- Page 1 Installation Operation Maintenance Manual Oil-sealed liquid ring vacuum pump systems SERIAL NO.:___________________________ June, 2006/13...
-
Page 2: Table Of Contents
Separator element Separator element oil return line Mechanical shaft seals MAINTENANCE SCHEDULE ELECTRICAL CONTROLS ACCESSORIES AND PROTECTIVE DEVICES Accessories Protective devices TROUBLE SHOOTING Trouble shooting guide CUSTOMER SERVICE AND INFORMATION Order information WARRANTY POLICY Dekker Vacuum Technologies, Inc. – Vmax/13... -
Page 3: Introduction
INTRODUCTION The Vmax oil-sealed liquid ring vacuum pump system have been designed to give you safe, reliable trouble-free service, provided some of the basic maintenance guidelines as set out in this manual are followed. Compared with other vacuum pump systems the Vmax oil-sealed liquid ring vacuum pump system offers the advantages of no metal-to-metal contact between the impeller and casing. -
Page 4: Ventilation
OSHA, National Electric Code and any other applicable local electrical code concerning switches, fused disconnects, etc. DEKKER includes a wiring diagram in the control panel for use by the installer. DEKKER recommends that a main disconnect switch be fitted between the vacuum system and the incoming power. -
Page 5: Vmax-Vfd Operational Instructions
OSHA, National Electric Code and any other applicable local electrical code concerning switches, fused disconnects, etc. DEKKER includes a wiring diagram in the control panel for use by the installer. DEKKER recommends that a main disconnect switch be fitted between the vacuum system and the incoming power. -
Page 6: Vmax-Vfd Value Chart
311.60 17.65 97.00 9.70 661.20 3.89 52.00 5.20 319.20 17.35 98.00 9.80 668.80 3.59 53.00 5.30 326.80 17.05 99.00 9.90 676.40 3.29 54.00 5.40 334.40 16.76 100.00 10.00 684.00 2.99 55.00 5.50 342.00 16.46 Dekker Vacuum Technologies, Inc. – Vmax/13... -
Page 7: Pipe Connections And Sizing
Vmax systems are supplied with an inlet check valve as standard. This valve provides a minimum of resistance close to the pump suction flange to prevent back flow of process gas and seal fluid when the pump is stopped. -
Page 8: Theory Of Operation
The discharge separator/reservoir holds the seal fluid and incorporates the DEKKER patented high-efficiency separator arrangement to separate the seal fluid from the air or gases discharged by the pump. See “Piping and Instrument Diagram” of the Vmax oil-sealed liquid ring vacuum pump system below. - Page 9 2 psig when operating under vacuum conditions. A pressure higher than 2 psig is a sign of high back-pressure in the discharge pipe system. Pressure gauge might show a higher pressure at start-up at low vacuum (0-10" Hg). Dekker Vacuum Technologies, Inc. – Vmax/13...
-
Page 10: Shut-Down Procedures
Open valves before starting system. SEQUENCE OF OPERATION The following sequence of operation is a description of how the Vmax oil-sealed vacuum pump system should operate. The description is general to cover simplex to multiplex (more than one pump) systems. It is assumed that all start-up procedures have been followed. -
Page 11: System Alarm Conditions
The back-up pump(s) will continue to operate unless a similar condition occurs in those pump(s). MAINTENANCE As you proceed in reading this section, it will become clear that the “Maintenance Schedule” for DVT Vmax oil-sealed liquid ring vacuum pump systems is quite minimal. The use of the service gauges will alert you when service is required. -
Page 12: Bearing Lubrication - Motor (Where Required)
182-215 3 years 1 year 6 months 182-215 1800 254-365 2 years 6-12 months 3 months 254-286 1800 404-449 1 year 6 months 1-3 months 324-365 3600 6 months 3 months 1 month 404-449 Dekker Vacuum Technologies, Inc. – Vmax/13... -
Page 13: Inlet Filter
The system(s) are shipped with our especially formulated Vmaxol seal fluid. These fluids are specifically designed for use in our Vmax systems, providing low viscosity, excellent water separating qualities, anti- foaming and low oxidation. We recommend that our Vmaxol sealing fluids be used for obtaining ultimate performance from your Vmax vacuum pump system and to guarantee the extended 3-year warranty period. -
Page 14: Spin-On Oil Filter (If Installed)
Mechanical Shaft Seals All DEKKER oil-sealed liquid ring vacuum pumps are fitted with mechanical shaft seals. Mechanical seals do not require maintenance unless there is more than a small amount of leakage. To define this we... -
Page 15: Electrical Controls
10,000 hours of operation Or once per year, change seal fluid. Use DEKKER Vmaxol seal fluid. Life of Standard Vmaxol is 10,000 hours of operation. Synthetic/Food grade Long-life Vmaxol may be changed every 15,000 hours of operation or once a year, whichever comes first. - Page 16 Usually the valve is used to isolate the vacuum system from the piping network. ♦ Inlet Filter (optional): An inlet filter may be installed on the Vmax oil-sealed vacuum pump systems to prevent carry-over of particles into the pump.
- Page 17 4. Arrow down to Start and press OK. (This will save the changes) 5. Turn pump(s) to Automatic mode. Vacuum pump ON/OFF settings for Microprocessing Controller (Vacuum in “Hg): When setting the ON and OFF switch points in your Controller, use the following table for reference: Dekker Vacuum Technologies, Inc. – Vmax/13...
- Page 18 Lag pump ON at 15”HgV – OFF at 18”HgV - Specific Block number for Triplex Controller Program: Lead Pump =B15 Mid pump =B16 Lag pump =B23 Alarm visual/audible =B13 (Typically set to come on and off with lag pump settings) Dekker Vacuum Technologies, Inc. – Vmax/13...
-
Page 19: Protective Devices
The following protective devices are available to protect the unit from being damaged and to help with maintenance. ♦ High Temperature Switch (standard except on Vmax ): will signal when the temperature of the oil is exceeding the shut-down level. The switch will shut the unit down. The unit will not restart until the alarm condition is acknowledged and is reset. -
Page 20: Trouble Shooting
TROUBLE-SHOOTING Following is a basic trouble-shooting guide. We recommended that you consult your local dealer for service. Each Vmax system is tested and checked at the factory. Always indicate system model and serial number when calling. WARNING: Before attempting any repairs, disconnect all power from the system by switching off the main breaker or disconnect switch. - Page 21 Also insulate the seal-fluid solenoid valve (if installed). NOISE AND VIBRATION PROBLEMS: The system is making an abnormal noise or sound: (Vmax) Stop system and disconnect power. Check the coupling and/or element for proper alignment. If worn or damaged, replace.
-
Page 22: Customer Service And Information
Refer to the bill of lading or the gold-colored system information plate attached to the system. Parts should be purchased from the nearest authorized DEKKER representative or from the vacuum pump system supplier. If for any reason parts cannot be obtained in this manner, contact the factory directly. -
Page 23: Warranty Policy
Vmax systems: full 3-year warranty from date of shipment, provided the system is operated exclusively with DEKKER Vmaxol sealing liquid and is operated during the full warranty period as per the instructions given in the Operation and Maintenance Manual. If purchaser elects not to use DEKKER seal-fluids, system warranty shall be 2 years if fluid is approved by DEKKER.
