAFETY 1. ROUTINE The device is limited to be used in tap water. The filter is limited to be used for swimming pool water treatment and prohibited to be used for other water treatment.
